Provide a means of reading/writing the single-file OpenFOAM extendedEdgeMesh format. More...

Inheritance diagram for extendedEdgeMeshFormat:

Collaboration diagram for extendedEdgeMeshFormat:

Public Member Functions
	extendedEdgeMeshFormat (const fileName &)
	Construct from file name. More...

	extendedEdgeMeshFormat (const extendedEdgeMeshFormat &)=delete
	Disallow default bitwise copy construction. More...

virtual	~extendedEdgeMeshFormat ()
	Destructor. More...

virtual bool	read (const fileName &)
	Read from file. More...

void	operator= (const extendedEdgeMeshFormat &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from extendedEdgeMesh
	TypeName ("extendedEdgeMesh")
	Runtime type information. More...

	extendedEdgeMesh ()
	Construct null. More...

	extendedEdgeMesh (const extendedEdgeMesh &)
	Copy constructor. More...

	extendedEdgeMesh (extendedEdgeMesh &&)
	Move constructor. More...

	extendedEdgeMesh (const fileName &)
	Construct from file name (uses extension to determine type) More...

	extendedEdgeMesh (const fileName &, const word &ext)
	Construct from file name (uses extension to determine type) More...

	extendedEdgeMesh (Istream &)
	Construct from Istream. More...

	extendedEdgeMesh (pointField &&, edgeList &&)
	Construct by transferring components (points, edges) More...

	extendedEdgeMesh (const surfaceFeatures &sFeat, const boolList &surfBaffleRegions)
	Construct given a surface with selected edges,points. More...

	extendedEdgeMesh (const PrimitivePatch< faceList, pointField > &surf, const labelList &featureEdges, const labelList &regionFeatureEdges, const labelList &featurePoints)
	Construct from PrimitivePatch. More...

	extendedEdgeMesh (const pointField &pts, const edgeList &eds, label concaveStart, label mixedStart, label nonFeatureStart, label internalStart, label flatStart, label openStart, label multipleStart, const vectorField &normals, const List< sideVolumeType > &normalVolumeTypes, const vectorField &edgeDirections, const labelListList &normalDirections, const labelListList &edgeNormals, const labelListList &featurePointNormals, const labelListList &featurePointEdges, const labelList &regionEdges)
	Construct from all components. More...

	declareRunTimeSelectionTable (autoPtr, extendedEdgeMesh, fileExtension,(const fileName &name),(name))

	~extendedEdgeMesh ()
	Destructor. More...

void	nearestFeaturePoint (const point &sample, scalar searchDistSqr, pointIndexHit &info) const
	Find nearest surface edge for the sample point. More...

void	nearestFeatureEdge (const point &sample, scalar searchDistSqr, pointIndexHit &info) const
	Find nearest surface edge for the sample point. More...

void	nearestFeatureEdge (const pointField &samples, const scalarField &searchDistSqr, pointIndexHitList &info) const
	Find nearest surface edge for each sample point. More...

void	nearestFeatureEdgeByType (const point &sample, const scalarField &searchDistSqr, pointIndexHitList &info) const
	Find the nearest point on each type of feature edge. More...

void	allNearestFeaturePoints (const point &sample, scalar searchRadiusSqr, pointIndexHitList &info) const
	Find all the feature points within searchDistSqr of sample. More...

void	allNearestFeatureEdges (const point &sample, const scalar searchRadiusSqr, pointIndexHitList &info) const
	Find all the feature edges within searchDistSqr of sample. More...

scalar	minDisconnectedDist (const pointIndexHitList &hitList) const
	Return the minimum distance between disconnected edges. More...

label	convexStart () const
	Return the index of the start of the convex feature points. More...

label	concaveStart () const
	Return the index of the start of the concave feature points. More...

label	mixedStart () const
	Return the index of the start of the mixed type feature points. More...

label	nonFeatureStart () const
	Return the index of the start of the non-feature points. More...

label	externalStart () const
	Return the index of the start of the external feature edges. More...

label	internalStart () const
	Return the index of the start of the internal feature edges. More...

label	flatStart () const
	Return the index of the start of the flat feature edges. More...

label	openStart () const
	Return the index of the start of the open feature edges. More...

label	multipleStart () const
	Return the index of the start of the multiply-connected feature. More...

bool	featurePoint (label ptI) const
	Return whether or not the point index is a feature point. More...

const vectorField &	normals () const
	Return the normals of the surfaces adjacent to the feature edges. More...

const List< sideVolumeType > &	normalVolumeTypes () const
	Return. More...

const vectorField &	edgeDirections () const
	Return the edgeDirection vectors. More...

const labelListList &	normalDirections () const

vector	edgeDirection (label edgeI, label ptI) const
	Return the direction of edgeI, pointing away from ptI. More...

const labelListList &	edgeNormals () const
	Return the indices of the normals that are adjacent to the. More...

vectorField	edgeNormals (const labelList &edgeNormIs) const
	Return the normal vectors for a given set of normal indices. More...

vectorField	edgeNormals (label edgeI) const
	Return the normal vectors for a given edge. More...

const labelListList &	featurePointNormals () const
	Return the indices of the normals that are adjacent to the. More...

vectorField	featurePointNormals (label ptI) const
	Return the normal vectors for a given feature point. More...

const labelListList &	featurePointEdges () const
	Return the edge labels for a given feature point. Edges are. More...

const labelList &	regionEdges () const
	Return the feature edges which are on the boundary between. More...

pointStatus	getPointStatus (label ptI) const
	Return the pointStatus of a specified point. More...

edgeStatus	getEdgeStatus (label edgeI) const
	Return the edgeStatus of a specified edge. More...

PackedList< 2 >	edgeBaffles (label edgeI) const
	Return the baffle faces of a specified edge. More...

const indexedOctree< treeDataPoint > &	pointTree () const
	Demand driven construction of octree for feature points. More...

const indexedOctree< treeDataEdge > &	edgeTree () const
	Demand driven construction of octree for boundary edges. More...

const PtrList< indexedOctree< treeDataEdge > > &	edgeTreesByType () const
	Demand driven construction of octree for boundary edges by type. More...

void	transfer (extendedEdgeMesh &)
	Transfer the contents of the argument and annul the argument. More...

virtual void	clear ()
	Clear all storage. More...

void	add (const extendedEdgeMesh &)
	Add extendedEdgeMesh. No filtering of duplicates. More...

void	flipNormals ()
	Flip normals. All concave become convex, all internal external. More...

bool	read (const fileName &, const word &ext)
	Read from file. Chooses reader based on explicit extension. More...

void	writeObj (const fileName &prefix, const bool verbose=true) const
	Write all components of the extendedEdgeMesh as obj files. More...

virtual void	writeStats (Ostream &os) const
	Dump some information. More...

Public Member Functions inherited from edgeMesh
	TypeName ("edgeMesh")
	Runtime type information. More...

	edgeMesh ()
	Construct null. More...

	edgeMesh (const pointField &, const edgeList &)
	Construct from components. More...

	edgeMesh (pointField &&, edgeList &&)
	Construct by transferring components (points, edges). More...

	edgeMesh (const edgeMesh &)
	Copy constructor. More...

	edgeMesh (edgeMesh &&)
	Move constructor. More...

	edgeMesh (const fileName &)
	Construct from file name (uses extension to determine type) More...

	edgeMesh (const fileName &, const word &ext)
	Construct from file name (uses extension to determine type) More...

	edgeMesh (Istream &)
	Construct from Istream. More...

	declareRunTimeSelectionTable (autoPtr, edgeMesh, fileExtension,(const fileName &name),(name))

virtual	~edgeMesh ()
	Destructor. More...

	declareMemberFunctionSelectionTable (void, edgeMesh, write, fileExtension,(const fileName &name, const edgeMesh &mesh),(name, mesh))

void	transfer (edgeMesh &)
	Transfer the contents of the argument and annul the argument. More...

bool	read (const fileName &, const word &ext)
	Read from file. Chooses reader based on explicit extension. More...

const pointField &	points () const
	Return points. More...

const edgeList &	edges () const
	Return edges. More...

const labelListList &	pointEdges () const
	Return edges. More...

label	regions (labelList &edgeRegion) const
	Find connected regions. Set region number per edge. More...

virtual void	reset (pointField &&points, edgeList &&edges)
	Reset primitive data (points, edges) More...

virtual void	scalePoints (const scalar)
	Scale points. A non-positive factor is ignored. More...

virtual void	mergeEdges ()
	Merge duplicate edges. More...

virtual void	write (const fileName &name) const
	Generic write routine. Chooses writer based on extension. More...

void	operator= (const edgeMesh &)

void	operator= (edgeMesh &&)

Additional Inherited Members
Public Types inherited from extendedEdgeMesh
enum	pointStatus { CONVEX , CONCAVE , MIXED , NONFEATURE }

enum	edgeStatus { EXTERNAL , INTERNAL , FLAT , OPEN , MULTIPLE , NONE }

enum	sideVolumeType { INSIDE = 0 , OUTSIDE = 1 , BOTH = 2 , NEITHER = 3 }
	Normals point to the outside. More...

Static Public Member Functions inherited from extendedEdgeMesh
static bool	canRead (const fileName &, const bool verbose=false)
	Can we read this file format? More...

static bool	canReadType (const word &ext, const bool verbose=false)
	Can we read this file format? More...

static bool	canWriteType (const word &ext, const bool verbose=false)
	Can we write this file format type? More...

static wordHashSet	readTypes ()

static wordHashSet	writeTypes ()

static autoPtr< extendedEdgeMesh >	New (const fileName &, const word &ext)
	Select constructed from filename (explicit extension) More...

static autoPtr< extendedEdgeMesh >	New (const fileName &)
	Select constructed from filename (implicit extension) More...

static edgeStatus	classifyEdge (const List< vector > &norms, const labelList &edNorms, const vector &fC0tofC1)
	Classify the type of feature edge. Requires face centre 0 to face. More...

Static Public Member Functions inherited from edgeMesh
static bool	canRead (const fileName &, const bool verbose=false)
	Can we read this file format? More...

static bool	canReadType (const word &ext, const bool verbose=false)
	Can we read this file format? More...

static bool	canWriteType (const word &ext, const bool verbose=false)
	Can we write this file format type? More...

static wordHashSet	readTypes ()

static wordHashSet	writeTypes ()

static autoPtr< edgeMesh >	New (const fileName &, const word &ext)
	Select constructed from filename (explicit extension) More...

static autoPtr< edgeMesh >	New (const fileName &)
	Select constructed from filename (implicit extension) More...

static void	write (const fileName &, const edgeMesh &)
	Write to file. More...

Static Public Member Functions inherited from edgeMeshFormatsCore
static bool	checkSupport (const wordHashSet &available, const word &ext, const bool verbose, const word &functionName)
	... More...

Static Public Attributes inherited from extendedEdgeMesh
static const Foam::NamedEnum< pointStatus, 4 >	pointStatusNames_

static const Foam::NamedEnum< edgeStatus, 6 >	edgeStatusNames_

static const Foam::NamedEnum< sideVolumeType, 4 >	sideVolumeTypeNames_

static scalar	cosNormalAngleTol_
	Angular closeness tolerance for treating normals as the same. More...

static label	nPointTypes = 4
	Number of possible point types (i.e. number of slices) More...

static label	nEdgeTypes = 5
	Number of possible feature edge types (i.e. number of slices) More...

Static Public Attributes inherited from edgeMeshFormatsCore
static word	nativeExt
	The file extension corresponding to 'native' edge format. More...

Protected Member Functions inherited from extendedEdgeMesh
pointStatus	classifyFeaturePoint (label ptI) const
	Classify the type of feature point. Requires valid stored member. More...

template<class Patch >
void	sortPointsAndEdges (const Patch &, const labelList &featureEdges, const labelList &regionFeatureEdges, const labelList &feaurePoints)

Protected Member Functions inherited from edgeMesh
pointField &	storedPoints ()
	Non-const access to global points. More...

edgeList &	storedEdges ()
	Non-const access to the edges. More...

Static Protected Member Functions inherited from edgeMeshFormatsCore
static string	getLineNoComment (IFstream &)
	Read non-comment line. More...

Protected Attributes inherited from extendedEdgeMesh
label	concaveStart_
	Index of the start of the concave feature points. More...

label	mixedStart_
	Index of the start of the mixed type feature points. More...

label	nonFeatureStart_
	Index of the start of the non-feature points. More...

label	internalStart_
	Index of the start of the internal feature edges. More...

label	flatStart_
	Index of the start of the flat feature edges. More...

label	openStart_
	Index of the start of the open feature edges. More...

label	multipleStart_
	Index of the start of the multiply-connected feature edges. More...

vectorField	normals_
	Normals of the features, to be referred to by index by both feature. More...

List< sideVolumeType >	normalVolumeTypes_
	Type per normal: which side of normal to mesh. More...

vectorField	edgeDirections_
	Flat and open edges require the direction of the edge. More...

labelListList	normalDirections_
	Starting directions for the edges. More...

labelListList	edgeNormals_
	Indices of the normals that are adjacent to the feature edges. More...

labelListList	featurePointNormals_
	Indices of the normals that are adjacent to the feature points. More...

labelListList	featurePointEdges_
	Indices of feature edges attached to feature points. The edges are. More...

labelList	regionEdges_
	Feature edges which are on the boundary between regions. More...

autoPtr< indexedOctree< treeDataPoint > >	pointTree_
	Search tree for all feature points. More...

autoPtr< indexedOctree< treeDataEdge > >	edgeTree_
	Search tree for all edges. More...

PtrList< indexedOctree< treeDataEdge > >	edgeTreesByType_
	Individual search trees for each type of edge. More...

Static Protected Attributes inherited from extendedEdgeMesh
static label	convexStart_ = 0
	Index of the start of the convex feature points - static as 0. More...

static label	externalStart_ = 0
	Index of the start of the external feature edges - static as 0. More...

Detailed Description

Provide a means of reading/writing the single-file OpenFOAM extendedEdgeMesh format.

Source files

Definition at line 51 of file extendedEdgeMeshFormat.H.

Constructor & Destructor Documentation

◆ extendedEdgeMeshFormat() [1/2]

extendedEdgeMeshFormat ( const fileName & filename )

Construct from file name.

Definition at line 33 of file extendedEdgeMeshFormat.C.

References extendedEdgeMeshFormat::read().

Here is the call graph for this function:

◆ extendedEdgeMeshFormat() [2/2]

extendedEdgeMeshFormat ( const extendedEdgeMeshFormat & )

delete

Disallow default bitwise copy construction.

◆ ~extendedEdgeMeshFormat()

virtual ~extendedEdgeMeshFormat ( )

inlinevirtual

Destructor.

Definition at line 67 of file extendedEdgeMeshFormat.H.

Member Function Documentation

◆ read()

bool read ( const fileName & filename )

virtual

Read from file.

Reimplemented from extendedEdgeMesh.

Definition at line 44 of file extendedEdgeMeshFormat.C.

References clear(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, typeIOobject< Type >::filePath(), IOstream::good(), typeIOobject< Type >::headerOk(), fileName::name(), IOobject::NO_READ, IOobject::NO_WRITE, fileName::path(), and IOobject::readHeader().

Referenced by extendedEdgeMeshFormat::extendedEdgeMeshFormat().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=()

void operator= ( const extendedEdgeMeshFormat & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/meshTools/edgeMesh/extendedEdgeMesh/extendedEdgeMeshFormats/extendedEdgeMeshFormat/extendedEdgeMeshFormat.H
src/meshTools/edgeMesh/extendedEdgeMesh/extendedEdgeMeshFormats/extendedEdgeMeshFormat/extendedEdgeMeshFormat.C

Public Member Functions

Additional Inherited Members
