Base class for distributions that have a closed integral form for the cumulative density function (CDF) when the effective size exponent is zero, but not otherwise. More...

Inheritance diagram for unintegrableForNonZeroQ:

[legend]

Collaboration diagram for unintegrableForNonZeroQ:

[legend]

Public Member Functions
virtual scalar	sample () const
	Sample the distribution. More...

virtual scalar	sampleForZeroQ () const =0
	Sample the distribution. More...

virtual tmp< scalarField >	integralPDFxPow (const scalarField &x, const label e, const bool consistent=false) const
	Return the integral of the PDF multiplied by an integer power of x. More...

	unintegrable (const word &name, const unitConversion &units, const dictionary &dict, const label sampleQ, randomGenerator &&rndGen)
	Inherit constructors. More...

	unintegrable (const label Q, const label sampleQ, randomGenerator &&rndGen, const label n)
	Inherit constructors. More...

	unintegrable (const unintegrable &d, const label sampleQ)
	Inherit constructors. More...

Public Member Functions inherited from unintegrable
	unintegrable (const word &name, const unitConversion &units, const dictionary &dict, const label sampleQ, randomGenerator &&rndGen)
	Construct from a dictionary. More...

	unintegrable (const label Q, const label sampleQ, randomGenerator &&rndGen, const label n)
	Construct from components. More...

	unintegrable (const unintegrable &d, const label sampleQ)
	Construct copy. More...

virtual	~unintegrable ()
	Destructor. More...

virtual scalar	mean () const
	Return the mean value. More...

virtual void	write (Ostream &os, const unitConversion &units) const
	Write to a stream. More...

virtual tmp< scalarField >	plotPDF (const scalarField &x) const
	Return values to plot the probability density function. More...

virtual scalar	sample () const=0
	Sample the distribution. More...

template<class Type >
Type	sample () const
	Sample the distribution. More...

virtual tmp< scalarField >	sample (const label n) const=0
	Sample the distribution. More...

virtual tmp< scalarField >	plotX (const label n) const
	Return coordinates to plot across the range of the distribution. More...

Public Member Functions inherited from distribution
	TypeName ("distribution")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, distribution, dictionary,(const unitConversion &units, const dictionary &dict, const label sampleQ, randomGenerator &&rndGen),(units, dict, sampleQ, std::move(rndGen)))
	Declare runtime constructor selection table. More...

	distribution (const word &name, const unitConversion &units, const dictionary &dict, const label sampleQ, randomGenerator &&rndGen)
	Construct from dictionary. More...

	distribution (const label Q, const label sampleQ, randomGenerator &&rndGen)
	Construct from components. More...

	distribution (const distribution &d, const label sampleQ)
	Construct copy. More...

virtual autoPtr< distribution >	clone (const label sampleQ) const =0
	Construct and return a clone. More...

autoPtr< distribution >	clone () const
	Construct and return a clone. More...

virtual	~distribution ()
	Destructor. More...

label	sampleQ () const
	Access the sample size exponent. More...

void	start (const bool repeat) const
	Start a sequence of samples. Either a new sequence, or a. More...

template<class Type >
Type	sample () const
	Sample the distribution into components of a primitive type. More...

virtual tmp< scalarField >	sample (const label n) const =0
	Sample the distribution into a field. More...

virtual scalar	min () const =0
	Return the minimum value. More...

virtual scalar	max () const =0
	Return the maximum value. More...

virtual tmp< scalarField >	CDF (const scalarField &x) const
	Return the cumulative density function at the given coordinates. More...

virtual void	writeState (Ostream &os) const
	Write the state to a stream. More...

virtual tmp< scalarField >	plotX (const label n) const
	Return coordinates to plot across the range of the distribution. More...

Protected Member Functions
virtual tmp< scalarField >	Phi (const label q, const scalarField &x) const
	Return values of the un-normalised CDF for the given size exponent. More...

virtual tmp< scalarField >	PhiForZeroQ (const scalarField &x) const =0
	Return values of the un-normalised CDF for zero effective size. More...

virtual Pair< scalar >	Phi01 (const label q) const
	Return values of the un-normalised CDF at the minimum and maximum. More...

virtual Pair< scalar >	Phi01 (const label q) const
	Access cached values of the un-normalised CDF at the minimum and. More...

const Pair< scalar > &	Phi01 () const
	Access cached values of the un-normalised CDF at the minimum and. More...

Protected Member Functions inherited from unintegrable
virtual tmp< scalarField >	phi (const label q, const scalarField &x) const =0
	Return values of the un-normalised PDF for the given size exponent. More...

const Pair< scalar > &	Phi01 () const
	Access cached values of the un-normalised CDF at the minimum and. More...

Protected Member Functions inherited from distribution
virtual void	validateBounds (const dictionary &dict) const
	Validate that the bounds are monotonic. More...

virtual void	validatePositive (const dictionary &dict) const
	Validate that the lower bound is positive. More...

tmp< scalarField >	clipPDF (const scalarField &x, const tmp< scalarField > &pdf) const
	Clip the PDF values to zero outside the bounds. More...

label	q () const
	Return the effective distribution size exponent. More...

	FOR_ALL_FIELD_TYPES (VIRTUAL_SAMPLE_TYPE)

Additional Inherited Members
Static Public Member Functions inherited from unintegrable
static tmp< scalarField >	integrate (const scalarField &x, const scalarField &y)
	Integrate the values y with respect to the coordinates x. More...

static tmp< scalarField >	integrateX (const scalarField &x, const scalarField &y)
	Integrate the values x*y with respect to the coordinates x. More...

static tmp< scalarField >	interpolateIntegrateXPow (const scalarField &xStar, const label e, const scalarField &yStar, const scalarField &x)
	Integrate the values x^e*y with respect to the coordinates x,. More...

static scalar	sampleInterval (const Pair< scalar > &x, const Pair< scalar > &Phi, const scalar s)
	Sample an interval, given the interval's bounding x-coordinates,. More...

static scalar	sampleInterval (const Pair< scalar > &x, const Pair< scalar > &phi, const Pair< scalar > &Phi, const scalar s)
	Sample an interval, given the interval's bounding x-coordinates,. More...

static scalar	sample (const scalarField &x, const scalarField &Phi, const scalar s)
	Sample a discretised distribution, given the x-coordinates,. More...

static scalar	sample (const scalarField &x, const scalarField &phi, const scalarField &Phi, const scalar s)
	Sample a discretised distribution, given the x-coordinates, values. More...

Static Public Member Functions inherited from distribution
static autoPtr< distribution >	New (const unitConversion &units, const dictionary &dict, const label sampleQ, randomGenerator &&rndGen, const bool report=true)
	Select from dictionary and a random generator. More...

static autoPtr< distribution >	New (const unitConversion &units, const dictionary &dict, const label sampleQ, const randomGenerator::seed &s, const bool global=false, const bool report=true)
	Select from a dictionary and a random generator seed and global flag. More...

static autoPtr< distribution >	New (autoPtr< distribution > &dPtr, const label sampleQ)
	Re-select with a different sample size exponent. More...

Protected Attributes inherited from distribution
const label	Q_
	Distribution size exponent. More...

const label	sampleQ_
	Sample size exponent. More...

restartableRandomGenerator	rndGen_
	Random number generator. More...

Detailed Description

Base class for distributions that have a closed integral form for the cumulative density function (CDF) when the effective size exponent is zero, but not otherwise.

Source files
