Distribution in which the probability density function is given as a table of values. More...

Inheritance diagram for tabulatedDensity:

Collaboration diagram for tabulatedDensity:

Public Member Functions
	TypeName ("tabulatedDensity")
	Runtime type information. More...

	tabulatedDensity (const unitConversion &units, const dictionary &dict, const label sampleQ, randomGenerator &&rndGen)
	Construct from a dictionary. More...

	tabulatedDensity (const tabulatedDensity &d, const label sampleQ)
	Construct copy. More...

virtual autoPtr< distribution >	clone (const label sampleQ) const
	Construct and return a clone. More...

virtual	~tabulatedDensity ()
	Destructor. More...

virtual scalar	sample () const
	Sample the distribution. More...

virtual scalar	min () const
	Return the minimum value. More...

virtual scalar	max () const
	Return the maximum value. More...

virtual scalar	mean () const
	Return the mean value. More...

virtual tmp< scalarField >	integralPDFxPow (const scalarField &x, const label e, const bool consistent=false) const
	Return the integral of the PDF multiplied by an integer power of x. More...

virtual void	write (Ostream &os, const unitConversion &units) const
	Write to a stream. More...

virtual tmp< scalarField >	plotX (const label n) const
	Return coordinates to plot across the range of the distribution. More...

virtual tmp< scalarField >	plotPDF (const scalarField &x) const
	Return values to plot the probability density function. More...

Public Member Functions inherited from FieldDistribution< distribution, tabulatedDensity >
Type	sample () const
	Sample the distribution into components of a primitive type. More...

virtual tmp< scalarField >	sample (const label n) const
	Sample the distribution into a field. More...

Public Member Functions inherited from distribution
	TypeName ("distribution")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, distribution, dictionary,(const unitConversion &units, const dictionary &dict, const label sampleQ, randomGenerator &&rndGen),(units, dict, sampleQ, std::move(rndGen)))
	Declare runtime constructor selection table. More...

	distribution (const word &name, const unitConversion &units, const dictionary &dict, const label sampleQ, randomGenerator &&rndGen)
	Construct from dictionary. More...

	distribution (const label Q, const label sampleQ, randomGenerator &&rndGen)
	Construct from components. More...

	distribution (const distribution &d, const label sampleQ)
	Construct copy. More...

autoPtr< distribution >	clone () const
	Construct and return a clone. More...

virtual	~distribution ()
	Destructor. More...

label	sampleQ () const
	Access the sample size exponent. More...

void	start (const bool repeat) const
	Start a sequence of samples. Either a new sequence, or a. More...

template<class Type >
Type	sample () const
	Sample the distribution into components of a primitive type. More...

virtual tmp< scalarField >	CDF (const scalarField &x) const
	Return the cumulative density function at the given coordinates. More...

virtual void	writeState (Ostream &os) const
	Write the state to a stream. More...

Additional Inherited Members
Static Public Member Functions inherited from distribution
static autoPtr< distribution >	New (const unitConversion &units, const dictionary &dict, const label sampleQ, randomGenerator &&rndGen, const bool report=true)
	Select from dictionary and a random generator. More...

static autoPtr< distribution >	New (const unitConversion &units, const dictionary &dict, const label sampleQ, const randomGenerator::seed &s, const bool global=false, const bool report=true)
	Select from a dictionary and a random generator seed and global flag. More...

static autoPtr< distribution >	New (autoPtr< distribution > &dPtr, const label sampleQ)
	Re-select with a different sample size exponent. More...

Protected Member Functions inherited from FieldDistribution< distribution, tabulatedDensity >
	FOR_ALL_FIELD_TYPES (VIRTUAL_SAMPLE_TYPE)

Protected Member Functions inherited from distribution
virtual void	validateBounds (const dictionary &dict) const
	Validate that the bounds are monotonic. More...

virtual void	validatePositive (const dictionary &dict) const
	Validate that the lower bound is positive. More...

tmp< scalarField >	clipPDF (const scalarField &x, const tmp< scalarField > &pdf) const
	Clip the PDF values to zero outside the bounds. More...

label	q () const
	Return the effective distribution size exponent. More...

	FOR_ALL_FIELD_TYPES (VIRTUAL_SAMPLE_TYPE)

Protected Attributes inherited from distribution
const label	Q_
	Distribution size exponent. More...

const label	sampleQ_
	Sample size exponent. More...

restartableRandomGenerator	rndGen_
	Random number generator. More...

Detailed Description

Distribution in which the probability density function is given as a table of values.

Usage

Example usage:

{
    type    tabulatedDensity;
    Q       0;
    distribution
    (
        (10e-6 0.0025)
        (12e-6 0.2795)
        (15e-6 2.3988)
        (19e-6 6.3888)
        (25e-6 10.3153)
        (31e-6 12.0030)
        (39e-6 10.8427)
        (50e-6 6.1333)
        (63e-6 3.4688)
    );

}
