Boundary condition for size-group fractions that sets values corresponding to a given distribution. More...

Inheritance diagram for distributionSizeGroupFvPatchScalarField:

Collaboration diagram for distributionSizeGroupFvPatchScalarField:

Public Member Functions
	TypeName ("distributionSizeGroup")
	Runtime type information. More...

	distributionSizeGroupFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	distributionSizeGroupFvPatchScalarField (const distributionSizeGroupFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping given fixedValueTypeFvPatchField. More...

	distributionSizeGroupFvPatchScalarField (const distributionSizeGroupFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	distributionSizeGroupFvPatchScalarField (const distributionSizeGroupFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	write (Ostream &) const
	Write. More...

Detailed Description

Boundary condition for size-group fractions that sets values corresponding to a given distribution.

Usage

Example of the boundary condition specification:

<patchName>
{
    type        distributionSizeGroup;
    distribution
    {
        type        RosinRammler;
        Q           0;
        min         1 [mm];
        max         15 [mm];
        d           14 [mm];
        n           2 [];
    }
    value       $internalField;
}

Source files

Definition at line 69 of file distributionSizeGroupFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ distributionSizeGroupFvPatchScalarField() [1/4]

distributionSizeGroupFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 32 of file distributionSizeGroupFvPatchScalarField.C.

◆ distributionSizeGroupFvPatchScalarField() [2/4]

distributionSizeGroupFvPatchScalarField	(	const distributionSizeGroupFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping given fixedValueTypeFvPatchField.

onto a new patch

Definition at line 49 of file distributionSizeGroupFvPatchScalarField.C.

◆ distributionSizeGroupFvPatchScalarField() [3/4]

distributionSizeGroupFvPatchScalarField ( const distributionSizeGroupFvPatchScalarField & )

delete

Disallow copy without setting internal field reference.

◆ distributionSizeGroupFvPatchScalarField() [4/4]

distributionSizeGroupFvPatchScalarField	(	const distributionSizeGroupFvPatchScalarField &	ptf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 64 of file distributionSizeGroupFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "distributionSizeGroup" )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 122 of file distributionSizeGroupFvPatchScalarField.H.

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

Definition at line 79 of file distributionSizeGroupFvPatchScalarField.C.

References populationBalanceModel::etaV(), sizeGroup::group(), sizeGroup::i(), Foam::operator==(), and velocityGroup::popBal().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const
