A topoSetSource to select the cells from another cellSet. More...

Inheritance diagram for cellToCell:

Collaboration diagram for cellToCell:

Public Member Functions
	TypeName ("cellToCell")
	Runtime type information. More...

	cellToCell (const polyMesh &mesh, const word &setName)
	Construct from components. More...

	cellToCell (const polyMesh &mesh, const dictionary &dict)
	Construct from dictionary. More...

virtual	~cellToCell ()
	Destructor. More...

virtual sourceType	setType () const

virtual void	applyToSet (const topoSetSource::setAction action, topoSet &) const

Public Member Functions inherited from topoSetSource
	TypeName ("topoSetSource")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, topoSetSource, word,(const polyMesh &mesh, const dictionary &dict),(mesh, dict))

	topoSetSource (const polyMesh &mesh)
	Construct from components. More...

	topoSetSource (const topoSetSource &)=delete
	Disallow default bitwise copy construction. More...

autoPtr< topoSetSource >	clone () const
	Clone. More...

virtual	~topoSetSource ()
	Destructor. More...

const polyMesh &	mesh () const

void	operator= (const topoSetSource &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Public Types inherited from topoSetSource
enum	sourceType { CELLSETSOURCE , FACESETSOURCE , POINTSETSOURCE , CELLZONESOURCE , FACEZONESOURCE , POINTZONESOURCE }
	Enumeration defining the types of sources. More...

enum	setAction { CLEAR , NEW , INVERT , ADD , DELETE , SUBSET , LIST , REMOVE }
	Enumeration defining the valid actions. More...

Static Public Member Functions inherited from topoSetSource
static setAction	toAction (const word &actionName)
	Convert string to action. More...

static autoPtr< topoSetSource >	New (const word &topoSetSourceType, const polyMesh &mesh, const dictionary &dict)
	Return a reference to the selected topoSetSource. More...

Protected Member Functions inherited from topoSetSource
void	addOrDelete (topoSet &set, const label celli, const bool) const
	Add (if bool) celli to set or delete celli from set. More...

Protected Attributes inherited from topoSetSource
const polyMesh &	mesh_

Detailed Description

A topoSetSource to select the cells from another cellSet.

Source files

Definition at line 48 of file cellToCell.H.

Constructor & Destructor Documentation

◆ cellToCell() [1/2]

cellToCell	(	const polyMesh &	mesh,
		const word &	setName
	)

Construct from components.

Definition at line 41 of file cellToCell.C.

◆ cellToCell() [2/2]

cellToCell	(	const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from dictionary.

Definition at line 52 of file cellToCell.C.

◆ ~cellToCell()

~cellToCell ( )

virtual

Destructor.

Definition at line 65 of file cellToCell.C.

Member Function Documentation

◆ TypeName()

TypeName ( "cellToCell" )

Runtime type information.

◆ setType()

virtual sourceType setType ( ) const

inlinevirtual

Implements topoSetSource.

Definition at line 87 of file cellToCell.H.

References topoSetSource::CELLSETSOURCE.

◆ applyToSet()

void applyToSet	(	const topoSetSource::setAction	action,
		topoSet &	set
	)		const

virtual

Implements topoSetSource.

Definition at line 71 of file cellToCell.C.

References topoSetSource::ADD, topoSet::addSet(), topoSetSource::DELETE, topoSet::deleteSet(), Foam::endl(), Foam::Info, and topoSetSource::NEW.

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/topoSetSources/cellSources/cellToCell/cellToCell.H
src/topoSetSources/cellSources/cellToCell/cellToCell.C
