Basic sub-grid obstacle flame-wrinkling enhancement factor model. Details supplied by J Puttock 2/7/06. More...

Inheritance diagram for basicSubGrid:

Collaboration diagram for basicSubGrid:

Public Member Functions
	TypeName ("basicSubGrid")
	Runtime type information. More...

	basicSubGrid (const dictionary &XiEqProperties, const psiuMulticomponentThermo &thermo, const compressible::RASModel &turbulence, const volScalarField &Su)
	Construct from components. More...

	basicSubGrid (const basicSubGrid &)=delete
	Disallow default bitwise copy construction. More...

virtual	~basicSubGrid ()
	Destructor. More...

virtual tmp< volScalarField >	XiEq () const
	Return the flame-wrinkling XiEq. More...

virtual bool	read (const dictionary &XiEqProperties)
	Update properties from given dictionary. More...

void	operator= (const basicSubGrid &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from XiEqModel
	TypeName ("XiEqModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, XiEqModel, dictionary,(const dictionary &dict, const psiuMulticomponentThermo &thermo, const fluidThermoThermophysicalTransportModel &turbulence, const volScalarField &Su),(dict, thermo, turbulence, Su))

	XiEqModel (const psiuMulticomponentThermo &thermo, const fluidThermoThermophysicalTransportModel &turbulence, const volScalarField &Su)
	Construct from components. More...

	XiEqModel (const XiEqModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~XiEqModel ()
	Destructor. More...

virtual tmp< volScalarField >	Db () const
	Return the flame diffusivity. More...

bool	read (const dictionary &XiProperties)
	Update properties from the given XiProperties dictionary. More...

void	operator= (const XiEqModel &)=delete
	Disallow default bitwise assignment. More...

	TypeName ("XiEqModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, XiEqModel, dictionary,(const dictionary &XiEqProperties, const psiuMulticomponentThermo &thermo, const compressible::RASModel &turbulence, const volScalarField &Su),(XiEqProperties, thermo, turbulence, Su))

	XiEqModel (const dictionary &XiEqProperties, const psiuMulticomponentThermo &thermo, const compressible::RASModel &turbulence, const volScalarField &Su)
	Construct from components. More...

	XiEqModel (const XiEqModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~XiEqModel ()
	Destructor. More...

tmp< volScalarField >	calculateSchelkinEffect (const scalar) const
	Return the sub-grid Schelkin effect. More...

void	writeFields () const
	Write fields. More...

void	operator= (const XiEqModel &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from XiEqModel
static autoPtr< XiEqModel >	New (const dictionary &XiProperties, const psiuMulticomponentThermo &thermo, const fluidThermoThermophysicalTransportModel &turbulence, const volScalarField &Su)
	Return a reference to the selected XiEq model. More...

static autoPtr< XiEqModel >	New (const dictionary &XiEqProperties, const psiuMulticomponentThermo &thermo, const compressible::RASModel &turbulence, const volScalarField &Su)
	Return a reference to the selected XiEq model. More...

Protected Member Functions inherited from XiEqModel
virtual bool	readCoeffs (const dictionary &dict)=0
	Update coefficients from given dictionary. More...

Protected Attributes inherited from XiEqModel
const psiuMulticomponentThermo &	thermo_
	Thermo. More...

const fluidThermoThermophysicalTransportModel &	thermoTransport_
	Thermo-physical transport. More...

const compressibleMomentumTransportModel &	turbulence_
	Turbulence. More...

const volScalarField &	Su_
	Laminar burning velocity. More...

dictionary	XiEqModelCoeffs_
	Dictionary. More...

const compressible::RASModel &	turbulence_
	Turbulence. More...

Detailed Description

Basic sub-grid obstacle flame-wrinkling enhancement factor model. Details supplied by J Puttock 2/7/06.

Sub-grid flame area generation

$n = N - \hat{\dwea{\vec{U}}}.n_{s}.\hat{\dwea{\vec{U}}}$ $n_{r} = \sqrt{n}$

where:

$\hat{\dwea{\vec{U}}} = \dwea{\vec{U}} / \vert \dwea{\vec{U}} \vert$

$b = \hat{\dwea{\vec{U}}}.B.\hat{\dwea{\vec{U}}} / n_{r}$

where:

is the file "B".

is the file "N".

$n_{s}$ is the file "ns".

The flame area enhancement factor $\Xi_{sub}$ is expected to approach:

$\Xi_{{sub}_{eq}} = 1 + max(2.2 \sqrt{b}, min(0.34 \frac{\vert \dwea{\vec{U}} \vert}{{\vec{U}}^{'}}, 1.6)) \times min(\frac{n}{4}, 1)$

Source files

Definition at line 81 of file basicXiSubXiEq.H.

Constructor & Destructor Documentation

◆ basicSubGrid() [1/2]

basicSubGrid	(	const dictionary &	XiEqProperties,
		const psiuMulticomponentThermo &	thermo,
		const compressible::RASModel &	turbulence,
		const volScalarField &	Su
	)

Construct from components.

Definition at line 43 of file basicXiSubXiEq.C.

◆ basicSubGrid() [2/2]

basicSubGrid ( const basicSubGrid & )

delete

Disallow default bitwise copy construction.

◆ ~basicSubGrid()

~basicSubGrid ( )

virtual

Destructor.

Definition at line 72 of file basicXiSubXiEq.C.

Member Function Documentation

◆ TypeName()

TypeName ( "basicSubGrid" )

Runtime type information.

◆ XiEq()

Foam::tmp< Foam::volScalarField > XiEq ( ) const

virtual

Return the flame-wrinkling XiEq.

Implements XiEqModel.

Definition at line 78 of file basicXiSubXiEq.C.

References b, TimePaths::constant(), Foam::e, objectRegistry::lookupObject(), Foam::mag(), Foam::max(), fvMesh::mesh(), mesh, Foam::min(), n, IOobject::NO_READ, IOobject::NO_WRITE, Foam::pow(), GeometricField< Type, GeoMesh, PrimitiveField >::primitiveFieldRef(), Foam::sqrt(), fvMesh::time(), U, fvMesh::V(), and Foam::Zero.

Here is the call graph for this function:

◆ read()

bool read ( const dictionary & XiEqProperties )

virtual

Update properties from given dictionary.

Implements XiEqModel.

Definition at line 145 of file basicXiSubXiEq.C.

References XiEqModel::read().

Here is the call graph for this function:

◆ operator=()

void operator= ( const basicSubGrid & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

applications/legacy/combustion/PDRFoam/PDRModels/XiEqModels/basicXiSubXiEq/basicXiSubXiEq.H
applications/legacy/combustion/PDRFoam/PDRModels/XiEqModels/basicXiSubXiEq/basicXiSubXiEq.C
