Reads an interpolation table from a file in OpenFOAM-format. This is a list of Tuples in which complex types are delimited by parentheses. By default, a Tuple2 is assumed in which the first column is the (scalar) x-axis and the second column is the y-axis. But finer control over a n-component Tuple can be achieved by specifying the column indices. More...

Inheritance diagram for Foam< Type >:

[legend]

Collaboration diagram for Foam< Type >:

[legend]

Public Member Functions
	TypeName ("foam")
	Runtime type information. More...

	Foam (const word &name, const Function1s::unitConversions &units, const dictionary &dict)
	Construct from name and dictionary. More...

virtual autoPtr< TableReader< Type > >	clone () const
	Construct and return a copy. More...

virtual	~Foam ()
	Destructor. More...

virtual void	write (Ostream &os, const Function1s::unitConversions &units, const List< Tuple2< scalar, Type >> &table, const word &valuesKeyword=word::null) const
	Write settings and values. More...

Public Member Functions inherited from TableFileReader< Type >
	TableFileReader (const Function1s::unitConversions &defaultUnits, const dictionary &dict)
	Construct from dictionary. More...

	TableFileReader (const TableFileReader< Type > &)
	Copy construct. More...

virtual	~TableFileReader ()
	Destructor. More...

virtual List< Tuple2< scalar, Type > >	read (const Function1s::unitConversions &units, const dictionary &dict, const word &valuesKeyword=word::null) const
	Read values. More...

Public Member Functions inherited from TableReader< Type >
	TypeName ("TableReader")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, TableReader, dictionary,(const word &name, const Function1s::unitConversions &units, const dictionary &dict),(name, units, dict))

	TableReader ()
	Default construct. More...

virtual	~TableReader ()
	Destructor. More...

Additional Inherited Members
Static Public Member Functions inherited from TableReader< Type >
static autoPtr< TableReader< Type > >	New (const word &name, const Function1s::unitConversions &units, const dictionary &dict)

Protected Member Functions inherited from TableFileReader< Type >
void	read (const Function1s::unitConversions &defaultUnits, const dictionary &dict, List< Tuple2< scalar, Type >> &) const
	Read a 1D table. More...

Protected Member Functions inherited from TableReader< Type >
void	convertRead (const Function1s::unitConversions &units, List< Tuple2< scalar, Type >> &table) const
	Do unit conversions on input data. More...

List< Tuple2< scalar, Type > >	convertRead (const Function1s::unitConversions &units, const List< Tuple2< scalar, Type >> &table) const
	Do unit conversions on input data. More...

List< Tuple2< scalar, Type > >	convertWrite (const Function1s::unitConversions &units, const List< Tuple2< scalar, Type >> &table) const
	Do unit conversions in order to output data. More...

Detailed Description

template<class Type>
class Foam::TableReaders::Foam< Type >

Reads an interpolation table from a file in OpenFOAM-format. This is a list of Tuples in which complex types are delimited by parentheses. By default, a Tuple2 is assumed in which the first column is the (scalar) x-axis and the second column is the y-axis. But finer control over a n-component Tuple can be achieved by specifying the column indices.

Usage

A file containing the following will be read with the first element in each tuple as the x-coordinate and the second as the y-values:

    (
        (0.0 (1 2 3))
        (1.0 (4 5 6))
    )

A more complex table file might look as follows:

    (
        (0 (1 2 3) 4 (5 6 7 8 9 10))
        (1 (2 3 4) 5 (6 7 8 9 10 11))
        (2 (3 4 5) 6 (7 8 9 10 11 12))
    )

In this case, the columns to be used can be specified using the columns entry. In this example, the second scalar column is taken as the x-axis, and the six-component symmTensor-s are used as the values:

    columns     (2 3);

Source files

Definition at line 82 of file FoamTableReader.H.

Constructor & Destructor Documentation

◆ Foam()

Foam	(	const word &	name,
		const Function1s::unitConversions &	units,
		const dictionary &	dict
	)

Construct from name and dictionary.

Definition at line 53 of file FoamTableReader.C.

◆ ~Foam()

~Foam

virtual

Destructor.

Definition at line 68 of file FoamTableReader.C.

Member Function Documentation

◆ TypeName()

TypeName ( "foam" )

Runtime type information.

◆ clone()

virtual autoPtr<TableReader<Type> > clone ( ) const

inlinevirtual

Construct and return a copy.

Implements TableReader< Type >.

Definition at line 115 of file FoamTableReader.H.

◆ write()

void write	(	Ostream &	os,
		const Function1s::unitConversions &	units,
		const List< Tuple2< scalar, Type >> &	table,
		const word &	valuesKeyword = `word::null`
	)		const

virtual

Write settings and values.

Reimplemented from TableFileReader< Type >.

Definition at line 75 of file FoamTableReader.C.

References Foam::units(), TableFileReader< Type >::write(), and Foam::writeEntry().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/OpenFOAM/primitives/functions/Function1/Table/TableReader/Foam/FoamTableReader.H
src/OpenFOAM/primitives/functions/Function1/Table/TableReader/Foam/FoamTableReader.C
