Public Member Functions | Static Public Member Functions | Friends | List of all members
rigidBody Class Reference
Inheritance diagram for rigidBody:
Inheritance graph
[legend]
Collaboration diagram for rigidBody:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("rigidBody")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, rigidBody, dictionary,(const word &name, const dictionary &dict),(name, dict))

 rigidBody (const word &name, const scalar &m, const vector &c, const symmTensor &Ic)
 Construct from mass, centre of mass and moment of inertia tensor. More...

 rigidBody (const word &name, const rigidBodyInertia &rbi)
 Construct from with the given rigidBodyInertia. More...

 rigidBody (const word &name, const dictionary &dict)
 Construct from dictionary. More...

virtual autoPtr< rigidBody > clone () const
 Return clone of this rigidBody. More...

virtual ~rigidBody ()
 Destructor. More...

const word & name () const
 Return name. More...

virtual bool massless () const
 Return false as this body is not massless. More...

void merge (const subBody &)
 Merge a body into this parent body. More...

virtual void write (Ostream &) const
 Write. More...

- Public Member Functions inherited from rigidBodyInertia
 rigidBodyInertia ()
 Null constructor, initialises to zero. More...

 rigidBodyInertia (const scalar m, const vector &c, const symmTensor &Ic)
 Construct from mass, centre of mass and moment of inertia tensor. More...

 rigidBodyInertia (const dictionary &dict)
 Construct from dictionary. More...

 rigidBodyInertia (const spatialTensor &st)
 Construct from the components of a spatial tensor. More...

 rigidBodyInertia (Istream &is)
 Construct from Istream. More...

scalar m () const
 Return the mass of the rigid-body. More...

const vector & c () const
 Return the centre of mass of the rigid-body. More...

const symmTensor & Ic () const
 Return the inertia tensor of the rigid-body about the centre of mass. More...

symmTensor Ioc () const
 Return the difference between the inertia tensor of the rigid-body. More...

symmTensor Icc (const vector &c) const
 Return the difference between the inertia tensor of the rigid-body. More...

symmTensor Io () const
 Return the inertia tensor of the rigid-body about the origin. More...

scalar kineticEnergy (const spatialVector &v)
 Return the kinetic energy of the body with the given velocity. More...

 operator spatialTensor () const
 Conversion to spatial tensor. More...

void operator+= (const rigidBodyInertia &)


Static Public Member Functions

static autoPtr< rigidBody > New (const word &name, const scalar &m, const vector &c, const symmTensor &Ic)
 Select constructed from components. More...

static autoPtr< rigidBody > New (const word &name, const dictionary &dict)
 Select constructed from name and dictionary. More...

- Static Public Member Functions inherited from rigidBodyInertia
static symmTensor Ioc (const scalar m, const vector &c)
 Return the difference between the inertia tensor of the rigid-body. More...


Friends

Ostream & operator<< (Ostream &, const rigidBody &)


Detailed Description

Source files

Definition at line 60 of file rigidBody.H.

Constructor & Destructor Documentation

◆ rigidBody() [1/3]

rigidBody ( const word &  name,
const scalar &  m,
const vector &  c,
const symmTensor &  Ic
)
inline

Construct from mass, centre of mass and moment of inertia tensor.

about the centre of mass

Definition at line 28 of file rigidBodyI.H.

Referenced by rigidBody::clone().

Here is the caller graph for this function:

◆ rigidBody() [2/3]

rigidBody ( const word &  name,
const rigidBodyInertia &  rbi
)
inline

Construct from with the given rigidBodyInertia.

Definition at line 41 of file rigidBodyI.H.

◆ rigidBody() [3/3]

rigidBody ( const word &  name,
const dictionary &  dict
)
inline

Construct from dictionary.

Definition at line 52 of file rigidBodyI.H.

◆ ~rigidBody()

~rigidBody ( )
virtual

Destructor.

Definition at line 98 of file rigidBody.C.

Member Function Documentation

◆ TypeName()

TypeName ( "rigidBody"  )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable ( autoPtr  ,
rigidBody  ,
dictionary  ,
(const word &name, const dictionary &dict)  ,
(name, dict)
)

◆ clone()

Foam::autoPtr< Foam::RBD::rigidBody > clone ( ) const
virtual

Return clone of this rigidBody.

Reimplemented in sphere, masslessBody, jointBody, cuboid, and compositeBody.

Definition at line 51 of file rigidBody.C.

References rigidBody::rigidBody().

Here is the call graph for this function:

◆ New() [1/2]

Foam::autoPtr< Foam::RBD::rigidBody > New ( const word &  name,
const scalar &  m,
const vector &  c,
const symmTensor &  Ic
)
static

Select constructed from components.

Definition at line 59 of file rigidBody.C.

References Foam::constant::universal::c, and Foam::name().

Referenced by rigidBodyModel::rigidBodyModel().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ New() [2/2]

Foam::autoPtr< Foam::RBD::rigidBody > New ( const word &  name,
const dictionary &  dict
)
static

Select constructed from name and dictionary.

Definition at line 71 of file rigidBody.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::name(), and Foam::nl.

Here is the call graph for this function:

◆ name()

const Foam::word & name ( ) const
inline

Return name.

Definition at line 65 of file rigidBodyI.H.

Referenced by rigidBodyModel::join_().

Here is the caller graph for this function:

◆ massless()

bool massless ( ) const
virtual

Return false as this body is not massless.

Reimplemented in masslessBody.

Definition at line 104 of file rigidBody.C.

◆ merge()

void merge ( const subBody &  subBody)

Merge a body into this parent body.

Definition at line 110 of file rigidBody.C.

References subBody::body(), subBody::masterXT(), Foam::name(), and Foam::RBD::transform().

Here is the call graph for this function:

◆ write()

void write ( Ostream &  os) const
virtual

Write.

Reimplemented in sphere, masslessBody, cuboid, and compositeBody.

Definition at line 120 of file rigidBody.C.

References Foam::constant::universal::c, Foam::type(), and Foam::writeEntry().

Referenced by Foam::RBD::operator<<().

Here is the call graph for this function:
Here is the caller graph for this function:

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<< ( Ostream &  ,
const rigidBody &
)
friend
The documentation for this class was generated from the following files:
