k-epsilon model for the gas-phase in a two-phase system supporting phase-inversion. More...

Inheritance diagram for continuousGasKEpsilon< BasicMomentumTransportModel >:

Collaboration diagram for continuousGasKEpsilon< BasicMomentumTransportModel >:

Public Types
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from kEpsilon< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from eddyViscosity< RASModel< BasicMomentumTransportModel > >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from linearViscousStress< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Member Functions
	TypeName ("continuousGasKEpsilon")
	Runtime type information. More...

	continuousGasKEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

	continuousGasKEpsilon (const continuousGasKEpsilon &)=delete
	Disallow default bitwise copy construction. More...

virtual	~continuousGasKEpsilon ()
	Destructor. More...

virtual bool	read ()
	Re-read model coefficients if they have changed. More...

const momentumTransportModel &	liquidTurbulence () const
	Return the turbulence model for the liquid phase. More...

virtual tmp< volScalarField >	nuEff () const
	Return the effective viscosity. More...

virtual tmp< volScalarField >	rhoEff () const
	Return the effective density for the stress. More...

virtual tmp< volSymmTensorField >	R () const
	Return the Reynolds stress tensor [m^2/s^2]. More...

void	operator= (const continuousGasKEpsilon &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from kEpsilon< BasicMomentumTransportModel >
	TypeName ("kEpsilon")
	Runtime type information. More...

	kEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

	kEpsilon (const kEpsilon &)=delete
	Disallow default bitwise copy construction. More...

virtual	~kEpsilon ()
	Destructor. More...

tmp< volScalarField >	DkEff () const
	Return the effective diffusivity for k. More...

tmp< volScalarField >	DepsilonEff () const
	Return the effective diffusivity for epsilon. More...

virtual tmp< volScalarField >	k () const
	Return the turbulence kinetic energy. More...

virtual tmp< volScalarField >	epsilon () const
	Return the turbulence kinetic energy dissipation rate. More...

virtual tmp< volScalarField >	omega () const
	Return the turbulence specific dissipation rate. More...

virtual void	correct ()
	Solve the turbulence equations and correct the turbulence viscosity. More...

void	operator= (const kEpsilon &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from eddyViscosity< RASModel< BasicMomentumTransportModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~eddyViscosity ()
	Destructor. More...

virtual tmp< volScalarField >	nut () const
	Return the turbulence viscosity. More...

virtual tmp< scalarField >	nut (const label patchi) const
	Return the turbulence viscosity on patch. More...

virtual void	validate ()
	Validate the turbulence fields after construction. More...

Public Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~linearViscousStress ()
	Destructor. More...

virtual tmp< surfaceVectorField >	devTau () const
	Return the effective surface stress. More...

virtual tmp< fvVectorMatrix >	divDevTau (volVectorField &U) const
	Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrix >	divDevTau (const volScalarField &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

template<class RhoFieldType >
Foam::tmp< Foam::fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const

Protected Member Functions
virtual void	correctNut ()
	Correct the eddy-viscosity nut. More...

tmp< volScalarField >	phaseTransferCoeff () const

virtual tmp< fvScalarMatrix >	kSource () const
	Source term for the k equation. More...

virtual tmp< fvScalarMatrix >	epsilonSource () const
	Source term for the epsilon equation. More...

Protected Member Functions inherited from kEpsilon< BasicMomentumTransportModel >
tmp< volScalarField >	boundEpsilon ()
	Bound epsilon and return Cmu*sqr(k) for nut. More...

Protected Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
template<class RhoFieldType >
tmp< fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

Protected Attributes
dimensionedScalar	alphaInversion_

Protected Attributes inherited from kEpsilon< BasicMomentumTransportModel >
dimensionedScalar	Cmu_

dimensionedScalar	C1_

dimensionedScalar	C2_

dimensionedScalar	C3_

dimensionedScalar	sigmak_

dimensionedScalar	sigmaEps_

volScalarField	k_

volScalarField	epsilon_

Protected Attributes inherited from eddyViscosity< RASModel< BasicMomentumTransportModel > >
volScalarField	nut_

Detailed Description

template<class BasicMomentumTransportModel>
class Foam::RASModels::continuousGasKEpsilon< BasicMomentumTransportModel >

k-epsilon model for the gas-phase in a two-phase system supporting phase-inversion.

In the limit that the gas-phase fraction approaches zero a contribution from the other phase is blended into the k and epsilon equations up to the phase-fraction of alphaInversion at which point phase-inversion is considered to have occurred and the model reverts to the pure single-phase form.

This model is unpublished and is provided as a stable numerical framework on which a more physical model may be built.

The default model coefficients are

    continuousGasKEpsilonCoeffs
    {
        Cmu             0.09;
        C1              1.44;
        C2              1.92;
        C3              0;
        sigmak          1.0;
        sigmaEps        1.3;
        alphaInversion  0.7;
    }

Source files

Definition at line 75 of file continuousGasKEpsilon.H.

Member Typedef Documentation

◆ alphaField

typedef BasicMomentumTransportModel::alphaField alphaField

Definition at line 105 of file continuousGasKEpsilon.H.

◆ rhoField

typedef BasicMomentumTransportModel::rhoField rhoField

Definition at line 106 of file continuousGasKEpsilon.H.

Constructor & Destructor Documentation

◆ continuousGasKEpsilon() [1/2]

continuousGasKEpsilon	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity,
		const word &	type = `typeName`
	)

Construct from components.

Definition at line 43 of file continuousGasKEpsilon.C.

◆ continuousGasKEpsilon() [2/2]

continuousGasKEpsilon ( const continuousGasKEpsilon< BasicMomentumTransportModel > & )

delete

Disallow default bitwise copy construction.

◆ ~continuousGasKEpsilon()

virtual ~continuousGasKEpsilon ( )

inlinevirtual

Destructor.

Definition at line 132 of file continuousGasKEpsilon.H.

Member Function Documentation

◆ correctNut()

void correctNut

protectedvirtual

Correct the eddy-viscosity nut.

Reimplemented from kEpsilon< BasicMomentumTransportModel >.

Definition at line 103 of file continuousGasKEpsilon.C.

References kEpsilon< BasicMomentumTransportModel >::correctNut(), dispersedVirtualMassModel::Cvm(), phaseModel::d(), momentumTransportModel::epsilon(), Foam::exp(), phaseModel::fluid(), momentumTransportModel::k(), phaseSystem::lookupInterfacialModel(), Foam::min(), dictionary::New(), momentumTransportModel::nut(), omega, phaseSystem::otherPhase(), phaseModel::rho(), liquid::rho(), and Foam::sqr().

Here is the call graph for this function:

◆ phaseTransferCoeff()

tmp< volScalarField > phaseTransferCoeff

protected

Definition at line 209 of file continuousGasKEpsilon.C.

References alpha(), momentumTransportModel::epsilon(), momentumTransportModel::k(), Foam::max(), Foam::min(), rho, and U.

Here is the call graph for this function:

◆ kSource()

tmp< fvScalarMatrix > kSource

protectedvirtual

Source term for the k equation.

Reimplemented from kEpsilon< BasicMomentumTransportModel >.

Definition at line 232 of file continuousGasKEpsilon.C.

References momentumTransportModel::k(), and Foam::fvm::Sp().

Here is the call graph for this function:

◆ epsilonSource()

tmp< fvScalarMatrix > epsilonSource

protectedvirtual

Source term for the epsilon equation.

Reimplemented from kEpsilon< BasicMomentumTransportModel >.

Definition at line 245 of file continuousGasKEpsilon.C.

References momentumTransportModel::epsilon(), and Foam::fvm::Sp().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "continuousGasKEpsilon< BasicMomentumTransportModel >" )

Runtime type information.

◆ read()

bool read

virtual

Re-read model coefficients if they have changed.

Reimplemented from kEpsilon< BasicMomentumTransportModel >.

Definition at line 87 of file continuousGasKEpsilon.C.

◆ liquidTurbulence()

const momentumTransportModel & liquidTurbulence

Return the turbulence model for the liquid phase.

Definition at line 141 of file continuousGasKEpsilon.C.

References phaseModel::fluid(), liquidProperties::name(), phaseSystem::otherPhase(), and U.

Here is the call graph for this function:

◆ nuEff()

tmp< Foam::volScalarField > nuEff

virtual

Return the effective viscosity.

Definition at line 161 of file continuousGasKEpsilon.C.

References Foam::max(), Foam::min(), and GeometricField< Type, GeoMesh, PrimitiveField >::New().

Here is the call graph for this function:

◆ rhoEff()

tmp< Foam::volScalarField > rhoEff

virtual

Return the effective density for the stress.

Definition at line 188 of file continuousGasKEpsilon.C.

References dispersedVirtualMassModel::Cvm(), phaseModel::fluid(), phaseSystem::lookupInterfacialModel(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), phaseSystem::otherPhase(), phaseModel::rho(), and liquid::rho().

Here is the call graph for this function:

◆ R()

tmp< volSymmTensorField > R

virtual

Return the Reynolds stress tensor [m^2/s^2].

Reimplemented from eddyViscosity< RASModel< BasicMomentumTransportModel > >.

Definition at line 258 of file continuousGasKEpsilon.C.

References Foam::dev(), Foam::fvc::grad(), Foam::I, k, GeometricField< Type, GeoMesh, PrimitiveField >::New(), and Foam::twoSymm().

Here is the call graph for this function:

◆ operator=()

void operator= ( const continuousGasKEpsilon< BasicMomentumTransportModel > & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ alphaInversion_

dimensionedScalar alphaInversion_

protected

Definition at line 92 of file continuousGasKEpsilon.H.

The documentation for this class was generated from the following files:

src/MomentumTransportModels/phaseCompressible/RAS/continuousGasKEpsilon/continuousGasKEpsilon.H
src/MomentumTransportModels/phaseCompressible/RAS/continuousGasKEpsilon/continuousGasKEpsilon.C
