Renormalisation group k-epsilon turbulence model for incompressible and compressible flows. More...

Inheritance diagram for RNGkEpsilon< BasicMomentumTransportModel >:

Collaboration diagram for RNGkEpsilon< BasicMomentumTransportModel >:

[legend]

Public Types
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from eddyViscosity< RASModel< BasicMomentumTransportModel > >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from linearViscousStress< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Member Functions
	TypeName ("RNGkEpsilon")
	Runtime type information. More...

	RNGkEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

	RNGkEpsilon (const RNGkEpsilon &)=delete
	Disallow default bitwise copy construction. More...

virtual	~RNGkEpsilon ()
	Destructor. More...

virtual bool	read ()
	Re-read model coefficients if they have changed. More...

tmp< volScalarField >	DkEff () const
	Return the effective diffusivity for k. More...

tmp< volScalarField >	DepsilonEff () const
	Return the effective diffusivity for epsilon. More...

virtual tmp< volScalarField >	k () const
	Return the turbulence kinetic energy. More...

virtual tmp< volScalarField >	epsilon () const
	Return the turbulence kinetic energy dissipation rate. More...

virtual tmp< volScalarField >	omega () const
	Return the turbulence specific dissipation rate. More...

virtual void	correct ()
	Solve the turbulence equations and correct the turbulence viscosity. More...

void	operator= (const RNGkEpsilon &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from eddyViscosity< RASModel< BasicMomentumTransportModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~eddyViscosity ()
	Destructor. More...

virtual tmp< volScalarField >	nut () const
	Return the turbulence viscosity. More...

virtual tmp< scalarField >	nut (const label patchi) const
	Return the turbulence viscosity on patch. More...

virtual tmp< volSymmTensorField >	R () const
	Return the Reynolds stress tensor [m^2/s^2]. More...

virtual void	validate ()
	Validate the turbulence fields after construction. More...

Public Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~linearViscousStress ()
	Destructor. More...

virtual tmp< surfaceVectorField >	devTau () const
	Return the effective surface stress. More...

virtual tmp< fvVectorMatrix >	divDevTau (volVectorField &U) const
	Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrix >	divDevTau (const volScalarField &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

template<class RhoFieldType >
Foam::tmp< Foam::fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const

Protected Member Functions
tmp< volScalarField >	boundEpsilon ()
	Bound epsilon and return Cmu*sqr(k) for nut. More...

virtual void	correctNut ()
	Correct the eddy-viscosity nut. More...

virtual tmp< fvScalarMatrix >	kSource () const
	Source term for the k equation. More...

virtual tmp< fvScalarMatrix >	epsilonSource () const
	Source term for the epsilon equation. More...

Protected Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
template<class RhoFieldType >
tmp< fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

Protected Attributes
dimensionedScalar	Cmu_

dimensionedScalar	C1_

dimensionedScalar	C2_

dimensionedScalar	C3_

dimensionedScalar	sigmak_

dimensionedScalar	sigmaEps_

dimensionedScalar	eta0_

dimensionedScalar	beta_

volScalarField	k_

volScalarField	epsilon_

Protected Attributes inherited from eddyViscosity< RASModel< BasicMomentumTransportModel > >
volScalarField	nut_

Detailed Description

template<class BasicMomentumTransportModel>
class Foam::RASModels::RNGkEpsilon< BasicMomentumTransportModel >

Renormalisation group k-epsilon turbulence model for incompressible and compressible flows.

Reference:

    Yakhot, V., Orszag, S. A., Thangam, S.,
    Gatski, T. B., & Speziale, C. G. (1992).
    Development of turbulence models for shear flows
    by a double expansion technique.
    Physics of Fluids A: Fluid Dynamics (1989-1993), 4(7), 1510-1520.

For the RDT-based compression term:
    El Tahry, S. H. (1983).
    k-epsilon equation for compressible reciprocating engine flows.
    Journal of Energy, 7(4), 345-353.

The default model coefficients are

    RNGkEpsilonCoeffs
    {
        Cmu         0.0845;
        C1          1.42;
        C2          1.68;
        C3          0;
        sigmak      0.71942;
        sigmaEps    0.71942;
        eta0        4.38;
        beta        0.012;
    }

Source files

Definition at line 82 of file RNGkEpsilon.H.

Member Typedef Documentation

◆ alphaField

typedef BasicMomentumTransportModel::alphaField alphaField

Definition at line 126 of file RNGkEpsilon.H.

◆ rhoField

typedef BasicMomentumTransportModel::rhoField rhoField

Definition at line 127 of file RNGkEpsilon.H.

Constructor & Destructor Documentation

◆ RNGkEpsilon() [1/2]

RNGkEpsilon	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity,
		const word &	type = `typeName`
	)

Construct from components.

Definition at line 92 of file RNGkEpsilon.C.

References Foam::bound(), RNGkEpsilon< BasicMomentumTransportModel >::boundEpsilon(), and RNGkEpsilon< BasicMomentumTransportModel >::k_.

Here is the call graph for this function:

◆ RNGkEpsilon() [2/2]

RNGkEpsilon ( const RNGkEpsilon< BasicMomentumTransportModel > & )

delete

Disallow default bitwise copy construction.

◆ ~RNGkEpsilon()

virtual ~RNGkEpsilon ( )

inlinevirtual

Destructor.

Definition at line 153 of file RNGkEpsilon.H.

Member Function Documentation

◆ boundEpsilon()

tmp< volScalarField > boundEpsilon

protected

Bound epsilon and return Cmu*sqr(k) for nut.

Definition at line 41 of file RNGkEpsilon.C.

References Foam::max(), and Foam::sqr().

Referenced by RNGkEpsilon< BasicMomentumTransportModel >::RNGkEpsilon().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ correctNut()

void correctNut

protectedvirtual

Correct the eddy-viscosity nut.

Implements eddyViscosity< RASModel< BasicMomentumTransportModel > >.

Definition at line 50 of file RNGkEpsilon.C.

References dictionary::New().

Here is the call graph for this function:

◆ kSource()

tmp< fvScalarMatrix > kSource

protectedvirtual

Source term for the k equation.

Definition at line 59 of file RNGkEpsilon.C.

References Foam::dimTime, and Foam::dimVolume.

◆ epsilonSource()

tmp< fvScalarMatrix > epsilonSource

protectedvirtual

Source term for the epsilon equation.

Definition at line 75 of file RNGkEpsilon.C.

References Foam::dimTime, and Foam::dimVolume.

◆ TypeName()

TypeName ( "RNGkEpsilon< BasicMomentumTransportModel >" )

Runtime type information.

◆ read()

bool read

virtual

Re-read model coefficients if they have changed.

Implements eddyViscosity< RASModel< BasicMomentumTransportModel > >.

Definition at line 156 of file RNGkEpsilon.C.

References Foam::read().

Here is the call graph for this function:

◆ DkEff()

tmp<volScalarField> DkEff ( ) const

inline

Return the effective diffusivity for k.

Definition at line 163 of file RNGkEpsilon.H.

References GeometricField< Type, GeoMesh, PrimitiveField >::New(), and eddyViscosity< RASModel< BasicMomentumTransportModel > >::nut_.

Here is the call graph for this function:

◆ DepsilonEff()

tmp<volScalarField> DepsilonEff ( ) const

inline

Return the effective diffusivity for epsilon.

Definition at line 173 of file RNGkEpsilon.H.

References GeometricField< Type, GeoMesh, PrimitiveField >::New(), and eddyViscosity< RASModel< BasicMomentumTransportModel > >::nut_.

Here is the call graph for this function:

◆ k()

virtual tmp<volScalarField> k ( ) const

inlinevirtual

Return the turbulence kinetic energy.

Implements eddyViscosity< RASModel< BasicMomentumTransportModel > >.

Definition at line 183 of file RNGkEpsilon.H.

References RNGkEpsilon< BasicMomentumTransportModel >::k_.

◆ epsilon()

virtual tmp<volScalarField> epsilon ( ) const

inlinevirtual

Return the turbulence kinetic energy dissipation rate.

Definition at line 189 of file RNGkEpsilon.H.

References RNGkEpsilon< BasicMomentumTransportModel >::epsilon_.

◆ omega()

virtual tmp<volScalarField> omega ( ) const

inlinevirtual

Return the turbulence specific dissipation rate.

Definition at line 195 of file RNGkEpsilon.H.

References RNGkEpsilon< BasicMomentumTransportModel >::Cmu_, RNGkEpsilon< BasicMomentumTransportModel >::epsilon_, RNGkEpsilon< BasicMomentumTransportModel >::k_, and GeometricField< Type, GeoMesh, PrimitiveField >::New().

Here is the call graph for this function:

◆ correct()

void correct

virtual

Solve the turbulence equations and correct the turbulence viscosity.

Implements eddyViscosity< RASModel< BasicMomentumTransportModel > >.

Definition at line 179 of file RNGkEpsilon.C.

References Foam::fvc::absolute(), alpha(), Foam::bound(), tmp< T >::clear(), fvConstraints::constrain(), Foam::MULES::correct(), Foam::fvm::ddt(), Foam::dev(), Foam::fvc::div(), Foam::fvm::div(), fvConstraints(), fvModels(), Foam::constant::universal::G, Foam::fvc::grad(), Foam::fvm::laplacian(), Foam::mag(), dictionary::New(), nut, Foam::R(), tmp< T >::ref(), rho, Foam::solve(), fvModels::source(), Foam::fvm::Sp(), Foam::sqr(), Foam::sqrt(), Foam::fvm::SuSp(), Foam::twoSymm(), Foam::typedName(), and U.

Here is the call graph for this function:

◆ operator=()

void operator= ( const RNGkEpsilon< BasicMomentumTransportModel > & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ Cmu_

dimensionedScalar Cmu_

protected

Definition at line 93 of file RNGkEpsilon.H.

Referenced by RNGkEpsilon< BasicMomentumTransportModel >::omega().

◆ C1_

dimensionedScalar C1_

protected

Definition at line 94 of file RNGkEpsilon.H.

◆ C2_

dimensionedScalar C2_

protected

Definition at line 95 of file RNGkEpsilon.H.

◆ C3_

dimensionedScalar C3_

protected

Definition at line 96 of file RNGkEpsilon.H.

◆ sigmak_

dimensionedScalar sigmak_

protected

Definition at line 97 of file RNGkEpsilon.H.

◆ sigmaEps_

dimensionedScalar sigmaEps_

protected

Definition at line 98 of file RNGkEpsilon.H.

◆ eta0_

dimensionedScalar eta0_

protected

Definition at line 99 of file RNGkEpsilon.H.

◆ beta_

dimensionedScalar beta_

protected

Definition at line 100 of file RNGkEpsilon.H.

◆ k_

volScalarField k_

protected

Definition at line 105 of file RNGkEpsilon.H.

Referenced by RNGkEpsilon< BasicMomentumTransportModel >::k(), RNGkEpsilon< BasicMomentumTransportModel >::omega(), and RNGkEpsilon< BasicMomentumTransportModel >::RNGkEpsilon().

◆ epsilon_

volScalarField epsilon_

protected

Definition at line 106 of file RNGkEpsilon.H.

Referenced by RNGkEpsilon< BasicMomentumTransportModel >::epsilon(), and RNGkEpsilon< BasicMomentumTransportModel >::omega().

The documentation for this class was generated from the following files:

src/MomentumTransportModels/momentumTransportModels/RAS/RNGkEpsilon/RNGkEpsilon.H
src/MomentumTransportModels/momentumTransportModels/RAS/RNGkEpsilon/RNGkEpsilon.C

Public Types

Public Member Functions

Protected Member Functions

Protected Attributes

Detailed Description

template<class BasicMomentumTransportModel> class Foam::RASModels::RNGkEpsilon< BasicMomentumTransportModel >

Member Typedef Documentation

◆ alphaField

◆ rhoField

Constructor & Destructor Documentation

◆ RNGkEpsilon() [1/2]

◆ RNGkEpsilon() [2/2]

◆ ~RNGkEpsilon()

Member Function Documentation

◆ boundEpsilon()

◆ correctNut()

◆ kSource()

◆ epsilonSource()

◆ TypeName()

◆ read()

◆ DkEff()

◆ DepsilonEff()

◆ k()

◆ epsilon()

◆ omega()

◆ correct()

◆ operator=()

Member Data Documentation

◆ Cmu_

◆ C1_

◆ C2_

◆ C3_

◆ sigmak_

◆ sigmaEps_

◆ eta0_

◆ beta_

◆ k_

◆ epsilon_

template<class BasicMomentumTransportModel>
class Foam::RASModels::RNGkEpsilon< BasicMomentumTransportModel >
