Public Member Functions | List of all members
ParkRogakSurfaceAreaVolumeRatioFvScalarFieldSource Class Reference

This source condition creates an interfacial mass transfer source term in the surface-area-to-volume-ratio (kappa) equations of the fractal shape model of population balance, according to the model of Park and Rogak. More...

Inheritance diagram for ParkRogakSurfaceAreaVolumeRatioFvScalarFieldSource:
Inheritance graph
[legend]
Collaboration diagram for ParkRogakSurfaceAreaVolumeRatioFvScalarFieldSource:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("ParkRogakSurfaceAreaVolumeRatio")
 Runtime type information. More...

virtual autoPtr< fvScalarFieldSource > clone (const DimensionedField< scalar, volMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

virtual tmp< DimensionedField< scalar, volMesh > > value (const label i, const fvSource &model) const
 Return the value transported from the adjacent group. More...

- Public Member Functions inherited from growthSecondaryPropertyFvScalarFieldSource
 growthSecondaryPropertyFvScalarFieldSource (const DimensionedField< scalar, volMesh > &, const dictionary &dict)
 Construct from internal field and dictionary. More...

 growthSecondaryPropertyFvScalarFieldSource (const growthSecondaryPropertyFvScalarFieldSource &, const DimensionedField< scalar, volMesh > &)
 Copy constructor setting internal field reference. More...

virtual tmp< DimensionedField< scalar, volMesh > > internalCoeff (const fvSource &model, const DimensionedField< scalar, volMesh > &source) const
 Return the internal coefficient. More...

virtual Pair< tmp< DimensionedField< scalar, volMesh > > > sourceCoeffs (const fvSource &model) const
 Return the source coefficients for exchange with the groups below. More...

virtual tmp< DimensionedField< scalar, volMesh > > sourceCoeff (const fvSource &model, const DimensionedField< scalar, volMesh > &source) const
 Return the combined source coefficient. More...

- Public Member Functions inherited from growthFvScalarFieldSource
virtual tmp< DimensionedField< scalar, volMesh > > sourceValue (const fvSource &model, const DimensionedField< scalar, volMesh > &source) const
 Return the source value. Not Implemented. More...

- Public Member Functions inherited from secondaryPropertyFvScalarFieldSource
 secondaryPropertyFvScalarFieldSource (const DimensionedField< scalar, volMesh > &)
 Construct from internal field. More...

const UPtrList< diameterModels::sizeGroup > & fis () const
 Return the list of size-groups. More...

label i () const
 Return the index of this group. More...

const diameterModels::sizeGroup & fi (const label deltai=0) const
 Return a size-group. More...

template<class ModelType >
const volScalarField & fld (const label deltai=0) const
 Return a secondary property field. More...

template<class ModelType >
const ModelType & model (const label deltai=0) const
 Return a secondary property model. More...

template<class ModelType >
const Foam::volScalarField & fld (const label deltai) const


Detailed Description

This source condition creates an interfacial mass transfer source term in the surface-area-to-volume-ratio (kappa) equations of the fractal shape model of population balance, according to the model of Park and Rogak.

Reference:

    Park, S. H., & Rogak, S. N. (2004).
    A novel fixed-sectional model for the formation and growth of aerosol
    agglomerates.
    Journal of Aerosol Science, 35(11), 1385-1404.
\endbverbatim

\par Usage
Example of the source condition specification:
\verbatim
<sourceName>
{
    type            ParkRogakSurfaceAreaVolumeRatio;
    libs            ("libmultiphaseEulerFvModels.so");
}
Source files

Definition at line 68 of file ParkRogakSurfaceAreaVolumeRatioFvScalarFieldSource.H.

Member Function Documentation

◆ TypeName()

TypeName ( "ParkRogakSurfaceAreaVolumeRatio"  )

Runtime type information.

◆ clone()

virtual autoPtr<fvScalarFieldSource> clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 86 of file ParkRogakSurfaceAreaVolumeRatioFvScalarFieldSource.H.

◆ value()

Foam::tmp< Foam::DimensionedField< Foam::scalar, Foam::volMesh > > value ( const label  i,
const fvSource &  model
) const
virtual

Return the value transported from the adjacent group.

Implements growthSecondaryPropertyFvScalarFieldSource.

Definition at line 33 of file ParkRogakSurfaceAreaVolumeRatioFvScalarFieldSource.C.

References fractal::alphaC(), fractal::d(), fractal::Df(), secondaryPropertyFvScalarFieldSource::fi(), Foam::constant::mathematical::pi(), Foam::pow(), Foam::pow3(), Foam::sqr(), and sizeGroup::x().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
