OldTimeField< FieldType > Class Template Reference

Class to add into field types to provide old-time storage and retrieval. More...

Inheritance diagram for OldTimeField< FieldType >:

Public Member Functions
	OldTimeField (const label timeIndex)
	Construct from a time index. More...
	OldTimeField (const OldTimeField< FieldType > &otf)
	Copy construct. More...
	OldTimeField (OldTimeField< FieldType > &&otf)
	Move construct. More...
	~OldTimeField ()
	Destructor. More...
label	timeIndex () const
	Return the time index of the field. More...
label &	timeIndex ()
	Return a non-const reference to the time index of the field. More...
bool	isOldTime () const
	Return whether or not this is an old-time field. More...
bool	hasStoredOldTimes () const
	Return whether old-time fields have been stored yet. More...
void	storeOldTimes () const
	Store the old-time fields. More...
void	clearOldTimes ()
	Clear old-time fields. More...
void	nullOldestTime ()
	Set the oldest field pointer to nullObjectPtr. This removes the. More...
label	nOldTimes (const bool includeNull=true) const
	Return the number of old-time fields stored. More...
const Field0Type &	oldTime () const
	Return the old-time field. More...
Field0Type &	oldTimeRef ()
	Return a non-const reference to the old-time field. More...
const Field0Type &	oldTime (const label n) const
	Return the n-th old-time field. More...
Field0Type &	oldTimeRef (const label n)
	Return a non-const reference to the n-th old time field. More...
void	operator= (const OldTimeField< FieldType > &)=delete
	Disallow default bitwise assignment. More...

Protected Member Functions
bool	readOldTimeIfPresent ()
	Read old-time field from file if it is present. More...
template<template< class > class OtherPrimitiveField>
void	copyOldTimes (const IOobject &io, const OtherOldTime< OtherPrimitiveField > &)
	Copy the old-times from the given field. More...
template<template< class > class OtherPrimitiveField>
void	copyOldTimes (const word &newName, const OtherOldTime< OtherPrimitiveField > &)
	Copy the old-times from the given field. More...

Friends
template<class OtherFieldType >
class	OldTimeField
	Declare friendship with other old-time fields. More...
template<class OtherFieldType , typename >
struct	OldTimeBaseFieldType
	Declare friendship with the base old-time field casting struct. More...

Detailed Description

template<class FieldType>
class Foam::OldTimeField< FieldType >

Class to add into field types to provide old-time storage and retrieval.

Source files

• OldTimeField.H
• OldTimeFieldI.H
• OldTimeField.C

Definition at line 112 of file OldTimeField.H.

Constructor & Destructor Documentation

OldTimeField() [1/3]

OldTimeField

(

const label

timeIndex

)

Construct from a time index.

Definition at line 190 of file OldTimeField.C.

OldTimeField() [2/3]

OldTimeField

(

const OldTimeField< FieldType > &

otf

)

Copy construct.

Definition at line 198 of file OldTimeField.C.

References Foam::notNull(), and tmp< T >::valid().

Here is the call graph for this function:

OldTimeField() [3/3]

OldTimeField

(

OldTimeField< FieldType > &&

otf

)

Move construct.

Definition at line 212 of file OldTimeField.C.

~OldTimeField()

~OldTimeField

Destructor.

Definition at line 228 of file OldTimeField.C.

References Foam::notNull().

Here is the call graph for this function:

Member Function Documentation

readOldTimeIfPresent()

bool readOldTimeIfPresent

protected

Read old-time field from file if it is present.

Definition at line 125 of file OldTimeField.C.

References typeIOobject< Type >::headerOk(), mesh, and Foam::name().

Here is the call graph for this function:

copyOldTimes() [1/2]

void copyOldTimes ( const IOobject &  io, const OtherOldTime< OtherPrimitiveField > &  otf  )

protected

Copy the old-times from the given field.

Definition at line 161 of file OldTimeField.C.

References IOobject::name().

Here is the call graph for this function:

copyOldTimes() [2/2]

void copyOldTimes ( const word &  newName, const OtherOldTime< OtherPrimitiveField > &  otf  )

protected

Copy the old-times from the given field.

Definition at line 173 of file OldTimeField.C.

timeIndex() [1/2]

Foam::label timeIndex

inline

Return the time index of the field.

Definition at line 31 of file OldTimeFieldI.H.

Referenced by subCycleField< GeometricField >::~subCycleField().

Here is the caller graph for this function:

timeIndex() [2/2]

Foam::label & timeIndex

inline

Return a non-const reference to the time index of the field.

Definition at line 38 of file OldTimeFieldI.H.

isOldTime()

bool isOldTime

Return whether or not this is an old-time field.

Definition at line 241 of file OldTimeField.C.

hasStoredOldTimes()

bool hasStoredOldTimes

Return whether old-time fields have been stored yet.

Definition at line 250 of file OldTimeField.C.

storeOldTimes()

void storeOldTimes

Store the old-time fields.

Definition at line 257 of file OldTimeField.C.

Referenced by LagrangianMesh::reset().

Here is the caller graph for this function:

clearOldTimes()

void clearOldTimes

Clear old-time fields.

Definition at line 276 of file OldTimeField.C.

Referenced by Foam::MeshToMeshMapVolFields(), and LagrangianMesh::reset().

Here is the caller graph for this function:

nullOldestTime()

void nullOldestTime

Set the oldest field pointer to nullObjectPtr. This removes the.

field whilst maintaining a tag distinct from nullptr so that the field can be reinstated on the next storeOldTimes.

Definition at line 287 of file OldTimeField.C.

nOldTimes()

Foam::label nOldTimes

(

const bool

includeNull = true

)

const

Return the number of old-time fields stored.

Definition at line 297 of file OldTimeField.C.

References Foam::isNull().

Referenced by fvMesh::conform(), inhomogeneousEGRMixture< ThermoType >::reset(), and fvMesh::unconform().

Here is the call graph for this function:

Here is the caller graph for this function:

oldTime() [1/2]

const Foam::OldTimeField< FieldType >::Field0Type & oldTime

Return the old-time field.

Definition at line 322 of file OldTimeField.C.

References Foam::isNull(), Foam::name(), IOobject::NO_READ, and IOobject::NO_WRITE.

Referenced by turbulentDispersion::calculate(), fvMesh::conform(), EulerD2dt2Scheme< Type >::fvcD2dt2(), backwardDdtScheme< Type >::fvcDdt(), CoEulerDdtScheme< Type >::fvcDdt(), CrankNicolsonDdtScheme< Type >::fvcDdt(), EulerDdtScheme< Type >::fvcDdt(), localEulerDdtScheme< Type >::fvcDdt(), SLTSDdtScheme< Type >::fvcDdt(), backwardDdtScheme< Type >::fvcDdtPhiCorr(), CoEulerDdtScheme< Type >::fvcDdtPhiCorr(), CrankNicolsonDdtScheme< Type >::fvcDdtPhiCorr(), EulerDdtScheme< Type >::fvcDdtPhiCorr(), localEulerDdtScheme< Type >::fvcDdtPhiCorr(), SLTSDdtScheme< Type >::fvcDdtPhiCorr(), backwardDdtScheme< Type >::fvcDdtUfCorr(), CoEulerDdtScheme< Type >::fvcDdtUfCorr(), CrankNicolsonDdtScheme< Type >::fvcDdtUfCorr(), EulerDdtScheme< Type >::fvcDdtUfCorr(), localEulerDdtScheme< Type >::fvcDdtUfCorr(), SLTSDdtScheme< Type >::fvcDdtUfCorr(), EulerD2dt2Scheme< Type >::fvmD2dt2(), backwardDdtScheme< Type >::fvmDdt(), CoEulerDdtScheme< Type >::fvmDdt(), CrankNicolsonDdtScheme< Type >::fvmDdt(), EulerDdtScheme< Type >::fvmDdt(), localEulerDdtScheme< Type >::fvmDdt(), SLTSDdtScheme< Type >::fvmDdt(), ddtScheme< Type >::Lagrangianmddt(), CrankNicolson< Type >::LagrangianmDdt(), ddtScheme< Type >::Lagrangianmddt0(), CrankNicolsonDdtScheme< Type >::meshPhi(), backwardDdtScheme< Type >::meshPhi(), OldTimeField< FieldType >::oldTimeRef(), LagrangianMesh::reset(), inhomogeneousEGRMixture< ThermoType >::reset(), cloud::solve(), chemistryModel< ThermoType >::solve(), LagrangianMesh::track(), fvMesh::unconform(), advectiveFvPatchField< Type >::updateCoeffs(), waveSurfacePressureFvPatchScalarField::updateCoeffs(), and fvMeshStitcher::volumeConservationError().

Here is the call graph for this function:

Here is the caller graph for this function:

oldTimeRef() [1/2]

Foam::OldTimeField< FieldType >::Field0Type & oldTimeRef

Return a non-const reference to the old-time field.

Definition at line 362 of file OldTimeField.C.

References OldTimeField< FieldType >::oldTime().

Referenced by inhomogeneousEGRMixture< ThermoType >::reset().

Here is the call graph for this function:

Here is the caller graph for this function:

oldTime() [2/2]

const Foam::OldTimeField< FieldType >::Field0Type & oldTime

(

const label

n

)

const

Return the n-th old-time field.

Definition at line 375 of file OldTimeField.C.

References n.

oldTimeRef() [2/2]

Foam::OldTimeField< FieldType >::Field0Type & oldTimeRef

(

const label

n

)

Return a non-const reference to the n-th old time field.

Definition at line 386 of file OldTimeField.C.

References n.

operator=()

void operator= ( const OldTimeField< FieldType > &  )

delete

Disallow default bitwise assignment.

Friends And Related Function Documentation

OldTimeField

friend class OldTimeField

friend

Declare friendship with other old-time fields.

Definition at line 200 of file OldTimeField.H.

OldTimeBaseFieldType

friend struct OldTimeBaseFieldType

friend

Declare friendship with the base old-time field casting struct.

Definition at line 204 of file OldTimeField.H.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/fields/OldTimeField/OldTimeField.H
• src/OpenFOAM/fields/OldTimeField/OldTimeField.C
• src/OpenFOAM/fields/OldTimeField/OldTimeFieldI.H
