accumulationScheme< Type > Class Template Reference

Basic cell Lagrangian accumulation scheme. More...

Inheritance diagram for accumulationScheme< Type >:

Collaboration diagram for accumulationScheme< Type >:

Public Member Functions
	TypeName ("accumulationScheme")
	Runtime type information. More...
	declareRunTimeSelectionTable (tmp, accumulationScheme, Istream,(const LagrangianMesh &mesh, Istream &is),(mesh, is))
	Declare run-time constructor selection tables. More...
	accumulationScheme (const LagrangianMesh &mesh)
	Construct from a mesh. More...
	accumulationScheme (const LagrangianMesh &mesh, Istream &)
	Construct from a mesh and a stream. More...
	accumulationScheme (const accumulationScheme &)=delete
	Disallow default bitwise copy construction. More...
virtual	~accumulationScheme ()
	Destructor. More...
const LagrangianMesh &	mesh () const
	Return mesh reference. More...
template<class CellMesh , template< class > class PrimitiveField>
tmp< DimensionedField< Type, CellMesh > >	accumulate (const DimensionedField< Type, LagrangianMesh, PrimitiveField > &lPsi)
	Accumulate a Lagrangian field into a finite volume field. More...
template<class CellMesh , template< class > class PrimitiveField>
void	accumulate (const LagrangianSubField< Type, PrimitiveField > &lPsi, DimensionedField< Type, CellMesh > &vPsi)
	Accumulate a Lagrangian sub-field into a finite volume field. More...
void	operator= (const accumulationScheme &)=delete
	Disallow default bitwise assignment. More...
template<class CellMesh , template< class > class PrimitiveField>
Foam::tmp< Foam::DimensionedField< Type, CellMesh > >	accumulate (const DimensionedField< Type, LagrangianMesh, PrimitiveField > &lPsi)
Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...
bool	unique () const
	Return true if the reference count is zero. More...
void	operator++ ()
	Increment the reference count. More...
void	operator++ (int)
	Increment the reference count. More...
void	operator-- ()
	Decrement the reference count. More...
void	operator-- (int)
	Decrement the reference count. More...
void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Static Public Member Functions
static tmp< accumulationScheme< Type > >	New (const LagrangianMesh &mesh, Istream &is)
	Return a pointer to a new accumulationScheme. More...

Protected Attributes
const LagrangianMesh &	mesh_
	Reference to the mesh. More...

Additional Inherited Members
Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...
	refCount (const refCount &)=delete
	Disallow copy. More...

Detailed Description

template<class Type>
class Foam::Lagrangian::accumulationScheme< Type >

Basic cell Lagrangian accumulation scheme.

Abstract base class for Lagrangian accumulation schemes.

Cell-point Lagrangian accumulation scheme.

Source files

• cell_LagrangianAccumulationScheme.H cell_
• LagrangianAccumulationScheme.C cell_
• LagrangianAccumulationSchemes.C

Source files

• cellPoint_LagrangianAccumulationScheme.H cellPoint_
• LagrangianAccumulationScheme.C cellPoint_
• LagrangianAccumulationSchemes.C

Source files

• LagrangianAccumulationScheme.H
• LagrangianAccumulationScheme.C
• LagrangianAccumulationSchemes.C

Definition at line 62 of file LagrangianAccumulationScheme.H.

Constructor & Destructor Documentation

accumulationScheme() [1/3]

accumulationScheme ( const LagrangianMesh &  mesh )

inline

Construct from a mesh.

Definition at line 106 of file LagrangianAccumulationScheme.H.

accumulationScheme() [2/3]

accumulationScheme ( const LagrangianMesh &  mesh, Istream &    )

inline

Construct from a mesh and a stream.

Definition at line 112 of file LagrangianAccumulationScheme.H.

accumulationScheme() [3/3]

accumulationScheme ( const accumulationScheme< Type > &  )

delete

Disallow default bitwise copy construction.

~accumulationScheme()

~accumulationScheme

virtual

Destructor.

Definition at line 69 of file LagrangianAccumulationScheme.C.

Member Function Documentation

TypeName()

TypeName

(

"accumulationScheme< Type >"

)

Runtime type information.

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	tmp	,
		accumulationScheme< Type >	,
		Istream	,
		(const LagrangianMesh &mesh, Istream &is)	,
		(mesh, is)
	)

Declare run-time constructor selection tables.

New()

Foam::tmp< Foam::Lagrangian::accumulationScheme< Type > > New ( const LagrangianMesh &  mesh, Istream &  is  )

static

Return a pointer to a new accumulationScheme.

Definition at line 33 of file LagrangianAccumulationScheme.C.

References Foam::endl(), IOstream::eof(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, mesh, and Foam::nl.

Here is the call graph for this function:

mesh()

const LagrangianMesh& mesh ( ) const

inline

Return mesh reference.

Definition at line 138 of file LagrangianAccumulationScheme.H.

References accumulationScheme< Type >::mesh_.

accumulate() [1/3]

tmp<DimensionedField<Type, CellMesh> > accumulate

(

const DimensionedField< Type, LagrangianMesh, PrimitiveField > &

lPsi

)

Accumulate a Lagrangian field into a finite volume field.

accumulate() [2/3]

void accumulate	(	const LagrangianSubField< Type, PrimitiveField > &	lPsi,
		DimensionedField< Type, CellMesh > &	vPsi
	)

Accumulate a Lagrangian sub-field into a finite volume field.

Definition at line 105 of file LagrangianAccumulationScheme.C.

References Foam::Lagrangianc::accumulate(), DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), DimensionedField< Type, GeoMesh, PrimitiveField >::primitiveFieldRef(), and Foam::toSubField().

Here is the call graph for this function:

operator=()

void operator= ( const accumulationScheme< Type > &  )

delete

Disallow default bitwise assignment.

accumulate() [3/3]

Foam::tmp<Foam::DimensionedField<Type, CellMesh> > accumulate

(

const DimensionedField< Type, LagrangianMesh, PrimitiveField > &

lPsi

)

Definition at line 78 of file LagrangianAccumulationScheme.C.

References Foam::Lagrangianc::accumulate(), DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), DimensionedField< Type, GeoMesh, PrimitiveField >::mesh(), IOobject::name(), Foam::compressible::New(), and tmp< T >::ref().

Here is the call graph for this function:

Member Data Documentation

mesh_

const LagrangianMesh& mesh_

protected

Reference to the mesh.

Definition at line 83 of file LagrangianAccumulationScheme.H.

Referenced by accumulationScheme< Type >::mesh().

---

The documentation for this class was generated from the following files:

• src/Lagrangian/Lagrangian/Lagrangian/LagrangianAccumulationSchemes/LagrangianAccumulationScheme/LagrangianAccumulationScheme.H
• src/Lagrangian/Lagrangian/Lagrangian/LagrangianAccumulationSchemes/LagrangianAccumulationScheme/LagrangianAccumulationScheme.C
