Inheritance diagram for cellPoint< Type >:

Collaboration diagram for cellPoint< Type >:

Public Member Functions
	TypeName ("cellPoint")
	Runtime type information. More...

	cellPoint (const word &name, const LagrangianMesh &mesh, const dimensionSet &dimensions, const Field< scalar > &weightSum)
	Construct with a name, for a mesh and with given dimensions. More...

virtual	~cellPoint ()
	Destructor. More...

virtual void	remove (const LagrangianSubSubField< scalar > &weight, const LagrangianSubSubField< Type > &psi)
	Remove weighted values from the average. More...

virtual void	add (const LagrangianSubSubField< scalar > &weight, const LagrangianSubSubField< Type > &psi, const bool cache)
	Add weighted values to the average. More...

virtual void	correct (const LagrangianSubSubField< scalar > &weight, const LagrangianSubSubField< Type > &psi, const bool cache)
	Correct weighted values in the average. More...

template<class CellWeight >
Foam::tmp< Foam::Field< Foam::scalar > >	cellVolumeWeightedSum (const polyMesh &pMesh, const CellWeight &cellWeight)

template<class CellWeight >
Foam::tmp< Foam::Field< Foam::scalar > >	pointVolumeWeightedSum (const polyMesh &pMesh, const CellWeight &cellWeight)

Public Member Functions inherited from LagrangianAverage< Type >
	TypeName ("LagrangianAverage")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, LagrangianAverage, dictionary,(const word &name, const LagrangianMesh &mesh, const dimensionSet &dimensions, const Field< scalar > &cellWeightSum),(name, mesh, dimensions, cellWeightSum))
	Declare run-time constructor selection tables. More...

	LagrangianAverage (const word &name, const LagrangianMesh &mesh, const dimensionSet &dimensions)
	Construct with a name, for a mesh and with given dimensions. More...

virtual	~LagrangianAverage ()
	Destructor. More...

void	remove (const LagrangianSubSubField< Type > &weightPsi)
	Remove values from the average. More...

void	add (const LagrangianSubSubField< Type > &weightPsi, const bool cache)
	Add values to the average. More...

void	correct (const LagrangianSubSubField< Type > &weightPsi, const bool cache)
	Correct values in the average. More...

tmp< LagrangianSubField< Type > >	interpolate (const LagrangianSubMesh &subMesh) const
	Interpolate to a sub-mesh. More...

void	operator= (const LagrangianAverage< Type > &)=delete
	Disallow default bitwise assignment. More...

template<template< class > class WeightPF, template< class > class PsiPF>
Foam::autoPtr< Foam::LagrangianAverage< Type > >	New (const word &type, const word &name, const DimensionedField< scalar, LagrangianMesh, WeightPF > &weight, const DimensionedField< Type, LagrangianMesh, PsiPF > &psi)

template<class CellMesh , template< class > class PsiPF>
Foam::LagrangianAverageNewReturnType< CellMesh, Type >::type	New (const word &type, const word &name, const DimensionedField< scalar, CellMesh > &cellWeightSum, const DimensionedField< Type, LagrangianMesh, PsiPF > &weightPsi)

Additional Inherited Members
Static Public Member Functions inherited from LagrangianAverage< Type >
template<template< class > class WeightPF, template< class > class PsiPF>
static autoPtr< LagrangianAverage< Type > >	New (const word &type, const word &name, const DimensionedField< scalar, LagrangianMesh, WeightPF > &weight, const DimensionedField< Type, LagrangianMesh, PsiPF > &psi)
	Select to average a field. More...

template<class CellMesh , template< class > class WeightPsiPF>
static LagrangianAverageNewReturnType< CellMesh, Type >::type	New (const word &type, const word &name, const DimensionedField< scalar, CellMesh > &cellWeightSum, const DimensionedField< Type, LagrangianMesh, WeightPsiPF > &weightPsi)
	Select to average a field with a given cell weight sum. More...

Detailed Description

template<class Type>
class Foam::LagrangianAverages::cellPoint< Type >

Definition at line 58 of file cellPoint_LagrangianAverage.H.

Constructor & Destructor Documentation

◆ cellPoint()

cellPoint	(	const word &	name,
		const LagrangianMesh &	mesh,
		const dimensionSet &	dimensions,
		const Field< scalar > &	weightSum
	)

Construct with a name, for a mesh and with given dimensions.

Definition at line 584 of file cellPoint_LagrangianAverage.C.

◆ ~cellPoint()

~cellPoint

virtual

Destructor.

Definition at line 614 of file cellPoint_LagrangianAverage.C.

Member Function Documentation

◆ TypeName()

TypeName ( "cellPoint< Type >" )

Runtime type information.

◆ remove()

void remove	(	const LagrangianSubSubField< scalar > &	weight,
		const LagrangianSubSubField< Type > &	psi
	)

virtual

Remove weighted values from the average.

Implements LagrangianAverage< Type >.

Definition at line 621 of file cellPoint_LagrangianAverage.C.

References clear(), Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ add()

void add	(	const LagrangianSubSubField< scalar > &	weight,
		const LagrangianSubSubField< Type > &	psi,
		const bool	cache
	)

virtual

Add weighted values to the average.

Implements LagrangianAverage< Type >.

Definition at line 645 of file cellPoint_LagrangianAverage.C.

References clear(), Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ correct()

void correct	(	const LagrangianSubSubField< scalar > &	weight,
		const LagrangianSubSubField< Type > &	psi,
		const bool	cache
	)

virtual

Correct weighted values in the average.

Implements LagrangianAverage< Type >.

Definition at line 675 of file cellPoint_LagrangianAverage.C.

References clear(), Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ cellVolumeWeightedSum()

Foam::tmp<Foam::Field<Foam::scalar> > cellVolumeWeightedSum	(	const polyMesh &	pMesh,
		const CellWeight &	cellWeight
	)

Definition at line 38 of file cellPoint_LagrangianAverage.C.

References Foam::constant::universal::c, primitiveMesh::cells(), f(), polyMesh::faces(), forAll, tetrahedron< Point, PointRef >::mag(), primitiveMesh::nCells(), tmp< T >::ref(), and tetIndices::tet().

Here is the call graph for this function:

◆ pointVolumeWeightedSum()

Foam::tmp<Foam::Field<Foam::scalar> > pointVolumeWeightedSum	(	const polyMesh &	pMesh,
		const CellWeight &	cellWeight
	)

Definition at line 73 of file cellPoint_LagrangianAverage.C.

References Foam::constant::universal::c, primitiveMesh::cells(), f(), polyMesh::faces(), tetIndices::faceTriIs(), forAll, tetrahedron< Point, PointRef >::mag(), primitiveMesh::nPoints(), tmp< T >::ref(), and tetIndices::tet().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/Lagrangian/Lagrangian/LagrangianAverage/cellPoint/cellPoint_LagrangianAverage.H
src/Lagrangian/Lagrangian/LagrangianAverage/cellPoint/cellPoint_LagrangianAverage.C
