Abstract base class for LES deltas. More...

Inheritance diagram for LESdelta:

[legend]

Collaboration diagram for LESdelta:

Public Member Functions
	TypeName ("LESdelta")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, LESdelta, dictionary,(const word &name, const momentumTransportModel &turbulence, const dictionary &dict),(name, turbulence, dict))

	LESdelta (const word &name, const momentumTransportModel &turbulence)
	Construct from name, momentumTransportModel and dictionary. More...

	LESdelta (const LESdelta &)=delete
	Disallow default bitwise copy construction. More...

virtual	~LESdelta ()
	Destructor. More...

const momentumTransportModel &	turbulence () const
	Return momentumTransportModel reference. More...

virtual void	read (const dictionary &)=0
	Read the LESdelta dictionary. More...

virtual void	correct ()=0

void	operator= (const LESdelta &)=delete

virtual	operator const volScalarField & () const

Static Public Member Functions
static autoPtr< LESdelta >	New (const word &name, const momentumTransportModel &turbulence, const dictionary &dict)
	Return a reference to the selected LES delta. More...

static autoPtr< LESdelta >	New (const word &name, const momentumTransportModel &turbulence, const dictionary &dict, const dictionaryConstructorTable &)
	Return a reference to the selected LES delta. More...

Protected Attributes
const momentumTransportModel &	momentumTransportModel_

volScalarField	delta_

Detailed Description

Abstract base class for LES deltas.

Source files

Definition at line 50 of file LESdelta.H.

Constructor & Destructor Documentation

◆ LESdelta() [1/2]

LESdelta	(	const word &	name,
		const momentumTransportModel &	turbulence
	)

Construct from name, momentumTransportModel and dictionary.

Definition at line 39 of file LESdelta.C.

◆ LESdelta() [2/2]

LESdelta ( const LESdelta & )

delete

Disallow default bitwise copy construction.

◆ ~LESdelta()

virtual ~LESdelta ( )

inlinevirtual

Destructor.

Definition at line 117 of file LESdelta.H.

Member Function Documentation

◆ TypeName()

TypeName ( "LESdelta" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		LESdelta	,
		dictionary	,
		(const word &name, const momentumTransportModel &turbulence, const dictionary &dict)	,
		(name, turbulence, dict)
	)

◆ New() [1/2]

Foam::autoPtr< Foam::LESdelta > New	(	const word &	name,
		const momentumTransportModel &	turbulence,
		const dictionary &	dict
	)

static

Return a reference to the selected LES delta.

Definition at line 65 of file LESdelta.C.

References Foam::decrIndent(), dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::incrIndent(), Foam::indent(), Foam::Info, dictionary::lookup(), Foam::name(), Foam::nl, and turbulence().

Here is the call graph for this function:

◆ New() [2/2]

Foam::autoPtr< Foam::LESdelta > New	(	const word &	name,
		const momentumTransportModel &	turbulence,
		const dictionary &	dict,
		const dictionaryConstructorTable &	additionalConstructors
	)

static

Return a reference to the selected LES delta.

Definition at line 97 of file LESdelta.C.

References Foam::decrIndent(), dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::incrIndent(), Foam::indent(), Foam::Info, dictionary::lookup(), Foam::name(), Foam::nl, and turbulence().

Here is the call graph for this function:

◆ turbulence()

const momentumTransportModel& turbulence ( ) const

inline

Return momentumTransportModel reference.

Definition at line 124 of file LESdelta.H.

References LESdelta::momentumTransportModel_.

◆ read()

virtual void read ( const dictionary & )

pure virtual

Read the LESdelta dictionary.

Implemented in vanDriestDelta, smoothDelta, PrandtlDelta, maxDeltaxyz, IDDESDelta, and cubeRootVolDelta.

◆ correct()

virtual void correct ( )

pure virtual

Implemented in vanDriestDelta, smoothDelta, PrandtlDelta, maxDeltaxyz, IDDESDelta, and cubeRootVolDelta.

◆ operator=()

void operator= ( const LESdelta & )

delete

◆ operator const volScalarField &()

virtual operator const volScalarField & ( ) const

inlinevirtual

Definition at line 140 of file LESdelta.H.

References LESdelta::delta_.

Member Data Documentation

◆ momentumTransportModel_

const momentumTransportModel& momentumTransportModel_

protected

Definition at line 56 of file LESdelta.H.

Referenced by LESdelta::turbulence().

◆ delta_

volScalarField delta_
