Inheritance diagram for Smagorinsky< BasicMomentumTransportModel >:

Collaboration diagram for Smagorinsky< BasicMomentumTransportModel >:

Public Types
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from LESeddyViscosity< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from eddyViscosity< LESModel< BasicMomentumTransportModel > >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from linearViscousStress< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Member Functions
	TypeName ("Smagorinsky")
	Runtime type information. More...

	Smagorinsky (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

	Smagorinsky (const Smagorinsky &)=delete
	Disallow default bitwise copy construction. More...

virtual	~Smagorinsky ()
	Destructor. More...

virtual bool	read ()
	Read model coefficients if they have changed. More...

virtual tmp< volScalarField >	k () const
	Return SGS kinetic energy. More...

virtual void	correct ()
	Correct Eddy-Viscosity and related properties. More...

void	operator= (const Smagorinsky &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from LESeddyViscosity< BasicMomentumTransportModel >
	LESeddyViscosity (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

	LESeddyViscosity (const LESeddyViscosity &)=delete
	Disallow default bitwise copy construction. More...

virtual	~LESeddyViscosity ()
	Destructor. More...

virtual tmp< volScalarField >	epsilon () const
	Return sub-grid disipation rate. More...

virtual tmp< volScalarField >	omega () const
	Return the turbulence specific dissipation rate. More...

void	operator= (const LESeddyViscosity &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from eddyViscosity< LESModel< BasicMomentumTransportModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~eddyViscosity ()
	Destructor. More...

virtual tmp< volScalarField >	nut () const
	Return the turbulence viscosity. More...

virtual tmp< scalarField >	nut (const label patchi) const
	Return the turbulence viscosity on patch. More...

virtual tmp< volSymmTensorField >	R () const
	Return the Reynolds stress tensor [m^2/s^2]. More...

virtual void	validate ()
	Validate the turbulence fields after construction. More...

Public Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~linearViscousStress ()
	Destructor. More...

virtual tmp< surfaceVectorField >	devTau () const
	Return the effective surface stress. More...

virtual tmp< fvVectorMatrix >	divDevTau (volVectorField &U) const
	Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrix >	divDevTau (const volScalarField &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

template<class RhoFieldType >
Foam::tmp< Foam::fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const

Protected Member Functions
tmp< volScalarField >	k (const tmp< volTensorField > &gradU) const
	Return SGS kinetic energy. More...

virtual void	correctNut ()
	Update the SGS eddy viscosity. More...

Protected Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
template<class RhoFieldType >
tmp< fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

Additional Inherited Members
Protected Attributes inherited from LESeddyViscosity< BasicMomentumTransportModel >
dimensionedScalar	Ck_

dimensionedScalar	Ce_

Protected Attributes inherited from eddyViscosity< LESModel< BasicMomentumTransportModel > >
volScalarField	nut_

Detailed Description

template<class BasicMomentumTransportModel>
class Foam::LESModels::Smagorinsky< BasicMomentumTransportModel >

The Smagorinsky SGS model.

Reference:

    Smagorinsky, J. (1963).
    General circulation experiments with the primitive equations: I.
    The basic experiment*.
    Monthly weather review, 91(3), 99-164.

The form of the Smagorinsky model implemented is obtained from the k-equation model assuming local equilibrium which provides estimates of both k and epsilon separate from the sub-grid scale viscosity:

    B = 2/3*k*I - 2*nuSgs*dev(D)

where

    D = symm(grad(U));
    k from D:B + Ce*k^3/2/delta = 0
    nuSgs = Ck*sqrt(k)*delta

The default model coefficients are

    SmagorinskyCoeffs
    {
        Ck                  0.094;
        Ce                  1.048;
    }

See also: Foam::LESModels::kEqn

Source files

Definition at line 86 of file Smagorinsky.H.

Member Typedef Documentation

◆ alphaField

typedef BasicMomentumTransportModel::alphaField alphaField

Definition at line 104 of file Smagorinsky.H.

◆ rhoField

typedef BasicMomentumTransportModel::rhoField rhoField

Definition at line 105 of file Smagorinsky.H.

Constructor & Destructor Documentation

◆ Smagorinsky() [1/2]

Smagorinsky	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity,
		const word &	type = `typeName`
	)

Construct from components.

Definition at line 73 of file Smagorinsky.C.

◆ Smagorinsky() [2/2]

Smagorinsky ( const Smagorinsky< BasicMomentumTransportModel > & )

delete

Disallow default bitwise copy construction.

◆ ~Smagorinsky()

virtual ~Smagorinsky ( )

inlinevirtual

Destructor.

Definition at line 131 of file Smagorinsky.H.

Member Function Documentation

◆ k() [1/2]

tmp< volScalarField > k ( const tmp< volTensorField > & gradU ) const

protected

Return SGS kinetic energy.

calculated from the given velocity gradient

Definition at line 40 of file Smagorinsky.C.

References b, Foam::constant::universal::c, Foam::saturationModels::D, delta, Foam::dev(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), Foam::sqr(), Foam::sqrt(), Foam::symm(), and Foam::tr().

Here is the call graph for this function:

◆ correctNut()

void correctNut

protectedvirtual

Update the SGS eddy viscosity.

Implements eddyViscosity< LESModel< BasicMomentumTransportModel > >.

Reimplemented in SmagorinskyZhang< BasicMomentumTransportModel >.

Definition at line 60 of file Smagorinsky.C.

References delta, Foam::fvc::grad(), k, dictionary::New(), and Foam::sqrt().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "Smagorinsky< BasicMomentumTransportModel >" )

Runtime type information.

◆ read()

bool read

virtual

Read model coefficients if they have changed.

Reimplemented from LESeddyViscosity< BasicMomentumTransportModel >.

Reimplemented in SmagorinskyZhang< BasicMomentumTransportModel >.

Definition at line 100 of file Smagorinsky.C.

References LESeddyViscosity< BasicMomentumTransportModel >::read().

Here is the call graph for this function:

◆ k() [2/2]

virtual tmp<volScalarField> k ( ) const

inlinevirtual

Return SGS kinetic energy.

Implements eddyViscosity< LESModel< BasicMomentumTransportModel > >.

Definition at line 141 of file Smagorinsky.H.

References Foam::fvc::grad().

Here is the call graph for this function:

◆ correct()

void correct

virtual

Correct Eddy-Viscosity and related properties.

Implements eddyViscosity< LESModel< BasicMomentumTransportModel > >.

Definition at line 107 of file Smagorinsky.C.

References eddyViscosity< LESModel< BasicMomentumTransportModel > >::correct().

Here is the call graph for this function:

◆ operator=()

void operator= ( const Smagorinsky< BasicMomentumTransportModel > & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/MomentumTransportModels/momentumTransportModels/LES/Smagorinsky/Smagorinsky.H
src/MomentumTransportModels/momentumTransportModels/LES/Smagorinsky/Smagorinsky.C
