Binary diffusion coefficient polynomial function of the log of temperature correcting the standard kinetic theory temperature dependence. More...

Inheritance diagram for binaryDiffusionCoefficient:

[legend]

Collaboration diagram for binaryDiffusionCoefficient:

[legend]

Public Member Functions
	TypeName ("binaryDiffusionCoefficient")
	Runtime type information. More...

	binaryDiffusionCoefficient (const word &name, const Polynomial< 5 > coeffs)
	Construct from name and coefficients. More...

	binaryDiffusionCoefficient (const word &name, const unitConversions &units, const dictionary &dict)
	Construct from name and dictionary. More...

virtual tmp< Function2< scalar > >	clone () const
	Construct and return a clone. More...

virtual scalar	value (scalar p, scalar T) const
	Binary diffusion coefficient function of pressure and temperature. More...

virtual void	write (Ostream &os, const unitConversions &units) const
	Write the function coefficients. More...

Public Member Functions inherited from FieldFunction2< scalar, binaryDiffusionCoefficient >
	FieldFunction2 (const word &name)
	Construct from name. More...

virtual	~FieldFunction2 ()
	Destructor. More...

virtual tmp< Field< scalar > >	value (const scalarField &x, const scalarField &y) const
	Return value as a function of two scalar fields. More...

Public Member Functions inherited from Function2< Type >
	TypeName ("Function2")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, Function2, dictionary,(const word &name, const Function2s::unitConversions &units, const dictionary &dict),(name, units, dict))

	declareRunTimeSelectionTable (autoPtr, Function2, Istream,(const word &name, const Function2s::unitConversions &units, Istream &is),(name, units, is))

	Function2 (const word &name)
	Construct from name. More...

	Function2 (const Function2< Type > &f2)
	Copy constructor. More...

virtual	~Function2 ()
	Destructor. More...

const word &	name () const
	Return the name of the entry. More...

void	operator= (const Function2< Type > &)
	Assignment. More...

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Additional Inherited Members
Public Types inherited from Function2< Type >
typedef Type	returnType

Static Public Member Functions inherited from Function2< Type >
static autoPtr< Function2< Type > >	New (const word &name, const Function2s::unitConversions &units, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function2< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &yUnits, const unitConversion &valueUnits, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function2< Type > >	New (const word &name, const Function2s::unitConversions &units, const word &Function2Type, Istream &is)
	Select from Istream. More...

static autoPtr< Function2< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &yUnits, const unitConversion &valueUnits, const word &Function2Type, Istream &is)
	Select from Istream. More...

Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Protected Attributes inherited from Function2< Type >
const word	name_
	Name of entry. More...

Detailed Description

Binary diffusion coefficient polynomial function of the log of temperature correcting the standard kinetic theory temperature dependence.

    Dji = T^(3/2)*(c0 + c1*lnT + c2*lnT^2 + c3*lnT^3 + c4*lnT^4)/p

Source files

Definition at line 56 of file binaryDiffusionCoefficient.H.

Constructor & Destructor Documentation

◆ binaryDiffusionCoefficient() [1/2]

binaryDiffusionCoefficient	(	const word &	name,
		const Polynomial< 5 >	coeffs
	)

Construct from name and coefficients.

Definition at line 42 of file binaryDiffusionCoefficient.C.

Referenced by binaryDiffusionCoefficient::clone().

Here is the caller graph for this function:

◆ binaryDiffusionCoefficient() [2/2]

binaryDiffusionCoefficient	(	const word &	name,
		const unitConversions &	units,
		const dictionary &	dict
	)

Construct from name and dictionary.

Definition at line 53 of file binaryDiffusionCoefficient.C.

Member Function Documentation

◆ TypeName()

TypeName ( "binaryDiffusionCoefficient" )

Runtime type information.

◆ clone()

virtual tmp<Function2<scalar> > clone ( ) const

inlinevirtual

Construct and return a clone.

Reimplemented from FieldFunction2< scalar, binaryDiffusionCoefficient >.

Definition at line 90 of file binaryDiffusionCoefficient.H.

References binaryDiffusionCoefficient::binaryDiffusionCoefficient().

Here is the call graph for this function:

◆ value()

virtual scalar value	(	scalar	p,
		scalar	T
	)		const

inlinevirtual

Binary diffusion coefficient function of pressure and temperature.

Implements FieldFunction2< scalar, binaryDiffusionCoefficient >.

Definition at line 102 of file binaryDiffusionCoefficient.H.

References Foam::log(), p, Foam::sqrt(), Foam::T(), and Polynomial< PolySize >::value().

Here is the call graph for this function:

◆ write()

void write	(	Ostream &	os,
		const unitConversions &	units
	)		const

virtual

Write the function coefficients.

Implements Function2< Type >.

Definition at line 67 of file binaryDiffusionCoefficient.C.

References Foam::writeEntry().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/thermophysicalModels/specie/thermophysicalFunctions/binaryDiffusionCoefficient/binaryDiffusionCoefficient.H
src/thermophysicalModels/specie/thermophysicalFunctions/binaryDiffusionCoefficient/binaryDiffusionCoefficient.C
