Run-time selectable function of two variables. More...

Inheritance diagram for Function2< Type >:

[legend]

Collaboration diagram for Function2< Type >:

Public Types
typedef Type	returnType

Public Member Functions
	TypeName ("Function2")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, Function2, dictionary,(const word &name, const Function2s::unitConversions &units, const dictionary &dict),(name, units, dict))

	declareRunTimeSelectionTable (autoPtr, Function2, Istream,(const word &name, const Function2s::unitConversions &units, Istream &is),(name, units, is))

	Function2 (const word &name)
	Construct from name. More...

	Function2 (const Function2< Type > &f2)
	Copy constructor. More...

virtual tmp< Function2< Type > >	clone () const =0
	Construct and return a clone. More...

virtual	~Function2 ()
	Destructor. More...

const word &	name () const
	Return the name of the entry. More...

virtual Type	value (const scalar x, const scalar y) const =0
	Return value as a function of two scalars. More...

virtual tmp< Field< Type > >	value (const scalarField &x, const scalarField &y) const =0
	Return value as a function of two scalar fields. More...

virtual void	write (Ostream &os, const Function2s::unitConversions &) const =0
	Write in dictionary format. More...

void	operator= (const Function2< Type > &)
	Assignment. More...

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Static Public Member Functions
static autoPtr< Function2< Type > >	New (const word &name, const Function2s::unitConversions &units, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function2< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &yUnits, const unitConversion &valueUnits, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function2< Type > >	New (const word &name, const Function2s::unitConversions &units, const word &Function2Type, Istream &is)
	Select from Istream. More...

static autoPtr< Function2< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &yUnits, const unitConversion &valueUnits, const word &Function2Type, Istream &is)
	Select from Istream. More...

Protected Attributes
const word	name_
	Name of entry. More...

Friends
Ostream &	operator (Ostream &os, const Function2< Type > &func)
	Ostream Operator. More...

Additional Inherited Members
Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Detailed Description

template<class Type>
class Foam::Function2< Type >

Run-time selectable function of two variables.

with many options provided from simple constant values to complex functions, interpolated tabulated data etc. etc.

Source files

Definition at line 95 of file Function2.H.

Member Typedef Documentation

◆ returnType

typedef Type returnType

Definition at line 110 of file Function2.H.

Constructor & Destructor Documentation

◆ Function2() [1/2]

Function2 ( const word & name )

Construct from name.

Definition at line 31 of file Function2.C.

◆ Function2() [2/2]

Function2 ( const Function2< Type > & f2 )

Copy constructor.

Definition at line 38 of file Function2.C.

◆ ~Function2()

~Function2

virtual

Destructor.

Definition at line 66 of file Function2.C.

Member Function Documentation

◆ TypeName()

TypeName ( "Function2< Type >" )

Runtime type information.

◆ declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable	(	autoPtr	,
		Function2< Type >	,
		dictionary	,
		(const word &name, const Function2s::unitConversions &units, const dictionary &dict)	,
		(name, units, dict)
	)

◆ declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable	(	autoPtr	,
		Function2< Type >	,
		Istream	,
		(const word &name, const Function2s::unitConversions &units, Istream &is)	,
		(name, units, is)
	)

◆ clone()

virtual tmp<Function2<Type> > clone ( ) const

pure virtual

Construct and return a clone.

◆ New() [1/4]

Foam::autoPtr< Foam::Function2< Type > > New	(	const word &	name,
		const Function2s::unitConversions &	units,
		const dictionary &	dict
	)

static

Select from dictionary.

Definition at line 31 of file Function2New.C.

References dict, IOstream::eof(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, token::isWord(), dictionary::lookup(), Foam::name(), Foam::compressible::New(), Foam::nl, Istream::putBack(), and Foam::units().

Referenced by Coded< Type >::Coded(), swirlFlowRateInletVelocityFvPatchVectorField::swirlFlowRateInletVelocityFvPatchVectorField(), and swirlInletVelocityFvPatchVectorField::swirlInletVelocityFvPatchVectorField().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ New() [2/4]

Foam::autoPtr< Foam::Function2< Type > > New	(	const word &	name,
		const unitConversion &	xUnits,
		const unitConversion &	yUnits,
		const unitConversion &	valueUnits,
		const dictionary &	dict
	)

static

Select from dictionary.

Definition at line 100 of file Function2New.C.

References dict, Foam::name(), and Foam::compressible::New().

Here is the call graph for this function:

◆ New() [3/4]

Foam::autoPtr< Foam::Function2< Type > > New	(	const word &	name,
		const Function2s::unitConversions &	units,
		const word &	Function2Type,
		Istream &	is
	)

static

Select from Istream.

Definition at line 114 of file Function2New.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::name(), Foam::nl, and Foam::units().

Here is the call graph for this function:

◆ New() [4/4]

Foam::autoPtr< Foam::Function2< Type > > New	(	const word &	name,
		const unitConversion &	xUnits,
		const unitConversion &	yUnits,
		const unitConversion &	valueUnits,
		const word &	Function2Type,
		Istream &	is
	)

static

Select from Istream.

Definition at line 157 of file Function2New.C.

References Foam::name(), and Foam::compressible::New().

Here is the call graph for this function:

◆ name()

const Foam::word & name

Return the name of the entry.

Definition at line 78 of file Function2.C.

Referenced by Foam::writeEntry().

Here is the caller graph for this function:

◆ value() [1/2]

virtual Type value	(	const scalar	x,
		const scalar	y
	)		const

pure virtual

◆ value() [2/2]

virtual tmp<Field<Type> > value	(	const scalarField &	x,
		const scalarField &	y
	)		const

pure virtual

Return value as a function of two scalar fields.

◆ write()

virtual void write	(	Ostream &	os,
		const Function2s::unitConversions &
	)		const

pure virtual

Write in dictionary format.

Implemented in binaryDiffusionCoefficient, APIdiffCoef, ZeroConstant< Type >, UniformTable< Type >, UniformTable< scalar >, Scale< Type >, Radial< Type >, Product< Type >, OneConstant< Type >, None< Type >, Function12< Type >, Constant< Type >, and Coded< Type >.

Referenced by Foam::writeEntry().

Here is the caller graph for this function:

◆ operator=()

void operator= ( const Function2< Type > & f )

Assignment.

Definition at line 106 of file Function2.C.

References Foam::abort(), f(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator

Ostream& operator	(	Ostream &	os,
		const Function2< Type > &	func
	)

friend

Ostream Operator.

Member Data Documentation

◆ name_

const word name_

protected

Name of entry.

Definition at line 105 of file Function2.H.

Referenced by UniformTable< Type >::UniformTable().

The documentation for this class was generated from the following files:

src/OpenFOAM/primitives/functions/Function2/Function2/Function2.H
src/OpenFOAM/primitives/functions/Function2/Function2/Function2.C
src/OpenFOAM/primitives/functions/Function2/Function2/Function2New.C
