Non-uniform tabulated property function that linearly interpolates between the values. More...

Inheritance diagram for integratedNonUniformTable:

Collaboration diagram for integratedNonUniformTable:

Public Member Functions
	TypeName ("integratedNonUniformTable")
	Runtime type information. More...

	integratedNonUniformTable (const word &name, const unitConversions &units, const dictionary &dict)
	Construct from entry name and dictionary. More...

scalar	intfdT (scalar T) const
	Integrate the function and return the result. More...

scalar	intfByTdT (scalar T) const
	Integrate the function divided by T and return the result. More...

void	write (Ostream &os, const unitConversions &units) const
	Write the function coefficients. More...

Public Member Functions inherited from NonUniformTable< scalar >
	TypeName ("nonUniformTable")
	Runtime type information. More...

	NonUniformTable (const word &name, const Function1s::unitConversions &units, const dictionary &dict)
	Construct from name and dictionary. More...

	NonUniformTable (const NonUniformTable< scalar > &nut)
	Copy constructor. More...

const List< Tuple2< scalar, scalar > > &	values () const
	Return the non-uniform table of values. More...

virtual scalar	value (scalar x) const
	Evaluate the function and return the result. More...

virtual scalar	integral (const scalar x1, const scalar x2) const
	Integrate between two scalar values. More...

scalar	dfdT (scalar T) const
	Evaluate the derivative of the function and return the result. More...

void	write (Ostream &os, const unitConversions &units) const
	Write the function coefficients. More...

void	operator= (const NonUniformTable< scalar > &)
	Assignment. More...

Public Member Functions inherited from FieldFunction1< Type, Function1Type >
	FieldFunction1 (const word &name)
	Construct from name. More...

virtual tmp< Function1< Type > >	clone () const
	Construct and return a clone. More...

virtual	~FieldFunction1 ()
	Destructor. More...

virtual tmp< Field< Type > >	value (const scalarField &x) const
	Return value as a function of one scalar field. More...

virtual tmp< Field< Type > >	integral (const scalarField &x1, const scalarField &x2) const
	Integrate between two scalar fields. More...

Public Member Functions inherited from Function1< Type >
	TypeName ("Function1")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, Function1, dictionary,(const word &name, const Function1s::unitConversions &units, const dictionary &dict),(name, units, dict))

	declareRunTimeSelectionTable (autoPtr, Function1, Istream,(const word &name, const Function1s::unitConversions &units, Istream &is),(name, units, is))

	Function1 (const word &name)
	Construct from name. More...

	Function1 (const Function1< Type > &f1)
	Copy constructor. More...

virtual	~Function1 ()
	Destructor. More...

const word &	name () const
	Return the name of the entry. More...

virtual bool	constant () const
	Is this function guaranteed to be constant? More...

void	operator= (const Function1< Type > &)
	Assignment. More...

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Additional Inherited Members
Public Types inherited from Function1< Type >
typedef Type	returnType

Static Public Member Functions inherited from Function1< Type >
static autoPtr< Function1< Type > >	New (const word &name, const Function1s::unitConversions &units, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function1< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &valueUnits, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function1< Type > >	New (const word &name, const Function1s::unitConversions &units, const word &Function1Type, Istream &is)
	Select from Istream. More...

static autoPtr< Function1< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &valueUnits, const word &Function1Type, Istream &is)
	Select from Istream. More...

Protected Member Functions inherited from NonUniformTable< scalar >
label	index (scalar x) const
	Return the lower index of the interval in the table. More...

Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Protected Attributes inherited from Function1< Type >
const word	name_
	Name of entry. More...

Detailed Description

Non-uniform tabulated property function that linearly interpolates between the values.

To speed-up the search of the non-uniform table a uniform jump-table is created on construction which is used for fast indirect addressing into the table.

Usage

Property	Description
`values`	List of value pairs

Example for the density of water between 280 and 350K

    rho
    {
        type    integratedNonUniformTable;

        values
        (
            (280 999.87)
            (300 995.1)
            (350 973.7)
        );
    }

Definition at line 79 of file integratedNonUniformTable1.H.

Constructor & Destructor Documentation

◆ integratedNonUniformTable()

integratedNonUniformTable	(	const word &	name,
		const unitConversions &	units,
		const dictionary &	dict
	)

Construct from entry name and dictionary.

Definition at line 43 of file integratedNonUniformTable1.C.

References Foam::assertNoConvertUnits(), dict, Foam::first(), forAll, integratedNonUniformTable::intfByTdT(), integratedNonUniformTable::intfdT(), List< T >::size(), Foam::constant::standard::Tstd, Foam::units(), and NonUniformTable< scalar >::values().

Here is the call graph for this function:

Member Function Documentation

◆ TypeName()

TypeName ( "integratedNonUniformTable" )

Runtime type information.

◆ intfdT()

Foam::scalar intfdT ( scalar T ) const

Integrate the function and return the result.

Definition at line 78 of file integratedNonUniformTable1.C.

References lambda(), and Foam::T().

Referenced by integratedNonUniformTable::integratedNonUniformTable().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ intfByTdT()

Foam::scalar intfByTdT ( scalar T ) const

Integrate the function divided by T and return the result.

Definition at line 95 of file integratedNonUniformTable1.C.

References Foam::log(), and Foam::T().

Referenced by integratedNonUniformTable::integratedNonUniformTable().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ write()

void write	(	Ostream &	os,
		const unitConversions &	units
	)		const

virtual

Write the function coefficients.

Implements Function1< Type >.

Definition at line 111 of file integratedNonUniformTable1.C.

References Foam::units(), and NonUniformTable< Type >::write().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/thermophysicalModels/specie/thermophysicalFunctions/integratedNonUniformTable1/integratedNonUniformTable1.H
src/thermophysicalModels/specie/thermophysicalFunctions/integratedNonUniformTable1/integratedNonUniformTable1.C
