Records particle face quantities on used-specified face zone. More...

Inheritance diagram for FacePostProcessing< CloudType >:

Collaboration diagram for FacePostProcessing< CloudType >:

Public Member Functions
	TypeName ("facePostProcessing")
	Runtime type information. More...

	FacePostProcessing (const dictionary &dict, CloudType &owner, const word &modelName)
	Construct from dictionary. More...

	FacePostProcessing (const FacePostProcessing< CloudType > &ppm)
	Construct copy. More...

virtual autoPtr< CloudFunctionObject< CloudType > >	clone () const
	Construct and return a clone. More...

virtual	~FacePostProcessing ()
	Destructor. More...

const Switch &	resetOnWrite () const
	Return const access to the reset on write flag. More...

virtual void	postPatch (const parcelType &p, const polyPatch &pp)
	Post-patch hook. More...

virtual void	preFace (const parcelType &p)
	Post-face hook. More...

Public Member Functions inherited from CloudFunctionObject< CloudType >
	TypeName ("cloudFunctionObject")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, CloudFunctionObject, dictionary,(const dictionary &dict, CloudType &owner, const word &modelName),(dict, owner, modelName))
	Declare runtime constructor selection table. More...

	CloudFunctionObject (CloudType &owner)
	Construct null from owner. More...

	CloudFunctionObject (const dictionary &dict, CloudType &owner, const word &objectType, const word &modelName)
	Construct from dictionary. More...

	CloudFunctionObject (const CloudFunctionObject< CloudType > &ppm)
	Construct copy. More...

virtual	~CloudFunctionObject ()
	Destructor. More...

virtual void	preEvolve ()
	Pre-evolve hook. More...

virtual void	postEvolve ()
	Post-evolve hook. More...

virtual void	postMove (typename CloudType::parcelType &p, const scalar dt, const point &position0, bool &keepParticle)
	Post-move hook. More...

virtual void	postPatch (const typename CloudType::parcelType &p, const polyPatch &pp)
	Post-patch hook. More...

virtual void	preFace (const typename CloudType::parcelType &p)
	Pre-face hook. More...

virtual void	postFace (const typename CloudType::parcelType &p)
	Post-face hook. More...

const fileName &	outputDir () const
	Return the output path. More...

fileName	writeTimeDir () const
	Return the output time path. More...

Public Member Functions inherited from CloudSubModelBase< CloudType >
	CloudSubModelBase (CloudType &owner)
	Construct null from owner cloud. More...

	CloudSubModelBase (CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from owner cloud without name. More...

	CloudSubModelBase (const word &modelName, CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from owner cloud with name. More...

	CloudSubModelBase (const CloudSubModelBase< CloudType > &smb)
	Copy constructor. More...

virtual	~CloudSubModelBase ()
	Destructor. More...

const CloudType &	owner () const
	Return const access to the owner cloud. More...

virtual bool	writeTime () const
	Flag to indicate when to write a property. More...

CloudType &	owner ()
	Return non-const access to the owner cloud for manipulation. More...

virtual void	write (Ostream &os) const
	Write. More...

Public Member Functions inherited from subModelBase
	subModelBase (dictionary &properties)
	Construct null. More...

	subModelBase (dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from components without name. More...

	subModelBase (const word &modelName, dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from components with name. More...

	subModelBase (const subModelBase &smb)
	Copy constructor. More...

virtual	~subModelBase ()
	Destructor. More...

const word &	modelName () const
	Return const access to the name of the sub-model. More...

const dictionary &	dict () const
	Return const access to the cloud dictionary. More...

const word &	baseName () const
	Return const access to the base name of the sub-model. More...

const word &	modelType () const
	Return const access to the sub-model type. More...

const dictionary &	coeffDict () const
	Return const access to the coefficients dictionary. More...

const dictionary &	properties () const
	Return const access to the properties dictionary. More...

virtual bool	defaultCoeffs (const bool printMsg) const
	Returns true if defaultCoeffs is true and outputs on printMsg. More...

virtual void	cacheFields (const bool store)
	Cache dependent sub-model fields. More...

template<class Type >
Type	getBaseProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the base model. More...

template<class Type >
void	getBaseProperty (const word &entryName, Type &value) const
	Retrieve generic property from the base model. More...

template<class Type >
void	setBaseProperty (const word &entryName, const Type &value)
	Add generic property to the base model. More...

template<class Type >
void	getModelProperty (const word &entryName, Type &value) const
	Retrieve generic property from the sub-model. More...

template<class Type >
Type	getModelProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the sub-model. More...

template<class Type >
void	setModelProperty (const word &entryName, const Type &value)
	Add generic property to the sub-model. More...

void	operator= (const subModelBase &)=delete
	Disallow default bitwise assignment. More...

Protected Member Functions
void	write ()
	Write post-processing info. More...

Protected Member Functions inherited from subModelBase
bool	inLine () const
	Flag to indicate whether data is/was read in-line. More...

Additional Inherited Members
Public Types inherited from CloudSubModelBase< CloudType >
typedef CloudType	cloudType
	Type of cloud this model was instantiated for. More...

Static Public Member Functions inherited from CloudFunctionObject< CloudType >
static autoPtr< CloudFunctionObject< CloudType > >	New (const dictionary &dict, CloudType &owner, const word &objectType, const word &modelName)
	Selector. More...

Protected Attributes inherited from CloudSubModelBase< CloudType >
CloudType &	owner_
	Reference to the cloud. More...

Protected Attributes inherited from subModelBase
const word	modelName_
	Name of the sub-model. More...

dictionary &	properties_
	Reference to properties dictionary e.g. for restart. More...

const dictionary	dict_
	Copy of dictionary used during construction. More...

const word	baseName_
	Name of the sub-model base class. More...

const word	modelType_
	Type of the sub-model. More...

const dictionary	coeffDict_
	Coefficients dictionary. More...

Detailed Description

template<class CloudType>
class Foam::FacePostProcessing< CloudType >

Records particle face quantities on used-specified face zone.

Currently supports: accumulated mass average mass flux

Source files

Definition at line 54 of file FacePostProcessing.H.

Constructor & Destructor Documentation

◆ FacePostProcessing() [1/2]

FacePostProcessing	(	const dictionary &	dict,
		CloudType &	owner,
		const word &	modelName
	)

Construct from dictionary.

Definition at line 240 of file FacePostProcessing.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), polyMesh::boundaryMesh(), subModelBase::coeffDict(), polyMesh::faceZones(), PtrListDictionary< T >::findIndex(), forAll, Foam::Info, fvMesh::magSf(), DSMCCloud< ParcelType >::mesh(), primitiveMesh::nInternalFaces(), Foam::nl, CloudSubModelBase< CloudType >::owner(), patchi, polyBoundaryMesh::patchIndices(), Foam::returnReduce(), List< T >::setSize(), List< T >::size(), List< T >::transfer(), and polyPatch::whichFace().

Here is the call graph for this function:

◆ FacePostProcessing() [2/2]

FacePostProcessing ( const FacePostProcessing< CloudType > & ppm )

Construct copy.

Definition at line 323 of file FacePostProcessing.C.

◆ ~FacePostProcessing()

~FacePostProcessing

virtual

Destructor.

Definition at line 345 of file FacePostProcessing.C.

Member Function Documentation

◆ write()

void write

protectedvirtual

Write post-processing info.

Reimplemented from CloudFunctionObject< CloudType >.

Definition at line 81 of file FacePostProcessing.C.

References alpha(), Foam::endl(), polyMesh::faceZones(), forAll, polyMesh::globalData(), Foam::Info, Foam::inplaceRenumber(), PrimitivePatch< FaceList, PointField >::localFaces(), globalMeshData::mergePoints(), fvMesh::mesh(), mesh, PrimitivePatch< FaceList, PointField >::meshPointMap(), PrimitivePatch< FaceList, PointField >::meshPoints(), IOobject::name(), dimensioned< Type >::name(), Zone< ZoneType, ZonesType >::name(), Foam::compressible::New(), Foam::nl, faceZone::patch(), polyMesh::points(), Foam::sum(), fvMesh::time(), Foam::type(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "facePostProcessing" )

Runtime type information.

◆ clone()

virtual autoPtr<CloudFunctionObject<CloudType> > clone ( ) const

inlinevirtual

Construct and return a clone.

Reimplemented from CloudFunctionObject< CloudType >.

Definition at line 137 of file FacePostProcessing.H.

◆ resetOnWrite()

const Foam::Switch & resetOnWrite

inline

Return const access to the reset on write flag.

Definition at line 28 of file FacePostProcessingI.H.

◆ postPatch()

void postPatch	(	const parcelType &	p,
		const polyPatch &	pp
	)

virtual

Post-patch hook.

Definition at line 386 of file FacePostProcessing.C.

References polyPatch::coupled(), and p.

Here is the call graph for this function:

◆ preFace()

void preFace ( const parcelType & p )

virtual

Post-face hook.

Definition at line 352 of file FacePostProcessing.C.

References faceId(), polyMesh::faceZones(), forAll, ZoneList< ZoneType, ZonesType, MeshType >::mesh(), and p.

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/lagrangian/parcel/submodels/CloudFunctionObjects/FacePostProcessing/FacePostProcessing.H
src/lagrangian/parcel/submodels/CloudFunctionObjects/FacePostProcessing/FacePostProcessing.C
src/lagrangian/parcel/submodels/CloudFunctionObjects/FacePostProcessing/FacePostProcessingI.H
