Templated 2D Barycentric derived from VectorSpace. Has 3 components, one of which is redundant. More...

Inheritance diagram for Barycentric2D< Cmpt >:

Collaboration diagram for Barycentric2D< Cmpt >:

Public Types
enum	components { A , B , C }
	Component labeling enumeration. More...

typedef Barycentric2D< label >	labelType
	Equivalent type of labels used for valid component indexing. More...

Public Types inherited from VectorSpace< Barycentric2D< Cmpt >, Cmpt, 3 >
typedef VectorSpace< Barycentric2D< Cmpt >, Cmpt, Ncmpts >	vsType
	VectorSpace type. More...

typedef Cmpt	cmptType
	Component type. More...

Public Member Functions
	Barycentric2D ()
	Construct null. More...

	Barycentric2D (const Foam::zero)
	Construct initialised to zero. More...

	Barycentric2D (const Cmpt &va, const Cmpt &vb, const Cmpt &vc)
	Construct given four components. More...

const Cmpt &	a () const

const Cmpt &	b () const

const Cmpt &	c () const

Cmpt &	a ()

Cmpt &	b ()

Cmpt &	c ()

Public Member Functions inherited from VectorSpace< Barycentric2D< Cmpt >, Cmpt, 3 >
	VectorSpace ()
	Construct null. More...

	VectorSpace (const Foam::zero)
	Construct initialised to zero. More...

	VectorSpace (Istream &)
	Construct from Istream. More...

	VectorSpace (const VectorSpace< Form2, Cmpt2, Ncmpts > &)
	Construct as copy of a VectorSpace with the same size. More...

const Cmpt &	component (const direction) const

Cmpt &	component (const direction)

void	component (Cmpt &, const direction) const

void	replace (const direction, const Cmpt &)

const ConstBlock< SubVector, BStart >	block () const

const VectorSpace< Barycentric2D< Cmpt >, Cmpt, Ncmpts >::template ConstBlock< SubVector, BStart >	block () const

const Cmpt &	operator[] (const direction) const

Cmpt &	operator[] (const direction)

void	operator+= (const VectorSpace< Barycentric2D< Cmpt >, Cmpt, Ncmpts > &)

void	operator-= (const VectorSpace< Barycentric2D< Cmpt >, Cmpt, Ncmpts > &)

void	operator= (const Foam::zero)

void	operator*= (const Type)

void	operator/= (const Type)

Static Public Attributes
static const direction	rank = 1
	Rank of Barycentric2D is 1. More...

Static Public Attributes inherited from VectorSpace< Barycentric2D< Cmpt >, Cmpt, 3 >
static const direction	dim
	Dimensionality of space. More...

static const direction	nComponents
	Number of components in this vector space. More...

static const direction	mRows

static const direction	nCols

static const char *const	typeName

static const char *const	componentNames []

static const Barycentric2D< Cmpt >	zero

static const Barycentric2D< Cmpt >	one

static const Barycentric2D< Cmpt >	max

static const Barycentric2D< Cmpt >	min

static const Barycentric2D< Cmpt >	rootMax

static const Barycentric2D< Cmpt >	rootMin

static const Barycentric2D< Cmpt >	nan

Additional Inherited Members
Static Public Member Functions inherited from VectorSpace< Barycentric2D< Cmpt >, Cmpt, 3 >
static direction	size ()
	Return the number of elements in the VectorSpace = Ncmpts. More...

static Barycentric2D< Cmpt >	uniform (const Cmpt &s)
	Return a VectorSpace with all elements = s. More...

Public Attributes inherited from VectorSpace< Barycentric2D< Cmpt >, Cmpt, 3 >
Cmpt	v_ [Ncmpts]
	The components of this vector space. More...
