Stabilisation source for phase transport equations. More...

Inheritance diagram for phaseLimitStabilisation:

Collaboration diagram for phaseLimitStabilisation:

Public Member Functions
	TypeName ("phaseLimitStabilisation")
	Runtime type information. More...

	phaseLimitStabilisation (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)
	Construct from components. More...

	phaseLimitStabilisation (const phaseLimitStabilisation &)=delete
	Disallow default bitwise copy construction. More...

virtual	~phaseLimitStabilisation ()
	Destructor. More...

virtual wordList	addSupFields () const
	Return the list of fields for which the fvModel adds source term. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_MODEL_ADD_ALPHA_RHO_SUP)
	Add a source term to a phase equation. More...

virtual bool	movePoints ()
	Update for mesh motion. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

virtual bool	read (const dictionary &dict)
	Read dictionary. More...

void	operator= (const phaseLimitStabilisation &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvModel
	TypeName ("fvModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvModel, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh),(name, modelType, dict, mesh))

	fvModel (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh)
	Construct from components. More...

autoPtr< fvModel >	clone () const
	Return clone. More...

virtual	~fvModel ()
	Destructor. More...

const word &	name () const
	Return const access to the source name. More...

const fvMesh &	mesh () const
	Return const access to the mesh database. More...

const dictionary &	coeffs () const
	Return dictionary. More...

virtual bool	addsSupToField (const word &fieldName) const
	Return true if the fvModel adds a source term to the given. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_MODEL_ADD_SUP)
	Add a source term to an equation. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_MODEL_ADD_RHO_SUP)
	Add a source term to a compressible equation. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_MODEL_ADD_ALPHA_RHO_SUP)
	Add a source term to a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const GeometricField< Type, fvPatchField, volMesh > &field) const
	Return source for an equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const
	Return source for an equation with a specified name. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field) const
	Return source for a compressible equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const
	Return source for a compressible equation with a specified name. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field) const
	Return source for a phase equation. More...

template<class Type >
tmp< fvMatrix< Type > >	source (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const
	Return source for a phase equation with a specified name. More...

virtual void	preUpdateMesh ()
	Prepare for mesh update. More...

virtual void	correct ()
	Correct the fvModel. More...

template<class Type , class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
Foam::dimensionSet	sourceDims (const GeometricField< Type, fvPatchField, volMesh > &field, const dimensionSet &ds, const AlphaRhoFieldType &alphaRho, const AlphaRhoFieldTypes &... alphaRhos)

template<class Type >
Foam::dimensionSet	sourceDims (const GeometricField< Type, fvPatchField, volMesh > &field, const dimensionSet &ds)

template<class Type , class ... AlphaRhoFieldTypes>
Foam::tmp< Foam::fvMatrix< Type > >	source (const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName, const dimensionSet &ds, const AlphaRhoFieldTypes &... alphaRhos) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const GeometricField< Type, fvPatchField, volMesh > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field) const

template<class Type >
Foam::tmp< Foam::fvMatrix< Type > >	source (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const

Additional Inherited Members
Static Public Member Functions inherited from fvModel
template<class Type , class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static dimensionSet	sourceDims (const GeometricField< Type, fvPatchField, volMesh > &field, const dimensionSet &ds, const AlphaRhoFieldType &alphaRho, const AlphaRhoFieldTypes &... alphaRhos)
	Return the dimensions of the matrix of a source term. More...

template<class Type >
static dimensionSet	sourceDims (const GeometricField< Type, fvPatchField, volMesh > &field, const dimensionSet &ds)
	Return the dimensions of the matrix of a source term (base. More...

static autoPtr< fvModel >	New (const word &name, const dictionary &dict, const fvMesh &mesh)
	Return a reference to the selected fvModel. More...

Protected Member Functions inherited from fvModel
template<class Type >
void	addSupType (fvMatrix< Type > &eqn, const word &fieldName) const
	Add a source term to an equation. More...

template<class Type >
void	addSupType (const volScalarField &rho, fvMatrix< Type > &eqn, const word &fieldName) const
	Add a source term to a compressible equation. More...

template<class Type >
void	addSupType (const volScalarField &alpha, const volScalarField &rho, fvMatrix< Type > &eqn, const word &fieldName) const
	Add a source term to a phase equation. More...

template<class Type , class ... AlphaRhoFieldTypes>
tmp< fvMatrix< Type > >	source (const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName, const dimensionSet &ds, const AlphaRhoFieldTypes &... alphaRhos) const
	Return source for equation with specified name and dimensions. More...

Detailed Description

Stabilisation source for phase transport equations.

Applies an implicit source to the phase transport equation for the specified field when the phase volume fraction is below residualAlpha. The stabilisation rate is provided by the registered uniformDimensionedScalarField rate, which could be extended to also support volScalarField and volScalarField::Internal field types. The field is currently stabilised towards zero in the limit of the phase volume fraction approaching zero but this could be extended to support a specified value or a value or field looked-up from the database.

Usage

Example usage:

stabilisation
{
    type            phaseLimitStabilisation;

    field           sigma.liquid;

    rate            rLambda.liquid;
    residualAlpha   1e-3;
}

Source files

Definition at line 73 of file phaseLimitStabilisation.H.
