Actuation disk source. More...
Public Member Functions | |
TypeName ("actuationDiskSource") | |
Runtime type information. More... | |
actuationDiskSource (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh) | |
Construct from components. More... | |
actuationDiskSource (const actuationDiskSource &)=delete | |
Disallow default bitwise copy construction. More... | |
virtual | ~actuationDiskSource () |
Destructor. More... | |
virtual wordList | addSupFields () const |
Return the list of fields for which the fvModel adds source term. More... | |
virtual void | addSup (fvMatrix< vector > &eqn, const word &fieldName) const |
Source term to momentum equation. More... | |
virtual void | addSup (const volScalarField &rho, fvMatrix< vector > &eqn, const word &fieldName) const |
Source term to compressible momentum equation. More... | |
virtual void | addSup (const volScalarField &alpha, const volScalarField &rho, fvMatrix< vector > &eqn, const word &fieldName) const |
Explicit and implicit sources for phase equations. More... | |
virtual bool | movePoints () |
Update for mesh motion. More... | |
virtual void | topoChange (const polyTopoChangeMap &) |
Update topology using the given map. More... | |
virtual void | mapMesh (const polyMeshMap &) |
Update from another mesh using the given map. More... | |
virtual void | distribute (const polyDistributionMap &) |
Redistribute or update using the given distribution map. More... | |
virtual bool | read (const dictionary &dict) |
Read dictionary. More... | |
void | operator= (const actuationDiskSource &)=delete |
Disallow default bitwise assignment. More... | |
Public Member Functions inherited from fvModel | |
TypeName ("fvModel") | |
Runtime type information. More... | |
declareRunTimeSelectionTable (autoPtr, fvModel, dictionary,(const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh),(name, modelType, dict, mesh)) | |
fvModel (const word &name, const word &modelType, const dictionary &dict, const fvMesh &mesh) | |
Construct from components. More... | |
autoPtr< fvModel > | clone () const |
Return clone. More... | |
virtual | ~fvModel () |
Destructor. More... | |
const word & | name () const |
Return const access to the source name. More... | |
const fvMesh & | mesh () const |
Return const access to the mesh database. More... | |
const dictionary & | coeffs () const |
Return dictionary. More... | |
virtual bool | addsSupToField (const word &fieldName) const |
Return true if the fvModel adds a source term to the given. More... | |
virtual scalar | maxDeltaT () const |
Return the maximum time-step for stable operation. More... | |
FOR_ALL_FIELD_TYPES (DEFINE_FV_MODEL_ADD_SUP) | |
Add a source term to an equation. More... | |
FOR_ALL_FIELD_TYPES (DEFINE_FV_MODEL_ADD_RHO_SUP) | |
Add a source term to a compressible equation. More... | |
FOR_ALL_FIELD_TYPES (DEFINE_FV_MODEL_ADD_ALPHA_RHO_SUP) | |
Add a source term to a phase equation. More... | |
template<class Type > | |
tmp< fvMatrix< Type > > | source (const GeometricField< Type, fvPatchField, volMesh > &field) const |
Return source for an equation. More... | |
template<class Type > | |
tmp< fvMatrix< Type > > | source (const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const |
Return source for an equation with a specified name. More... | |
template<class Type > | |
tmp< fvMatrix< Type > > | source (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field) const |
Return source for a compressible equation. More... | |
template<class Type > | |
tmp< fvMatrix< Type > > | source (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const |
Return source for a compressible equation with a specified name. More... | |
template<class Type > | |
tmp< fvMatrix< Type > > | source (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field) const |
Return source for a phase equation. More... | |
template<class Type > | |
tmp< fvMatrix< Type > > | source (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const |
Return source for a phase equation with a specified name. More... | |
virtual void | preUpdateMesh () |
Prepare for mesh update. More... | |
virtual void | correct () |
Correct the fvModel. More... | |
template<class Type , class AlphaRhoFieldType , class ... AlphaRhoFieldTypes> | |
Foam::dimensionSet | sourceDims (const GeometricField< Type, fvPatchField, volMesh > &field, const dimensionSet &ds, const AlphaRhoFieldType &alphaRho, const AlphaRhoFieldTypes &... alphaRhos) |
template<class Type > | |
Foam::dimensionSet | sourceDims (const GeometricField< Type, fvPatchField, volMesh > &field, const dimensionSet &ds) |
template<class Type , class ... AlphaRhoFieldTypes> | |
Foam::tmp< Foam::fvMatrix< Type > > | source (const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName, const dimensionSet &ds, const AlphaRhoFieldTypes &... alphaRhos) const |
template<class Type > | |
Foam::tmp< Foam::fvMatrix< Type > > | source (const GeometricField< Type, fvPatchField, volMesh > &field) const |
template<class Type > | |
Foam::tmp< Foam::fvMatrix< Type > > | source (const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const |
template<class Type > | |
Foam::tmp< Foam::fvMatrix< Type > > | source (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field) const |
template<class Type > | |
Foam::tmp< Foam::fvMatrix< Type > > | source (const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const |
template<class Type > | |
Foam::tmp< Foam::fvMatrix< Type > > | source (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field) const |
template<class Type > | |
Foam::tmp< Foam::fvMatrix< Type > > | source (const volScalarField &alpha, const volScalarField &rho, const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName) const |
Protected Attributes | |
fvCellSet | set_ |
The set of cells the fvConstraint applies to. More... | |
word | phaseName_ |
The name of the phase to which this fvModel applies. More... | |
word | UName_ |
Name of the velocity field. More... | |
vector | diskDir_ |
Disk area normal. More... | |
scalar | Cp_ |
Power coefficient. More... | |
scalar | Ct_ |
Thrust coefficient. More... | |
scalar | diskArea_ |
Disk area. More... | |
point | upstreamPoint_ |
Upstream point sample. More... | |
label | upstreamCellId_ |
Upstream cell ID. More... | |
Additional Inherited Members | |
Static Public Member Functions inherited from fvModel | |
template<class Type , class AlphaRhoFieldType , class ... AlphaRhoFieldTypes> | |
static dimensionSet | sourceDims (const GeometricField< Type, fvPatchField, volMesh > &field, const dimensionSet &ds, const AlphaRhoFieldType &alphaRho, const AlphaRhoFieldTypes &... alphaRhos) |
Return the dimensions of the matrix of a source term. More... | |
template<class Type > | |
static dimensionSet | sourceDims (const GeometricField< Type, fvPatchField, volMesh > &field, const dimensionSet &ds) |
Return the dimensions of the matrix of a source term (base. More... | |
static autoPtr< fvModel > | New (const word &name, const dictionary &dict, const fvMesh &mesh) |
Return a reference to the selected fvModel. More... | |
Protected Member Functions inherited from fvModel | |
template<class Type > | |
void | addSupType (fvMatrix< Type > &eqn, const word &fieldName) const |
Add a source term to an equation. More... | |
template<class Type > | |
void | addSupType (const volScalarField &rho, fvMatrix< Type > &eqn, const word &fieldName) const |
Add a source term to a compressible equation. More... | |
template<class Type > | |
void | addSupType (const volScalarField &alpha, const volScalarField &rho, fvMatrix< Type > &eqn, const word &fieldName) const |
Add a source term to a phase equation. More... | |
template<class Type , class ... AlphaRhoFieldTypes> | |
tmp< fvMatrix< Type > > | source (const GeometricField< Type, fvPatchField, volMesh > &field, const word &fieldName, const dimensionSet &ds, const AlphaRhoFieldTypes &... alphaRhos) const |
Return source for equation with specified name and dimensions. More... | |
Actuation disk source.
Constant values for momentum source for actuation disk
where:
= | Disk area | |
= | Unit disk direction | |
= | Upstream velocity | |
= | 1 - Cp/Ct | |
= | Power coefficient | |
= | Thrust coefficient |
actuationDiskSource1 { type actuationDiskSource; selectionMode cellSet; cellSet actuationDisk1; diskDir (-1 0 0); // Disk direction Cp 0.1; // Power coefficient Ct 0.5; // Thrust coefficient diskArea 5.0; // Disk area upstreamPoint (0 0 0); // Upstream point }
Definition at line 110 of file actuationDiskSource.H.
actuationDiskSource | ( | const word & | name, |
const word & | modelType, | ||
const dictionary & | dict, | ||
const fvMesh & | mesh | ||
) |
Construct from components.
Definition at line 101 of file actuationDiskSource.C.
|
delete |
Disallow default bitwise copy construction.
|
inlinevirtual |
Destructor.
Definition at line 188 of file actuationDiskSource.H.
References actuationDiskSource::addSup(), actuationDiskSource::addSupFields(), alpha(), dict, actuationDiskSource::distribute(), actuationDiskSource::mapMesh(), actuationDiskSource::movePoints(), actuationDiskSource::operator=(), actuationDiskSource::read(), rho, and actuationDiskSource::topoChange().
TypeName | ( | "actuationDiskSource" | ) |
Runtime type information.
|
virtual |
Return the list of fields for which the fvModel adds source term.
to the transport equation
Reimplemented from fvModel.
Definition at line 125 of file actuationDiskSource.C.
References actuationDiskSource::addSup().
Referenced by actuationDiskSource::~actuationDiskSource().
Source term to momentum equation.
Reimplemented in radialActuationDiskSource.
Definition at line 132 of file actuationDiskSource.C.
References mesh, fvMatrix< Type >::psi(), fvMatrix< Type >::source(), and U.
Referenced by actuationDiskSource::addSup(), actuationDiskSource::addSupFields(), and actuationDiskSource::~actuationDiskSource().
|
virtual |
Source term to compressible momentum equation.
Reimplemented in radialActuationDiskSource.
Definition at line 157 of file actuationDiskSource.C.
References actuationDiskSource::addSup(), mesh, fvMatrix< Type >::psi(), rho, fvMatrix< Type >::source(), and U.
|
virtual |
Explicit and implicit sources for phase equations.
Definition at line 183 of file actuationDiskSource.C.
References alpha(), mesh, fvMatrix< Type >::psi(), rho, fvMatrix< Type >::source(), and U.
|
virtual |
Update for mesh motion.
Implements fvModel.
Definition at line 209 of file actuationDiskSource.C.
Referenced by actuationDiskSource::~actuationDiskSource().
|
virtual |
Update topology using the given map.
Implements fvModel.
Definition at line 216 of file actuationDiskSource.C.
Referenced by actuationDiskSource::~actuationDiskSource().
|
virtual |
Update from another mesh using the given map.
Implements fvModel.
Definition at line 222 of file actuationDiskSource.C.
References actuationDiskSource::distribute().
Referenced by actuationDiskSource::~actuationDiskSource().
|
virtual |
Redistribute or update using the given distribution map.
Implements fvModel.
Definition at line 229 of file actuationDiskSource.C.
Referenced by actuationDiskSource::mapMesh(), and actuationDiskSource::~actuationDiskSource().
|
virtual |
Read dictionary.
Reimplemented from fvModel.
Reimplemented in radialActuationDiskSource.
Definition at line 237 of file actuationDiskSource.C.
References fvModel::read().
Referenced by radialActuationDiskSource::read(), and actuationDiskSource::~actuationDiskSource().
|
delete |
Disallow default bitwise assignment.
Referenced by actuationDiskSource::~actuationDiskSource().
|
protected |
The set of cells the fvConstraint applies to.
Definition at line 119 of file actuationDiskSource.H.
|
protected |
The name of the phase to which this fvModel applies.
Definition at line 122 of file actuationDiskSource.H.
|
protected |
Name of the velocity field.
Definition at line 125 of file actuationDiskSource.H.
|
protected |
Disk area normal.
Definition at line 128 of file actuationDiskSource.H.
|
protected |
Power coefficient.
Definition at line 131 of file actuationDiskSource.H.
|
protected |
Thrust coefficient.
Definition at line 134 of file actuationDiskSource.H.
|
protected |
Disk area.
Definition at line 137 of file actuationDiskSource.H.
|
protected |
Upstream point sample.
Definition at line 140 of file actuationDiskSource.H.
|
protected |
Upstream cell ID.
Definition at line 143 of file actuationDiskSource.H.
