turbulentTemperatureRadCoupledMixedFvPatchScalarField Class Reference

Mixed boundary condition for temperature and radiation heat transfer to be used for in multiregion cases. Optional thin thermal layer resistances can be specified through thicknessLayers and kappaLayers entries. More...

Inheritance diagram for turbulentTemperatureRadCoupledMixedFvPatchScalarField:
Collaboration diagram for turbulentTemperatureRadCoupledMixedFvPatchScalarField:

Public Member Functions

 TypeName ("compressible::turbulentTemperatureRadCoupledMixed")
 Runtime type information. More...

 turbulentTemperatureRadCoupledMixedFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
 Construct from patch and internal field. More...

 turbulentTemperatureRadCoupledMixedFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 turbulentTemperatureRadCoupledMixedFvPatchScalarField (const turbulentTemperatureRadCoupledMixedFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
 Construct by mapping given. More...

 turbulentTemperatureRadCoupledMixedFvPatchScalarField (const turbulentTemperatureRadCoupledMixedFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Construct as copy setting internal field reference. More...

virtual tmp< fvPatchScalarFieldclone (const DimensionedField< scalar, volMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

virtual void updateCoeffs ()
 Update the coefficients associated with the patch field. More...

virtual void write (Ostream &) const
 Write. More...

- Public Member Functions inherited from temperatureCoupledBase
 temperatureCoupledBase (const fvPatch &patch)
 Construct from patch. More...

 temperatureCoupledBase (const fvPatch &patch, const dictionary &dict)
 Construct from patch and dictionary. More...

 temperatureCoupledBase (const fvPatch &patch, const temperatureCoupledBase &base)
 Construct from patch and temperatureCoupledBase. More...

tmp< scalarFieldkappa (const fvPatchScalarField &Tp) const
 Given patch temperature calculate corresponding K field. More...

void write (Ostream &) const
 Write. More...


Detailed Description

Mixed boundary condition for temperature and radiation heat transfer to be used for in multiregion cases. Optional thin thermal layer resistances can be specified through thicknessLayers and kappaLayers entries.

The thermal conductivity kappa can either be retrieved from various possible sources, as detailed in the class temperatureCoupledBase.

Usage
Property Description Required Default value
Tnbr name of the field no T
qrNbr name of the radiative flux in the nbr region no none
qr name of the radiative flux in this region no none
thicknessLayers list of thicknesses per layer [m] no
kappaLayers list of thermal conductivites per layer [W/m/K] no

Example of the boundary condition specification:

    <patchName>
    {
        type            compressible::turbulentTemperatureRadCoupledMixed;
        Tnbr            T;
        qrNbr           qr; // or none. Name of qr field on neighbour region
        qr              qr; // or none. Name of qr field on local region
        thicknessLayers (0.1 0.2 0.3 0.4);
        kappaLayers     (1 2 3 4);
        value           uniform 300;
    }

Needs to be on underlying mapped(Wall)FvPatch.

See also
Foam::temperatureCoupledBase
Source files

Definition at line 117 of file turbulentTemperatureRadCoupledMixedFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ turbulentTemperatureRadCoupledMixedFvPatchScalarField() [1/4]

◆ turbulentTemperatureRadCoupledMixedFvPatchScalarField() [2/4]

◆ turbulentTemperatureRadCoupledMixedFvPatchScalarField() [3/4]

◆ turbulentTemperatureRadCoupledMixedFvPatchScalarField() [4/4]

Construct as copy setting internal field reference.

Definition at line 147 of file turbulentTemperatureRadCoupledMixedFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "compressible::turbulentTemperatureRadCoupledMixed"  )

Runtime type information.

◆ clone()

◆ updateCoeffs()

◆ write()


The documentation for this class was generated from the following files:
