Foam::TableReaders Namespace Reference

Classes
struct	CsvLabelType
struct	CsvLabelType< Type, CsvVoid< typename pTraits< Type >::labelType > >
class	Csv
	Reads an interpolation table from a file in CSV-format. Entries govern the layout of the CSV file. The indices of the columns of the table that are to be used are given by the columns entry. This is a tuple for which the first part is the index of the column used for the x-axis, and the second part is the column index used for the scalar values, or a list of column indices used for the components of vector, tensor, etc..., values. More...
class	Embedded
	Reads an interpolation table from the values entry in OpenFOAM-format. More...
class	Foam
	Reads an interpolation table from a file in OpenFOAM-format. This is a list of Tuples in which complex types are delimited by parentheses. By default, a Tuple2 is assumed in which the first column is the (scalar) x-axis and the second column is the y-axis. But finer control over a n-component Tuple can be achieved by specifying the column indices. More...

Typedefs
template<typename T >
using	CsvVoid = void

Functions
template<class Type >
Type	CsvReadValue (const typename CsvLabelType< Type >::type &columns, const List< string > &split)
template<>
label	CsvReadValue< label > (const typename CsvLabelType< scalar >::type &columns, const List< string > &split)
template<>
scalar	CsvReadValue< scalar > (const typename CsvLabelType< scalar >::type &columns, const List< string > &split)

Typedef Documentation

CsvVoid

using CsvVoid = void

Definition at line 65 of file CsvTableReader.H.

Function Documentation

CsvReadValue()

Type Foam::TableReaders::CsvReadValue	(	const typename CsvLabelType< Type >::type &	columns,
		const List< string > &	split
	)

Definition at line 40 of file CsvTableReader.C.

References Foam::component(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::readScalar(), and List< T >::size().

Here is the call graph for this function:

CsvReadValue< label >()

label Foam::TableReaders::CsvReadValue< label > ( const typename CsvLabelType< scalar >::type &  columns, const List< string > &  split  )

inline

Definition at line 69 of file CsvTableReader.C.

References Foam::component(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::readLabel(), and List< T >::size().

Here is the call graph for this function:

CsvReadValue< scalar >()

scalar Foam::TableReaders::CsvReadValue< scalar > ( const typename CsvLabelType< scalar >::type &  columns, const List< string > &  split  )

inline

Definition at line 87 of file CsvTableReader.C.

References Foam::component(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::readScalar(), and List< T >::size().

Here is the call graph for this function:
