Reads an interpolation table from a file in CSV-format. Entries govern the layout of the CSV file. The indices of the columns of the table that are to be used are given by the columns entry. This is a tuple for which the first part is the index of the column used for the x-axis, and the second part is the column index used for the scalar values, or a list of column indices used for the components of vector, tensor, etc..., values. More...

Inheritance diagram for Csv< Coordinate, Value >:

[legend]

Collaboration diagram for Csv< Coordinate, Value >:

[legend]

Public Member Functions
	TypeName ("csv")
	Runtime type information. More...

	Csv (const word &name, const Function1s::unitSets &units, const dictionary &dict)
	Construct from name and dictionary. More...

virtual autoPtr< TableReader< Coordinate, Value > >	clone () const
	Construct and return a copy. More...

virtual	~Csv ()
	Destructor. More...

virtual void	write (Ostream &os, const Function1s::unitSets &units, const List< Tuple2< Coordinate, Value >> &table, const word &valuesKeyword=word::null) const
	Write settings and values. More...

Public Member Functions inherited from TableFileReader< Coordinate, Value >
	TableFileReader (const Function1s::unitSets &defaultUnits, const dictionary &dict)
	Construct from dictionary. More...

	TableFileReader (const TableFileReader< Coordinate, Value > &)
	Copy construct. More...

virtual	~TableFileReader ()
	Destructor. More...

virtual List< Tuple2< Coordinate, Value > >	read (const Function1s::unitSets &units, const dictionary &dict, const word &valuesKeyword=word::null) const
	Read values. More...

Public Member Functions inherited from TableReader< Coordinate, Value >
	TypeName ("TableReader")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, TableReader, dictionary,(const word &name, const Function1s::unitSets &units, const dictionary &dict),(name, units, dict))

	TableReader ()
	Default construct. More...

virtual	~TableReader ()
	Destructor. More...

Additional Inherited Members
Static Public Member Functions inherited from TableReader< Coordinate, Value >
static autoPtr< TableReader< Coordinate, Value > >	New (const word &name, const Function1s::unitSets &units, const dictionary &dict)

Protected Member Functions inherited from TableFileReader< Coordinate, Value >
void	read (const Function1s::unitSets &defaultUnits, const dictionary &dict, List< Tuple2< Coordinate, Value >> &) const
	Read a 1D table. More...

Protected Member Functions inherited from TableReader< Coordinate, Value >
void	convertRead (const Function1s::unitSets &units, List< Tuple2< Coordinate, Value >> &table) const
	Do unit conversions on input data. More...

List< Tuple2< Coordinate, Value > >	convertRead (const Function1s::unitSets &units, const List< Tuple2< Coordinate, Value >> &table) const
	Do unit conversions on input data. More...

List< Tuple2< Coordinate, Value > >	convertWrite (const Function1s::unitSets &units, const List< Tuple2< Coordinate, Value >> &table) const
	Do unit conversions in order to output data. More...

Detailed Description

template<class Coordinate, class Value>
class Foam::TableReaders::Csv< Coordinate, Value >

Reads an interpolation table from a file in CSV-format. Entries govern the layout of the CSV file. The indices of the columns of the table that are to be used are given by the columns entry. This is a tuple for which the first part is the index of the column used for the x-axis, and the second part is the column index used for the scalar values, or a list of column indices used for the components of vector, tensor, etc..., values.

Usage

    nHeaderLine         4;           // number of header lines
    columns             (0 (1 2 3)); // column indices for vector values
    separator           ",";         // optional (defaults to ",")
    mergeSeparators     no;          // merge multiple separators

Source files

Definition at line 110 of file CsvTableReader.H.

Constructor & Destructor Documentation

◆ Csv()

Csv	(	const word &	name,
		const Function1s::unitSets &	units,
		const dictionary &	dict
	)

Construct from name and dictionary.

Definition at line 221 of file CsvTableReader.C.

◆ ~Csv()

~Csv

virtual

Destructor.

Definition at line 262 of file CsvTableReader.C.

Member Function Documentation

◆ TypeName()

TypeName ( "csv" )

Runtime type information.

◆ clone()

virtual autoPtr<TableReader<Coordinate, Value> > clone ( ) const

inlinevirtual

Construct and return a copy.

Implements TableReader< Coordinate, Value >.

Definition at line 162 of file CsvTableReader.H.

◆ write()

void write	(	Ostream &	os,
		const Function1s::unitSets &	units,
		const List< Tuple2< Coordinate, Value >> &	table,
		const word &	valuesKeyword = `word::null`
	)		const

virtual

Write settings and values.

Reimplemented from TableFileReader< Coordinate, Value >.

Definition at line 269 of file CsvTableReader.C.

References Foam::dimensions::table, TableFileReader< Coordinate, Value >::write(), and Foam::writeEntry().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/OpenFOAM/primitives/functions/Function1/Table/TableReader/Csv/CsvTableReader.H
src/OpenFOAM/primitives/functions/Function1/Table/TableReader/Csv/CsvTableReader.C
