nonConformalFvPatch Class Reference

Non-conformal FV patch. Provides the necessary interface for a FV patch which does not conform to the underlying poly mesh. The non-conformal geometry and topology are held in the fvMesh, and are generated by the fvMeshStitcher. This class just provides access to this data. More...

Inheritance diagram for nonConformalFvPatch:

Public Member Functions
	TypeName (nonConformalPolyPatch::typeName_())
	Runtime type information. More...
	nonConformalFvPatch (const fvPatch &patch)
	Construct from a patch. More...
virtual	~nonConformalFvPatch ()
	Destructor. More...
const nonConformalPolyPatch &	nonConformalPatch () const
	Return the reference to the polyPatch. More...
const word &	origPatchName () const
	Original patch name. More...
label	origPatchID () const
	Original patch ID. More...
const fvPatch &	origPatch () const
	Original patch. More...
const labelList &	polyFaces () const
	Return face face-poly-faces. More...
virtual label	start () const
	Return the start label of this patch in the polyMesh face list. More...
virtual label	size () const
	Return the size. More...
virtual const labelUList &	faceCells () const
	Return the face-cells. More...

Detailed Description

Non-conformal FV patch. Provides the necessary interface for a FV patch which does not conform to the underlying poly mesh. The non-conformal geometry and topology are held in the fvMesh, and are generated by the fvMeshStitcher. This class just provides access to this data.

See also

Foam::fvMesh Foam::fvMeshStitcher

Source files

• nonConformalFvPatch.H
• nonConformalFvPatch.C

Definition at line 56 of file nonConformalFvPatch.H.

Constructor & Destructor Documentation

nonConformalFvPatch()

nonConformalFvPatch

(

const fvPatch &

patch

)

Construct from a patch.

Definition at line 39 of file nonConformalFvPatch.C.

~nonConformalFvPatch()

~nonConformalFvPatch ( )

virtual

Destructor.

Definition at line 52 of file nonConformalFvPatch.C.

Member Function Documentation

TypeName()

TypeName

(

nonConformalPolyPatch::typeName_()

)

Runtime type information.

nonConformalPatch()

const Foam::nonConformalPolyPatch & nonConformalPatch

(

)

const

Return the reference to the polyPatch.

Definition at line 59 of file nonConformalFvPatch.C.

origPatchName()

const Foam::word & origPatchName

(

)

const

Original patch name.

Definition at line 65 of file nonConformalFvPatch.C.

origPatchID()

Foam::label origPatchID

(

)

const

Original patch ID.

Definition at line 71 of file nonConformalFvPatch.C.

Referenced by fvMeshStitcher::conformalNccBoundaryField(), fvMeshStitcher::getOrigNccMagSfb(), and fvMeshStitcher::nonConformalBoundaryField().

Here is the caller graph for this function:

origPatch()

const Foam::fvPatch & origPatch

(

)

const

Original patch.

Definition at line 77 of file nonConformalFvPatch.C.

References fvPatch::boundaryMesh().

Referenced by fvMeshStitcher::conformalNccBoundaryField(), fvMeshStitcher::getOrigNccMagSfb(), and fvMeshStitcher::nonConformalBoundaryField().

Here is the call graph for this function:

Here is the caller graph for this function:

polyFaces()

const Foam::labelList & polyFaces

(

)

const

Return face face-poly-faces.

Definition at line 83 of file nonConformalFvPatch.C.

References polyMesh::boundaryMesh(), fvMesh::conformal(), polyBoundaryMesh::mesh(), List< label >::null(), and fvMesh::polyFacesBf().

Referenced by fvMeshStitcher::conformalNccBoundaryField(), fvMeshStitcher::getOrigNccMagSfb(), fvMeshStitcher::nonConformalBoundaryField(), and nonConformalErrorFvPatch::polyFaces().

Here is the call graph for this function:

Here is the caller graph for this function:

start()

Foam::label start ( ) const

virtual

Return the start label of this patch in the polyMesh face list.

Raises an error unless the patch is empty.

Reimplemented in nonConformalProcessorCyclicFvPatch, nonConformalErrorFvPatch, and nonConformalCyclicFvPatch.

Definition at line 94 of file nonConformalFvPatch.C.

References Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Referenced by nonConformalCyclicFvPatch::start(), nonConformalErrorFvPatch::start(), and nonConformalProcessorCyclicFvPatch::start().

Here is the call graph for this function:

Here is the caller graph for this function:

size()

Foam::label size ( ) const

virtual

Return the size.

Reimplemented in nonConformalProcessorCyclicFvPatch, nonConformalErrorFvPatch, and nonConformalCyclicFvPatch.

Definition at line 108 of file nonConformalFvPatch.C.

Referenced by nonConformalCyclicFvPatch::size(), nonConformalErrorFvPatch::size(), and nonConformalProcessorCyclicFvPatch::size().

Here is the caller graph for this function:

faceCells()

const Foam::labelUList & faceCells ( ) const

virtual

Return the face-cells.

Reimplemented in nonConformalProcessorCyclicFvPatch, nonConformalErrorFvPatch, and nonConformalCyclicFvPatch.

Definition at line 114 of file nonConformalFvPatch.C.

References polyMesh::boundaryMesh(), polyMesh::faceOwner(), and polyBoundaryMesh::mesh().

Referenced by nonConformalCyclicFvPatch::faceCells(), nonConformalErrorFvPatch::faceCells(), and nonConformalProcessorCyclicFvPatch::faceCells().

Here is the call graph for this function:

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fvMesh/fvPatches/constraint/nonConformal/nonConformalFvPatch.H
• src/finiteVolume/fvMesh/fvPatches/constraint/nonConformal/nonConformalFvPatch.C
