Mesh manipulator that uses the intersection provided by the cyclic non-conformal poly patches to create non-conformal finite volume interfaces. More...

Inheritance diagram for fvMeshStitcher:

[legend]

Public Member Functions
	TypeName ("fvMeshStitcher")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvMeshStitcher, fvMesh,(fvMesh &mesh),(mesh))

	fvMeshStitcher (fvMesh &)
	Construct from fvMesh. More...

	fvMeshStitcher (const fvMeshStitcher &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvMeshStitcher ()
	Destructor. More...

fvMesh &	mesh ()
	Return the fvMesh. More...

bool	stitches () const
	Does this stitcher do anything? More...

virtual void	updateMesh (const polyTopoChangeMap &)
	Update local data for topology changes. More...

virtual void	movePoints ()
	Update local data for mesh motion. More...

virtual bool	disconnect (const bool changing, const bool geometric)
	Disconnect the mesh by removing faces from the nonConformalCyclics. More...

virtual bool	connect (const bool changing, const bool geometric, const bool load)
	Connect the mesh by adding faces into the nonConformalCyclics. More...

void	reconnect (const bool geometric) const
	Re-compute the connection. Topology is preserved. Permits a change. More...

virtual bool	write (const bool write=true) const
	Write the mover state. More...

void	operator= (const fvMeshStitcher &)=delete
	Disallow default bitwise assignment. More...

template<class NonConformalFvPatch >
void	createNonConformalStabilisationGeometry (const surfaceLabelField::Boundary &polyFacesBf, surfaceVectorField &SfSf, surfaceVectorField &CfSf) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	fieldRMapSum (const Field< Type > &f, const label size, const labelUList &addr)

template<class Type >
Foam::tmp< Foam::Field< Type > >	fieldRMapSum (const tmp< Field< Type >> &f, const label size, const labelUList &addr)

template<class Type >
Foam::tmp< Foam::fvMeshStitcher::SurfaceFieldBoundary< Type > >	conformalNccBoundaryField (const SurfaceFieldBoundary< Type > &fieldb) const

template<class Type >
Foam::tmp< Foam::fvMeshStitcher::SurfaceFieldBoundary< Type > >	conformalOrigBoundaryField (const SurfaceFieldBoundary< Type > &fieldb) const

template<class Type >
Foam::tmp< Foam::fvMeshStitcher::SurfaceFieldBoundary< Type > >	nonConformalBoundaryField (const SurfaceFieldBoundary< Type > &nccFieldb, const SurfaceFieldBoundary< Type > &origFieldb) const

template<class Type >
Foam::tmp< Foam::fvMeshStitcher::SurfaceFieldBoundary< Type > >	synchronisedBoundaryField (const SurfaceFieldBoundary< Type > &fieldb, const bool flip, const scalar ownerWeight, const scalar neighbourWeight) const

template<class Type >
Foam::tmp< Foam::fvMeshStitcher::SurfaceFieldBoundary< Type > >	synchronisedBoundaryField (const SurfaceFieldBoundary< Type > &fieldb) const

Static Public Member Functions
static autoPtr< fvMeshStitcher >	New (fvMesh &, bool changing)
	Select, construct and return the fvMeshStitcher. More...

Protected Types
template<class Type >
using	SurfaceFieldBoundary = GeometricBoundaryField< Type, fvsPatchField, surfaceMesh >
	Alias for surface boundary fields to reduce verbosity of method. More...

using	part = patchToPatches::intersection::part
	Alias the patchToPatch intersection part struct. More...

using	couple = patchToPatches::intersection::couple
	Alias the patchToPatch intersection couple struct. More...

Protected Member Functions
template<class GeoBoundaryField >
void	resizeBoundaryFieldPatchFields (const SurfaceFieldBoundary< label > &polyFacesBf, GeoBoundaryField &fieldBf)
	Resize the patch field of a given field to match the mesh. More...

template<class GeoField >
void	resizeFieldPatchFields (const SurfaceFieldBoundary< label > &polyFacesBf, GeoField &field)
	Resize the patch field of a given field to match the mesh. More...

tmp< SurfaceFieldBoundary< scalar > >	getOrigNccMagSfb () const
	Return the total non-conformal area associated with each. More...

template<class Type >
tmp< SurfaceFieldBoundary< Type > >	conformalNccBoundaryField (const SurfaceFieldBoundary< Type > &fieldb) const
	Extract the non-conformal-coupled parts of the boundary field. More...

template<class Type >
tmp< SurfaceFieldBoundary< Type > >	conformalOrigBoundaryField (const SurfaceFieldBoundary< Type > &fieldb) const
	Extract the original parts of the boundary field and store it. More...

template<class Type >
tmp< SurfaceFieldBoundary< Type > >	nonConformalBoundaryField (const SurfaceFieldBoundary< Type > &nccFieldb, const SurfaceFieldBoundary< Type > &origFieldb) const
	Combine non-conformal-coupled and original parts of the. More...

template<class Type >
tmp< SurfaceFieldBoundary< Type > >	synchronisedBoundaryField (const SurfaceFieldBoundary< Type > &fieldb, const bool flip, const scalar ownerWeight, const scalar neighbourWeight) const
	Synchronise the boundary field by combining corresponding. More...

template<class Type >
tmp< SurfaceFieldBoundary< Type > >	synchronisedBoundaryField (const SurfaceFieldBoundary< Type > &fieldb) const
	Synchronise the boundary field by combining corresponding. More...

bool	geometric () const
	Is the connection "geometric", or has the topology just been. More...

tmp< DimensionedField< scalar, volMesh > >	openness () const
	Return the non-dimensional cell openness for debugging/checking. More...

tmp< DimensionedField< scalar, volMesh > >	volumeConservationError (const label n) const
	Return the non-dimensional old-time volume conservation error. More...

Static Protected Member Functions
template<class Type >
static tmp< Field< Type > >	fieldRMapSum (const Field< Type > &f, const label size, const labelUList &addr)
	Reverse-map sum the values of a field. More...

template<class Type >
static tmp< Field< Type > >	fieldRMapSum (const tmp< Field< Type >> &f, const label size, const labelUList &addr)
	Reverse-map sum the values of a field. More...

Detailed Description

Mesh manipulator that uses the intersection provided by the cyclic non-conformal poly patches to create non-conformal finite volume interfaces.

Source files

Definition at line 53 of file fvMeshStitcher.H.

Member Typedef Documentation

◆ SurfaceFieldBoundary

using SurfaceFieldBoundary = GeometricBoundaryField<Type, fvsPatchField, surfaceMesh>

protected

Alias for surface boundary fields to reduce verbosity of method.

definitions below

Definition at line 62 of file fvMeshStitcher.H.

◆ part

using part = patchToPatches::intersection::part

protected

Alias the patchToPatch intersection part struct.

Definition at line 66 of file fvMeshStitcher.H.

◆ couple

using couple = patchToPatches::intersection::couple

protected

Alias the patchToPatch intersection couple struct.

Definition at line 69 of file fvMeshStitcher.H.

Constructor & Destructor Documentation

◆ fvMeshStitcher() [1/2]

fvMeshStitcher ( fvMesh & mesh )

explicit

Construct from fvMesh.

Definition at line 1160 of file fvMeshStitcher.C.

◆ fvMeshStitcher() [2/2]

fvMeshStitcher ( const fvMeshStitcher & )

delete

Disallow default bitwise copy construction.

◆ ~fvMeshStitcher()

~fvMeshStitcher ( )

virtual

Destructor.

Definition at line 1168 of file fvMeshStitcher.C.

Member Function Documentation

◆ resizeBoundaryFieldPatchFields()

void resizeBoundaryFieldPatchFields	(	const SurfaceFieldBoundary< label > &	polyFacesBf,
		GeoBoundaryField &	fieldBf
	)

protected

Resize the patch field of a given field to match the mesh.

Definition at line 313 of file fvMeshStitcherTemplates.C.

References forAll.

◆ resizeFieldPatchFields()

void resizeFieldPatchFields	(	const SurfaceFieldBoundary< label > &	polyFacesBf,
		GeoField &	field
	)

protected

Resize the patch field of a given field to match the mesh.

Definition at line 333 of file fvMeshStitcherTemplates.C.

◆ fieldRMapSum() [1/4]

static tmp<Field<Type> > fieldRMapSum	(	const Field< Type > &	f,
		const label	size,
		const labelUList &	addr
	)

staticprotected

Reverse-map sum the values of a field.

◆ fieldRMapSum() [2/4]

static tmp<Field<Type> > fieldRMapSum	(	const tmp< Field< Type >> &	f,
		const label	size,
		const labelUList &	addr
	)

staticprotected

Reverse-map sum the values of a field.

◆ getOrigNccMagSfb()

Foam::tmp< Foam::surfaceScalarField::Boundary > getOrigNccMagSfb ( ) const

inlineprotected

Return the total non-conformal area associated with each.

original face

Definition at line 382 of file fvMeshStitcherTemplates.C.

References GeometricField< Type, PatchField, GeoMesh >::boundaryField(), forAll, fvMesh::magSf(), fvBoundaryMesh::mesh(), DimensionedField< Type, GeoMesh >::null(), nonConformalFvPatch::origPatch(), nonConformalFvPatch::origPatchID(), nonConformalFvPatch::polyFaces(), tmp< T >::ref(), fvPatch::size(), and fvPatch::start().

Here is the call graph for this function:

◆ conformalNccBoundaryField() [1/2]

tmp<SurfaceFieldBoundary<Type> > conformalNccBoundaryField ( const SurfaceFieldBoundary< Type > & fieldb ) const

protected

Extract the non-conformal-coupled parts of the boundary field.

and store it on the conformal faces

◆ conformalOrigBoundaryField() [1/2]

tmp<SurfaceFieldBoundary<Type> > conformalOrigBoundaryField ( const SurfaceFieldBoundary< Type > & fieldb ) const

protected

Extract the original parts of the boundary field and store it.

on the conformal faces

◆ nonConformalBoundaryField() [1/2]

tmp<SurfaceFieldBoundary<Type> > nonConformalBoundaryField	(	const SurfaceFieldBoundary< Type > &	nccFieldb,
		const SurfaceFieldBoundary< Type > &	origFieldb
	)		const

protected

Combine non-conformal-coupled and original parts of the.

boundary field from the conformal faces to construct the complete non-conformal boundary field

◆ synchronisedBoundaryField() [1/4]

tmp<SurfaceFieldBoundary<Type> > synchronisedBoundaryField	(	const SurfaceFieldBoundary< Type > &	fieldb,
		const bool	flip,
		const scalar	ownerWeight,
		const scalar	neighbourWeight
	)		const

protected

Synchronise the boundary field by combining corresponding.

values across couplings with the given weightings

◆ synchronisedBoundaryField() [2/4]

tmp<SurfaceFieldBoundary<Type> > synchronisedBoundaryField ( const SurfaceFieldBoundary< Type > & fieldb ) const

protected

Synchronise the boundary field by combining corresponding.

values across couplings with equal weightings

◆ geometric()

bool geometric ( ) const

protected

Is the connection "geometric", or has the topology just been.

loaded and stabilisation geometry applied?

Definition at line 1089 of file fvMeshStitcher.C.

References forAll, polyPatch::magFaceAreas(), Foam::max(), patchi, Foam::reduce(), Foam::returnReduce(), and polyPatch::start().

Here is the call graph for this function:

◆ openness()

Foam::tmp< Foam::DimensionedField< Foam::scalar, Foam::volMesh > > openness ( ) const

protected

Return the non-dimensional cell openness for debugging/checking.

Definition at line 1124 of file fvMeshStitcher.C.

References Foam::cbrt(), Foam::cmptMag(), Foam::mag(), Foam::max(), Foam::sqr(), Foam::fvc::surfaceIntegrate(), and Foam::fvc::surfaceSum().

Here is the call graph for this function:

◆ volumeConservationError()

Foam::tmp< Foam::DimensionedField< Foam::scalar, Foam::volMesh > > volumeConservationError ( const label n ) const

protected

Return the non-dimensional old-time volume conservation error.

for a specified old-time index for debugging/checking

Definition at line 1137 of file fvMeshStitcher.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, n, GeometricField< Type, PatchField, GeoMesh >::oldTime(), and Foam::fvc::surfaceIntegrate().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "fvMeshStitcher" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		fvMeshStitcher	,
		fvMesh	,
		(fvMesh &mesh)	,
		(mesh)
	)

◆ New()

Foam::autoPtr< Foam::fvMeshStitcher > New	(	fvMesh &	mesh,
		bool	changing
	)

static

Select, construct and return the fvMeshStitcher.

Definition at line 30 of file fvMeshStitcherNew.C.

References TimePaths::constant(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAllConstIter, typeIOobject< Type >::headerOk(), Foam::libs, fvMeshStitcher::mesh(), Foam::nl, IOobject::NO_WRITE, dlLibraryTable::open(), IOobject::READ_IF_PRESENT, and fvMesh::time().

Here is the call graph for this function:

◆ mesh()

fvMesh& mesh ( )

inline

Return the fvMesh.

Definition at line 369 of file fvMeshStitcher.H.

Referenced by fvMeshStitcher::New().

Here is the caller graph for this function:

◆ stitches()

bool stitches ( ) const

Does this stitcher do anything?

Definition at line 1174 of file fvMeshStitcher.C.

References forAll, and patchi.

◆ updateMesh()

void updateMesh ( const polyTopoChangeMap & )

virtual

Update local data for topology changes.

Definition at line 1188 of file fvMeshStitcher.C.

◆ movePoints()

void movePoints ( )

virtual

Update local data for mesh motion.

Definition at line 1192 of file fvMeshStitcher.C.

◆ disconnect()

bool disconnect	(	const bool	changing,
		const bool	geometric
	)

virtual

Disconnect the mesh by removing faces from the nonConformalCyclics.

Definition at line 1196 of file fvMeshStitcher.C.

References Foam::decrIndent(), Foam::endl(), Foam::gAverage(), Foam::gMax(), Foam::gMin(), Foam::incrIndent(), Foam::indent(), Foam::Info, and UPstream::parRun().

Here is the call graph for this function:

◆ connect()

bool connect	(	const bool	changing,
		const bool	geometric,
		const bool	load
	)

virtual

Connect the mesh by adding faces into the nonConformalCyclics.

Definition at line 1279 of file fvMeshStitcher.C.

References GeometricBoundaryField< Type, PatchField, GeoMesh >::boundaryNeighbourField(), Foam::decrIndent(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::fileHandler(), forAll, Foam::gAverage(), Foam::gMax(), Foam::gMin(), Foam::incrIndent(), Foam::indent(), fvPatch::index(), Foam::Info, nonConformalCyclicPolyPatch::intersection(), Foam::isFile(), Foam::max(), Foam::min(), IOobject::MUST_READ, fvPatch::name(), nonConformalCyclicFvPatch::nonConformalCyclicPatch(), DimensionedField< Type, GeoMesh >::null(), GeometricField< Type, PatchField, GeoMesh >::null(), IOobject::objectPath(), nonConformalCyclicFvPatch::owner(), UPstream::parRun(), patchi, Foam::reduce(), GeometricBoundaryField< Type, PatchField, GeoMesh >::reset(), UPtrList< T >::size(), and Foam::sum().

Here is the call graph for this function:

◆ reconnect()

void reconnect ( const bool geometric ) const

Re-compute the connection. Topology is preserved. Permits a change.

in whether or not the connection is "geometric".

Definition at line 1533 of file fvMeshStitcher.C.

References GeometricField< Type, PatchField, GeoMesh >::null().

Here is the call graph for this function:

◆ write()

virtual bool write ( const bool write = true ) const

inlinevirtual

Write the mover state.

Definition at line 403 of file fvMeshStitcher.H.

◆ operator=()

void operator= ( const fvMeshStitcher & )

delete

Disallow default bitwise assignment.

◆ createNonConformalStabilisationGeometry()

void createNonConformalStabilisationGeometry	(	const surfaceLabelField::Boundary &	polyFacesBf,
		surfaceVectorField &	SfSf,
		surfaceVectorField &	CfSf
	)		const

inline

Definition at line 1050 of file fvMeshStitcher.C.

References GeometricField< Type, PatchField, GeoMesh >::boundaryFieldRef(), polyPatch::faceAreas(), polyPatch::faceCentres(), forAll, patchi, and polyPatch::start().

Here is the call graph for this function:

◆ fieldRMapSum() [3/4]

Foam::tmp<Foam::Field<Type> > fieldRMapSum	(	const Field< Type > &	f,
		const label	size,
		const labelUList &	addr
	)

Definition at line 351 of file fvMeshStitcherTemplates.C.

References f(), forAll, tmp< T >::ref(), and Foam::Zero.

Here is the call graph for this function:

◆ fieldRMapSum() [4/4]

Foam::tmp<Foam::Field<Type> > fieldRMapSum	(	const tmp< Field< Type >> &	f,
		const label	size,
		const labelUList &	addr
	)

Definition at line 368 of file fvMeshStitcherTemplates.C.

References List< T >::clear(), and f().

Here is the call graph for this function:

◆ conformalNccBoundaryField() [2/2]

Foam::tmp<Foam::fvMeshStitcher::SurfaceFieldBoundary<Type> > conformalNccBoundaryField ( const SurfaceFieldBoundary< Type > & fieldb ) const

Definition at line 434 of file fvMeshStitcherTemplates.C.

References nonConformalBoundary::allOrigPatchIDs(), GeometricField< Type, PatchField, GeoMesh >::boundaryField(), forAll, Foam::isFlux(), fvMesh::magSf(), Foam::max(), fvBoundaryMesh::mesh(), DemandDrivenMeshObject< polyMesh, MoveableMeshObject, nonConformalBoundary >::New(), DimensionedField< Type, GeoMesh >::null(), nonConformalFvPatch::origPatch(), nonConformalFvPatch::origPatchID(), nonConformalFvPatch::polyFaces(), tmp< T >::ref(), fvPatch::size(), and fvPatch::start().

Here is the call graph for this function:

◆ conformalOrigBoundaryField() [2/2]

Foam::tmp<Foam::fvMeshStitcher::SurfaceFieldBoundary<Type> > conformalOrigBoundaryField ( const SurfaceFieldBoundary< Type > & fieldb ) const

Definition at line 542 of file fvMeshStitcherTemplates.C.

References nonConformalBoundary::allOrigPatchIDs(), GeometricField< Type, PatchField, GeoMesh >::boundaryField(), forAll, Foam::isFlux(), fvMesh::magSf(), Foam::max(), fvBoundaryMesh::mesh(), DemandDrivenMeshObject< polyMesh, MoveableMeshObject, nonConformalBoundary >::New(), DimensionedField< Type, GeoMesh >::null(), and tmp< T >::ref().

Here is the call graph for this function:

◆ nonConformalBoundaryField() [2/2]

Foam::tmp<Foam::fvMeshStitcher::SurfaceFieldBoundary<Type> > nonConformalBoundaryField	(	const SurfaceFieldBoundary< Type > &	nccFieldb,
		const SurfaceFieldBoundary< Type > &	origFieldb
	)		const

Definition at line 598 of file fvMeshStitcherTemplates.C.

References GeometricField< Type, PatchField, GeoMesh >::boundaryField(), forAll, Foam::isFlux(), fvMesh::magSf(), fvBoundaryMesh::mesh(), DimensionedField< Type, GeoMesh >::null(), nonConformalFvPatch::origPatch(), nonConformalFvPatch::origPatchID(), patchi, nonConformalFvPatch::polyFaces(), nonConformalErrorFvPatch::polyFaces(), tmp< T >::ref(), fvPatch::start(), and Foam::Zero.

Here is the call graph for this function:

◆ synchronisedBoundaryField() [3/4]

Foam::tmp<Foam::fvMeshStitcher::SurfaceFieldBoundary<Type> > synchronisedBoundaryField	(	const SurfaceFieldBoundary< Type > &	fieldb,
		const bool	flip,
		const scalar	ownerWeight,
		const scalar	neighbourWeight
	)		const

Definition at line 720 of file fvMeshStitcherTemplates.C.

References GeometricBoundaryField< Type, PatchField, GeoMesh >::boundaryNeighbourField(), fvPatch::coupled(), forAll, coupledFvPatch::owner(), patchi, and tmp< T >::ref().

Here is the call graph for this function:

◆ synchronisedBoundaryField() [4/4]

Foam::tmp<Foam::fvMeshStitcher::SurfaceFieldBoundary<Type> > synchronisedBoundaryField ( const SurfaceFieldBoundary< Type > & fieldb ) const

Definition at line 769 of file fvMeshStitcherTemplates.C.

References Foam::isFlux().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/finiteVolume/fvMesh/fvMeshStitchers/fvMeshStitcher/fvMeshStitcher.H
src/finiteVolume/fvMesh/fvMeshStitchers/fvMeshStitcher/fvMeshStitcher.C
src/finiteVolume/fvMesh/fvMeshStitchers/fvMeshStitcher/fvMeshStitcherNew.C
src/finiteVolume/fvMesh/fvMeshStitchers/fvMeshStitcher/fvMeshStitcherTemplates.C

Public Member Functions

Static Public Member Functions

Protected Types

Protected Member Functions

Static Protected Member Functions

Detailed Description

Member Typedef Documentation

◆ SurfaceFieldBoundary

◆ part

◆ couple

Constructor & Destructor Documentation

◆ fvMeshStitcher() [1/2]

◆ fvMeshStitcher() [2/2]

◆ ~fvMeshStitcher()

Member Function Documentation

◆ resizeBoundaryFieldPatchFields()

◆ resizeFieldPatchFields()

◆ fieldRMapSum() [1/4]

◆ fieldRMapSum() [2/4]

◆ getOrigNccMagSfb()

◆ conformalNccBoundaryField() [1/2]

◆ conformalOrigBoundaryField() [1/2]

◆ nonConformalBoundaryField() [1/2]

◆ synchronisedBoundaryField() [1/4]

◆ synchronisedBoundaryField() [2/4]

◆ geometric()

◆ openness()

◆ volumeConservationError()

◆ TypeName()

◆ declareRunTimeSelectionTable()

◆ New()

◆ mesh()

◆ stitches()

◆ updateMesh()

◆ movePoints()

◆ disconnect()

◆ connect()

◆ reconnect()

◆ write()

◆ operator=()

◆ createNonConformalStabilisationGeometry()

◆ fieldRMapSum() [3/4]

◆ fieldRMapSum() [4/4]

◆ conformalNccBoundaryField() [2/2]

◆ conformalOrigBoundaryField() [2/2]

◆ nonConformalBoundaryField() [2/2]

◆ synchronisedBoundaryField() [3/4]

◆ synchronisedBoundaryField() [4/4]
