Non-conformal coupled FV patch. As nonConformalFvPatch, but is also coupled to another non-conformal patch. More...

Inheritance diagram for nonConformalCoupledFvPatch:

[legend]

Collaboration diagram for nonConformalCoupledFvPatch:

Public Member Functions
	TypeName (nonConformalCoupledPolyPatch::typeName_())
	Runtime type information. More...

	nonConformalCoupledFvPatch (const fvPatch &patch)
	Construct from a patch. More...

virtual	~nonConformalCoupledFvPatch ()
	Destructor. More...

const nonConformalCoupledPolyPatch &	nonConformalCoupledPatch () const
	Return the reference to the polyPatch. More...

bool	owner () const
	Does this side own the patch? More...

bool	neighbour () const
	Does the coupled side own the patch? More...

const transformer &	transform () const
	Return transformation between the coupled patches. More...

const word &	errorPatchName () const
	Error patch name. More...

label	errorPatchID () const
	Error patch ID. More...

const nonConformalErrorFvPatch &	errorPatch () const
	Error patch. More...

Public Member Functions inherited from nonConformalFvPatch
	TypeName (nonConformalPolyPatch::typeName_())
	Runtime type information. More...

	nonConformalFvPatch (const fvPatch &patch)
	Construct from a patch. More...

virtual	~nonConformalFvPatch ()
	Destructor. More...

const nonConformalPolyPatch &	nonConformalPatch () const
	Return the reference to the polyPatch. More...

const word &	origPatchName () const
	Original patch name. More...

label	origPatchID () const
	Original patch ID. More...

const fvPatch &	origPatch () const
	Original patch. More...

const labelList &	polyFaces () const
	Return face face-poly-faces. More...

virtual label	start () const
	Return the start label of this patch in the polyMesh face list. More...

virtual label	size () const
	Return the size. More...

virtual const labelUList &	faceCells () const
	Return the face-cells. More...

Protected Member Functions
void	makeWeights (scalarField &w, const vectorField &nbrSf, const vectorField &nbrDelta) const
	Make patch weighting factors. More...

Detailed Description

Non-conformal coupled FV patch. As nonConformalFvPatch, but is also coupled to another non-conformal patch.

See also: Foam::nonConformalCoupledPolyPatch Foam::nonConformalFvPatch

Source files

Definition at line 57 of file nonConformalCoupledFvPatch.H.

Constructor & Destructor Documentation

◆ nonConformalCoupledFvPatch()

nonConformalCoupledFvPatch ( const fvPatch & patch )

Construct from a patch.

Definition at line 84 of file nonConformalCoupledFvPatch.C.

◆ ~nonConformalCoupledFvPatch()

~nonConformalCoupledFvPatch ( )

virtual

Destructor.

Definition at line 100 of file nonConformalCoupledFvPatch.C.

Member Function Documentation

◆ makeWeights()

void makeWeights	(	scalarField &	w,
		const vectorField &	nbrSf,
		const vectorField &	nbrDelta
	)		const

protected

Make patch weighting factors.

Definition at line 42 of file nonConformalCoupledFvPatch.C.

References delta, forAll, Foam::mag(), and fvPatch::nf().

Referenced by nonConformalCyclicFvPatch::makeWeights(), and nonConformalProcessorCyclicFvPatch::makeWeights().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ TypeName()

TypeName ( nonConformalCoupledPolyPatch::typeName_() )

Runtime type information.

◆ nonConformalCoupledPatch()

const Foam::nonConformalCoupledPolyPatch & nonConformalCoupledPatch ( ) const

Return the reference to the polyPatch.

Definition at line 107 of file nonConformalCoupledFvPatch.C.

◆ owner()

bool owner ( ) const

Does this side own the patch?

Definition at line 113 of file nonConformalCoupledFvPatch.C.

◆ neighbour()

bool neighbour ( ) const

Does the coupled side own the patch?

Definition at line 119 of file nonConformalCoupledFvPatch.C.

◆ transform()

const Foam::transformer & transform ( ) const

Return transformation between the coupled patches.

Definition at line 125 of file nonConformalCoupledFvPatch.C.

References transformer::transform().

Here is the call graph for this function:

◆ errorPatchName()

const Foam::word & errorPatchName ( ) const

Error patch name.

Definition at line 131 of file nonConformalCoupledFvPatch.C.

◆ errorPatchID()

Foam::label errorPatchID ( ) const

Error patch ID.

Definition at line 137 of file nonConformalCoupledFvPatch.C.

◆ errorPatch()

const Foam::nonConformalErrorFvPatch & errorPatch ( ) const

Error patch.

Definition at line 144 of file nonConformalCoupledFvPatch.C.

The documentation for this class was generated from the following files:

src/finiteVolume/fvMesh/fvPatches/constraint/nonConformalCoupled/nonConformalCoupledFvPatch.H
src/finiteVolume/fvMesh/fvPatches/constraint/nonConformalCoupled/nonConformalCoupledFvPatch.C
