meshObjects Class Reference

Templated abstract base-class for optional mesh objects used to automate their allocation to the mesh database and the mesh-modifier event-loop. More...

Public Member Functions
	ClassName ("meshObjects")

Static Public Member Functions
template<class Mesh >
static void	movePoints (objectRegistry &)
template<class Mesh >
static void	topoChange (objectRegistry &, const polyTopoChangeMap &)
template<class Mesh >
static void	mapMesh (objectRegistry &, const polyMeshMap &)
template<class Mesh >
static void	distribute (objectRegistry &, const polyDistributionMap &)
template<class Mesh >
static void	addPatch (objectRegistry &, const label patchi)
template<class Mesh >
static void	reorderPatches (objectRegistry &, const labelUList &newToOld, const bool validBoundary)
template<class Mesh , template< class > class MeshObjectType>
static void	clear (objectRegistry &)
template<class Mesh , template< class > class FromType, template< class > class ToType>
static void	clearUpto (objectRegistry &)
	Clear all meshObjects derived from FromType up to (but not including) More...

Detailed Description

Templated abstract base-class for optional mesh objects used to automate their allocation to the mesh database and the mesh-modifier event-loop.

MeshObject is templated on the type of mesh it is allocated to, the type of the mesh object (TopologicalMeshObject, GeometricMeshObject, MoveableMeshObject, DistributeableMeshObject, UpdateableMeshObject) and the type of the actual object it is created for example:

class leastSquaresVectors
:
    public MeshObject<fvMesh, MoveableMeshObject, leastSquaresVectors>
{
.
.
.
    //! Delete the least square vectors when the mesh moves
    virtual bool movePoints();
};

MeshObject types:

• TopologicalMeshObject: mesh object to be deleted on topology change
• GeometricMeshObject: mesh object to be deleted on geometry change
• MoveableMeshObject: mesh object to be updated in movePoints
• UpdateableMeshObject: mesh object to be updated in topoChange or movePoints
• PatchMeshObject: mesh object to be additionally updated patch changes

Note: movePoints must be provided for MeshObjects of type MoveableMeshObject and both movePoints and topoChange functions must exist, provided for MeshObjects of type UpdateableMeshObject.

Source files

• meshObjects.H
• meshObject.C
• meshObjects.C

Definition at line 87 of file meshObjects.H.

Member Function Documentation

ClassName()

ClassName

(

"meshObjects"

)

movePoints()

void movePoints ( objectRegistry &  obr )

static

Definition at line 56 of file meshObjectsTemplates.C.

References Foam::endl(), forAllIter, Foam::isA(), objectRegistry::lookupClass(), IOobject::name(), OSstream::name(), and Foam::Pout.

Here is the call graph for this function:

topoChange()

void topoChange ( objectRegistry &  obr, const polyTopoChangeMap &  map  )

static

Definition at line 138 of file meshObjectsTemplates.C.

References Foam::endl(), forAllIter, Foam::isA(), objectRegistry::lookupClass(), IOobject::name(), OSstream::name(), and Foam::Pout.

Here is the call graph for this function:

mapMesh()

void mapMesh ( objectRegistry &  obr, const polyMeshMap &  map  )

static

Definition at line 180 of file meshObjectsTemplates.C.

References Foam::endl(), forAllIter, Foam::isA(), objectRegistry::lookupClass(), IOobject::name(), OSstream::name(), and Foam::Pout.

Here is the call graph for this function:

distribute()

void distribute ( objectRegistry &  obr, const polyDistributionMap &  map  )

static

Definition at line 94 of file meshObjectsTemplates.C.

References Foam::endl(), forAllIter, Foam::isA(), objectRegistry::lookupClass(), IOobject::name(), OSstream::name(), and Foam::Pout.

Here is the call graph for this function:

addPatch()

void addPatch ( objectRegistry &  obr, const label  patchi  )

static

Definition at line 222 of file meshObjectsTemplates.C.

References Foam::endl(), forAllIter, Foam::isA(), objectRegistry::lookupClass(), IOobject::name(), OSstream::name(), patchi, and Foam::Pout.

Here is the call graph for this function:

reorderPatches()

void reorderPatches ( objectRegistry &  obr, const labelUList &  newToOld, const bool  validBoundary  )

static

Definition at line 260 of file meshObjectsTemplates.C.

References Foam::endl(), forAllIter, Foam::isA(), objectRegistry::lookupClass(), IOobject::name(), OSstream::name(), and Foam::Pout.

Here is the call graph for this function:

clear()

void clear ( objectRegistry &  obr )

static

Definition at line 307 of file meshObjectsTemplates.C.

References Foam::endl(), forAllIter, objectRegistry::lookupClass(), IOobject::name(), and Foam::Pout.

Here is the call graph for this function:

clearUpto()

void clearUpto ( objectRegistry &  obr )

static

Clear all meshObjects derived from FromType up to (but not including)

ToType. Used to clear e.g. all non-updateable meshObjects

Definition at line 334 of file meshObjectsTemplates.C.

References Foam::endl(), forAllIter, Foam::isA(), objectRegistry::lookupClass(), IOobject::name(), and Foam::Pout.

Referenced by polyMesh::addPatch(), polyMesh::clearAddressing(), and polyMesh::reorderPatches().

Here is the call graph for this function:

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/meshes/meshObjects/meshObjects.H
• src/OpenFOAM/meshes/meshObjects/meshObjectsTemplates.C
