Mesh motion solver for an fvMesh. Based on solving the cell-centre Laplacian for the given component of the motion velocity. More...

Inheritance diagram for velocityComponentLaplacian:

[legend]

Collaboration diagram for velocityComponentLaplacian:

[legend]

Public Member Functions
	TypeName ("velocityComponentLaplacian")
	Runtime type information. More...

	velocityComponentLaplacian (fvMesh &, const dictionary &)
	Construct from fvMesh and dictionary. More...

	velocityComponentLaplacian (const polyMesh &, const dictionary &)
	Construct from polyMesh and dictionary. More...

	velocityComponentLaplacian (const velocityComponentLaplacian &)=delete
	Disallow default bitwise copy construction. More...

	~velocityComponentLaplacian ()
	Destructor. More...

volScalarField &	cellMotionU ()
	Non-const access to the cellMotionU in order to allow changes. More...

virtual tmp< pointField >	newPoints ()
	Return point location obtained from the current motion field. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update corresponding to the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

void	operator= (const velocityComponentLaplacian &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvMotionSolver
	ClassName ("fvMotionSolver")
	Runtime type information. More...

	fvMotionSolver (fvMesh &)
	Construct from fvMesh. More...

	fvMotionSolver (const polyMesh &)
	Construct from polyMesh. More...

virtual bool	solidBodyMotion () const
	Is this motion solid body? Delegate to the motion solver. More...

virtual bool	update ()
	Update the mesh for both mesh motion and topology change. More...

virtual void	distribute (const polyDistributionMap &)
	Update corresponding to the given distribution map. More...

template<class Type >
Foam::wordList	cellMotionBoundaryTypes (const typename PointField< Type >::Boundary &pmUbf) const

Public Member Functions inherited from fvMeshMover
	TypeName ("fvMeshMover")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvMeshMover, fvMesh,(fvMesh &mesh, const dictionary &dict),(mesh, dict))

	fvMeshMover (fvMesh &)
	Construct from fvMesh. More...

	fvMeshMover (const fvMeshMover &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvMeshMover ()
	Destructor. More...

fvMesh &	mesh ()
	Return the fvMesh. More...

const fvMesh &	mesh () const
	Return the fvMesh. More...

virtual bool	dynamic () const
	Is mesh dynamic, i.e. might it change? More...

virtual bool	write (const bool write=true) const
	Write the mover state. More...

void	operator= (const fvMeshMover &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from velocityComponent
	TypeName ("velocityComponent")
	Runtime type information. More...

	velocityComponent (const polyMesh &, const dictionary &, const word &type)
	Construct from mesh and dictionary. More...

	velocityComponent (const velocityComponent &)=delete
	Disallow default bitwise copy construction. More...

virtual	~velocityComponent ()
	Destructor. More...

pointScalarField &	pointMotionU ()
	Non-const access to the pointMotionU in order to allow changes. More...

virtual void	movePoints (const pointField &)
	Update local data for geometry changes. More...

virtual void	distribute (const polyDistributionMap &)
	Update corresponding to the given distribution map. More...

void	operator= (const velocityComponent &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from pointMeshMover
	TypeName ("pointMeshMover")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, pointMeshMover, dictionary,(const polyMesh &mesh, const dictionary &dict),(mesh, dict))

	pointMeshMover (const polyMesh &mesh, const word &type)
	Construct from polyMesh and dictionary and type. More...

virtual autoPtr< pointMeshMover >	clone () const
	Clone function. More...

virtual	~pointMeshMover ()
	Destructor. More...

const polyMesh &	poly () const
	Return reference to mesh. More...

virtual void	twoDCorrectPoints (pointField &) const
	Correct point field for reduced-dimensionality cases. More...

virtual bool	solidBodyMotion () const
	Is the motion solid body? I.e., are the volumes and area magnitudes. More...

virtual bool	write () const
	Optionally write motion state information for restart. More...

Additional Inherited Members
Static Public Member Functions inherited from fvMeshMover
static autoPtr< fvMeshMover >	New (fvMesh &)
	Select, construct and return the fvMeshMover. More...

Static Public Member Functions inherited from pointMeshMover
static autoPtr< pointMeshMover >	New (const polyMesh &, const dictionary &)
	Select constructed from polyMesh and dictionary. More...

Protected Member Functions inherited from fvMotionSolver
template<class Type >
wordList	cellMotionBoundaryTypes (const typename PointField< Type >::Boundary &pmUbf) const
	Create the corresponding patch types for cellMotion from those. More...

Protected Attributes inherited from velocityComponent
word	cmptName_
	The component name to solve for. More...

direction	cmpt_
	The component to solve for. More...

pointScalarField	pointMotionU_
	Point motion field. More...

Detailed Description

Mesh motion solver for an fvMesh. Based on solving the cell-centre Laplacian for the given component of the motion velocity.

Source files

velocityComponentLaplacian_fvMotionSolver.H velocityComponentLaplacian_
fvMotionSolver.C

Definition at line 56 of file velocityComponentLaplacian_fvMotionSolver.H.

Constructor & Destructor Documentation

◆ velocityComponentLaplacian() [1/3]

velocityComponentLaplacian	(	fvMesh &	mesh,
		const dictionary &	dict
	)

Construct from fvMesh and dictionary.

Definition at line 89 of file velocityComponentLaplacian_fvMotionSolver.C.

◆ velocityComponentLaplacian() [2/3]

velocityComponentLaplacian	(	const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from polyMesh and dictionary.

Definition at line 59 of file velocityComponentLaplacian_fvMotionSolver.C.

◆ velocityComponentLaplacian() [3/3]

velocityComponentLaplacian ( const velocityComponentLaplacian & )

delete

Disallow default bitwise copy construction.

◆ ~velocityComponentLaplacian()

~velocityComponentLaplacian ( )

Destructor.

Definition at line 101 of file velocityComponentLaplacian_fvMotionSolver.C.

Member Function Documentation

◆ TypeName()

TypeName ( "velocityComponentLaplacian" )

Runtime type information.

◆ cellMotionU()

volScalarField& cellMotionU ( )

inline

Non-const access to the cellMotionU in order to allow changes.

to the boundary motion

Definition at line 102 of file velocityComponentLaplacian_fvMotionSolver.H.

◆ newPoints()

Foam::tmp< Foam::pointField > newPoints ( )

virtual

Return point location obtained from the current motion field.

Implements fvMotionSolver.

Definition at line 108 of file velocityComponentLaplacian_fvMotionSolver.C.

References Foam::component(), volPointInterpolation::interpolate(), Foam::fvm::laplacian(), mesh, DemandDrivenMeshObject< fvMesh, DeletableMeshObject, volPointInterpolation >::New(), points, tmp< T >::ref(), Foam::solve(), and Foam::dimensions::time.

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & map )

virtual

Update corresponding to the given map.

Reimplemented from velocityComponent.

Definition at line 149 of file velocityComponentLaplacian_fvMotionSolver.C.

References mesh, motionDiffusivity::New(), and velocityComponent::topoChange().

Here is the call graph for this function:

◆ mapMesh()

void mapMesh ( const polyMeshMap & map )

virtual

Update from another mesh using the given map.

Reimplemented from velocityComponent.

Definition at line 168 of file velocityComponentLaplacian_fvMotionSolver.C.

References velocityComponent::mapMesh(), mesh, and motionDiffusivity::New().

Here is the call graph for this function:

◆ operator=()

void operator= ( const velocityComponentLaplacian & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/fvMeshMovers/fvMotionSolvers/fvMotionSolvers/velocityComponent/laplacian/velocityComponentLaplacian_fvMotionSolver.H
src/fvMeshMovers/fvMotionSolvers/fvMotionSolvers/velocityComponent/laplacian/velocityComponentLaplacian_fvMotionSolver.C
