emptyPointPatch Class Reference

Empty plane patch. More...

Inheritance diagram for emptyPointPatch:
Collaboration diagram for emptyPointPatch:

Public Member Functions

 TypeName (emptyPolyPatch::typeName_())
 Runtime type information. More...

 emptyPointPatch (const polyPatch &patch, const pointBoundaryMesh &bm)
 Construct from polyPatch. More...

virtual void applyConstraint (const label pointi, pointConstraint &) const
 Accumulate the effect of constraint direction of this patch. More...

- Public Member Functions inherited from facePointPatch
 TypeName (polyPatch::typeName_())
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, facePointPatch, polyPatch,(const polyPatch &patch, const pointBoundaryMesh &bm),(patch, bm))

 facePointPatch (const polyPatch &, const pointBoundaryMesh &)
 Construct from polyPatch. More...

 facePointPatch (const facePointPatch &)=delete
 Disallow default bitwise copy construction. More...

virtual ~facePointPatch ()
 Destructor. More...

const polyPatchpatch () const
 Return the polyPatch. More...

virtual const wordname () const
 Return name. More...

virtual label size () const
 Return size. More...

virtual label index () const
 Return the index of this patch in the pointBoundaryMesh. More...

virtual bool coupled () const
 Return true if this patch field is coupled. More...

virtual const labelListmeshPoints () const
 Return mesh points. More...

virtual const pointFieldlocalPoints () const
 Return pointField of points in patch. More...

virtual const vectorFieldpointNormals () const
 Return point unit normals. More...

void operator= (const facePointPatch &)=delete
 Disallow default bitwise assignment. More...

- Public Member Functions inherited from pointPatch
 TypeName ("basePatch")
 Runtime type information. More...

 pointPatch (const pointBoundaryMesh &bm)

 pointPatch (const pointPatch &)=delete
 Disallow default bitwise copy construction. More...

virtual ~pointPatch ()
 Destructor. More...

const pointBoundaryMeshboundaryMesh () const
 Return boundaryMesh reference. More...

void operator= (const pointPatch &)=delete
 Disallow default bitwise assignment. More...


Additional Inherited Members

- Static Public Member Functions inherited from facePointPatch
static autoPtr< facePointPatchNew (const polyPatch &, const pointBoundaryMesh &)
 Return a pointer to a new patch created on freestore from polyPatch. More...

- Protected Member Functions inherited from facePointPatch
virtual void initCalcGeometry (PstreamBuffers &)
 Initialise the calculation of the patch geometry. More...

virtual void calcGeometry (PstreamBuffers &)
 Calculate the patch geometry. More...

virtual void initMovePoints (PstreamBuffers &, const pointField &)
 Initialise the patches for moving points. More...

virtual void movePoints (PstreamBuffers &, const pointField &)
 Correct patches after moving points. More...

virtual void initTopoChange (PstreamBuffers &)
 Initialise the update of the patch topology. More...

virtual void topoChange (PstreamBuffers &)
 Update of the patch topology. More...

- Protected Attributes inherited from facePointPatch
const polyPatchpolyPatch_
 Reference to the underlying polyPatch. More...


Detailed Description

Empty plane patch.

Source files

Definition at line 49 of file emptyPointPatch.H.

Constructor & Destructor Documentation

◆ emptyPointPatch()

emptyPointPatch ( const polyPatch patch,
const pointBoundaryMesh bm
)
inline

Construct from polyPatch.

Definition at line 63 of file emptyPointPatch.H.

Member Function Documentation

◆ TypeName()

TypeName ( emptyPolyPatch::typeName_()  )

Runtime type information.

◆ applyConstraint()

void applyConstraint ( const label  pointi,
pointConstraint pc
) const
virtual

Accumulate the effect of constraint direction of this patch.

Reimplemented from pointPatch.

Definition at line 46 of file emptyPointPatch.C.

References pointConstraint::applyConstraint(), and facePointPatch::pointNormals().

Here is the call graph for this function:

The documentation for this class was generated from the following files:
