Wave propagation of information through grid. Every iteration information goes through one layer of edges. More...

Inheritance diagram for PointEdgeWave< Type, TrackingData >:

Collaboration diagram for PointEdgeWave< Type, TrackingData >:

Public Member Functions
	PointEdgeWave (const polyMesh &mesh, const labelList &initialPoints, const List< Type > &initialPointsInfo, UList< Type > &allPointInfo, UList< Type > &allEdgeInfo, const label maxIter, TrackingData &td=defaultTrackingData_)
	Construct from mesh, list of changed points with the Type. More...

	PointEdgeWave (const polyMesh &mesh, UList< Type > &allPointInfo, UList< Type > &allEdgeInfo, TrackingData &td=defaultTrackingData_)
	Construct from mesh. Use setPointInfo and iterate() to do. More...

	PointEdgeWave (const PointEdgeWave &)=delete
	Disallow default bitwise copy construction. More...

	~PointEdgeWave ()
	Destructor. More...

UList< Type > &	allPointInfo () const
	Access allPointInfo. More...

UList< Type > &	allEdgeInfo () const
	Access allEdgeInfo. More...

const TrackingData &	data () const
	Additional data to be passed into container. More...

label	getUnsetEdges () const
	Get number of unvisited edges, i.e. edges that were not (yet) More...

label	getUnsetPoints () const

void	setPointInfo (const labelList &changedPoints, const List< Type > &changedPointsInfo)
	Copy initial data into allPointInfo_. More...

label	pointToEdge ()
	Propagate from point to edge. Returns total number of edges. More...

label	edgeToPoint ()
	Propagate from edge to point. Returns total number of points. More...

label	iterate (const label maxIter)
	Iterate until no changes or maxIter reached. Returns actual. More...

void	operator= (const PointEdgeWave &)=delete
	Disallow default bitwise assignment. More...

template<class PatchType >
Foam::label	countPatchType () const

Static Public Member Functions
static scalar	propagationTol ()
	Access to tolerance. More...

static void	setPropagationTol (const scalar tol)
	Change tolerance. More...

Static Public Attributes
static int	defaultTrackingData_ = -1
	Default tracking data to go with default template argument. More...

Detailed Description

template<class Type, class TrackingData = int>
class Foam::PointEdgeWave< Type, TrackingData >

Wave propagation of information through grid. Every iteration information goes through one layer of edges.

Templated on information that is transferred.

Handles parallel and cyclics. Only parallel reasonably tested. Cyclics hardly tested.

Note: whether to propagate depends on the return value of Type::update which returns true (i.e. propagate) if the value changes by more than a certain tolerance.

Note: parallel is done in two steps:

transfer patch points in offset notation, i.e. every patch point is denoted by a patchface label and an index in this face. Receiving end uses that fact that f[0] is shared and order is reversed.
do all non-local shared points by means of reduce of data on them.

Note: cyclics is with offset in patchface as well. Patch is divided into two sub patches and the point-point addressing is never explicitly calculated but instead use is made of the face-face correspondence. (it probably is more efficient to calculate a point-point correspondence at the start and then reuse this; task to be done)

Source files

Definition at line 86 of file PointEdgeWave.H.

Constructor & Destructor Documentation

◆ PointEdgeWave() [1/3]

PointEdgeWave	(	const polyMesh &	mesh,
		const labelList &	initialPoints,
		const List< Type > &	initialPointsInfo,
		UList< Type > &	allPointInfo,
		UList< Type > &	allEdgeInfo,
		const label	maxIter,
		TrackingData &	td = `defaultTrackingData_`
	)

Construct from mesh, list of changed points with the Type.

for these points. Gets work arrays to operate on, one of size number of mesh points, the other number of mesh edges. Iterates until nothing changes or maxIter reached. (maxIter can be 0)

Definition at line 527 of file PointEdgeWave.C.

References Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, PointEdgeWave< Type, TrackingData >::iterate(), primitiveMesh::nEdges(), primitiveMesh::nPoints(), Foam::returnReduce(), PointEdgeWave< Type, TrackingData >::setPointInfo(), and UList< T >::size().

Here is the call graph for this function:

◆ PointEdgeWave() [2/3]

PointEdgeWave	(	const polyMesh &	mesh,
		UList< Type > &	allPointInfo,
		UList< Type > &	allEdgeInfo,
		TrackingData &	td = `defaultTrackingData_`
	)

Construct from mesh. Use setPointInfo and iterate() to do.

actual calculation

Definition at line 600 of file PointEdgeWave.C.

◆ PointEdgeWave() [3/3]

PointEdgeWave ( const PointEdgeWave< Type, TrackingData > & )

delete

Disallow default bitwise copy construction.

◆ ~PointEdgeWave()

~PointEdgeWave

Destructor.

Definition at line 628 of file PointEdgeWave.C.

Member Function Documentation

◆ propagationTol()

static scalar propagationTol ( )

inlinestatic

Access to tolerance.

Definition at line 204 of file PointEdgeWave.H.

◆ setPropagationTol()

static void setPropagationTol ( const scalar tol )

inlinestatic

Change tolerance.

Definition at line 210 of file PointEdgeWave.H.

◆ allPointInfo()

UList<Type>& allPointInfo ( ) const

inline

Access allPointInfo.

Definition at line 255 of file PointEdgeWave.H.

◆ allEdgeInfo()

UList<Type>& allEdgeInfo ( ) const

inline

Access allEdgeInfo.

Definition at line 261 of file PointEdgeWave.H.

◆ data()

const TrackingData& data ( ) const

inline

Additional data to be passed into container.

Definition at line 267 of file PointEdgeWave.H.

Referenced by mappedExtrudedPatchBase::patchLocalPoints().

Here is the caller graph for this function:

◆ getUnsetEdges()

Foam::label getUnsetEdges

Get number of unvisited edges, i.e. edges that were not (yet)

reached from walking across mesh. This can happen from

not enough iterations done
a disconnected mesh
a mesh without walls in it

Definition at line 643 of file PointEdgeWave.C.

◆ getUnsetPoints()

Foam::label getUnsetPoints

Definition at line 636 of file PointEdgeWave.C.

◆ setPointInfo()

void setPointInfo	(	const labelList &	changedPoints,
		const List< Type > &	changedPointsInfo
	)

Copy initial data into allPointInfo_.

Definition at line 651 of file PointEdgeWave.C.

References forAll, and Foam::blendedInterfacialModel::valid().

Referenced by mappedExtrudedPatchBase::patchLocalPoints(), and PointEdgeWave< Type, TrackingData >::PointEdgeWave().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ pointToEdge()

Foam::label pointToEdge

Propagate from point to edge. Returns total number of edges.

(over all processors) changed.

Definition at line 764 of file PointEdgeWave.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::nl, and Foam::reduce().

Here is the call graph for this function:

◆ edgeToPoint()

Foam::label edgeToPoint

Propagate from edge to point. Returns total number of points.

(over all processors) changed.

Definition at line 688 of file PointEdgeWave.C.

References Foam::abort(), Foam::e, Foam::FatalError, FatalErrorInFunction, forAll, Foam::nl, UPstream::parRun(), and Foam::reduce().

Here is the call graph for this function:

◆ iterate()

Foam::label iterate ( const label maxIter )

Iterate until no changes or maxIter reached. Returns actual.

number of iterations.

Definition at line 832 of file PointEdgeWave.C.

References Foam::endl(), Foam::Info, Foam::nl, nPoints, UPstream::parRun(), and Foam::returnReduce().

Referenced by mappedExtrudedPatchBase::patchLocalPoints(), and PointEdgeWave< Type, TrackingData >::PointEdgeWave().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=()

void operator= ( const PointEdgeWave< Type, TrackingData > & )

delete

Disallow default bitwise assignment.

◆ countPatchType()

Foam::label countPatchType ( ) const

Definition at line 233 of file PointEdgeWave.C.

References forAll, nPatches, and patchi.

Member Data Documentation

◆ defaultTrackingData_

int defaultTrackingData_ = -1

static

Default tracking data to go with default template argument.

Definition at line 198 of file PointEdgeWave.H.

The documentation for this class was generated from the following files:

src/meshTools/algorithms/PointEdgeWave/PointEdgeWave.H
src/meshTools/algorithms/PointEdgeWave/PointEdgeWave.C
