Surfaces< DimensionedFieldType > Class Template Reference

Dimensioned field function which sets constant values inside a set of surfaces, and a default value elsewhere. Cutting is used to set fractional values in elements that intersect the surfaces. Foam::searchableSurface is used to define the surface geometry, so triangulated surface files can be used, as well as a list of simple predefined shapes (box, cylinder, ...). More...

Inheritance diagram for Surfaces< DimensionedFieldType >:

Collaboration diagram for Surfaces< DimensionedFieldType >:

Public Member Functions
	TypeName ("surfaces")
	Runtime type information. More...
	Surfaces (const dictionary &dict, DimensionedFieldType &field)
	Construct with dictionary to initialise given field. More...
	Surfaces (const Surfaces &dff, DimensionedFieldType &field)
	Construct a copy for the given field. More...
virtual autoPtr< DimensionedFieldFunction< DimensionedFieldType > >	clone (DimensionedFieldType &field) const
	Construct and return a clone for the specified field. More...
virtual	~Surfaces ()
	Destructor. More...
virtual void	evaluate ()
	Evaluate the function and set the field. More...
virtual void	write (Ostream &os) const
	Write data to dictionary stream. More...
Public Member Functions inherited from DimensionedFieldFunction< DimensionedFieldType >
	TypeName ("DimensionedFieldFunction")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, DimensionedFieldFunction, dictionary,(const dictionary &dict, DimensionedFieldType &field),(dict, field))
	DimensionedFieldFunction (const dictionary &dict, DimensionedFieldType &field)
	Construct with dictionary to initialise given field. More...
	DimensionedFieldFunction (const DimensionedFieldFunction &dff, DimensionedFieldType &field)
	Construct a copy for the given field. More...
	DimensionedFieldFunction (const DimensionedFieldFunction< DimensionedFieldType > &)=delete
	Disallow default bitwise copy construction. More...
virtual autoPtr< DimensionedFieldFunction< DimensionedFieldType > >	clone () const
	Construct and return a clone for the specified field. More...
virtual	~DimensionedFieldFunction ()
	Destructor. More...
virtual bool	update ()
	Update the field if the function has changed and return true. More...
virtual void	reset ()
	Reset the field size. More...
void	operator= (const DimensionedFieldFunction< DimensionedFieldType > &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from DimensionedFieldFunction< DimensionedFieldType >
static autoPtr< DimensionedFieldFunction< DimensionedFieldType > >	New (const dictionary &dict, DimensionedFieldType &field)
	Select null constructed. More...
Protected Attributes inherited from DimensionedFieldFunction< DimensionedFieldType >
DimensionedFieldType &	field_
	Reference to the field the function applies to. More...

Detailed Description

template<class DimensionedFieldType>
class Foam::DimensionedFieldFunctions::Surfaces< DimensionedFieldType >

Dimensioned field function which sets constant values inside a set of surfaces, and a default value elsewhere. Cutting is used to set fractional values in elements that intersect the surfaces. Foam::searchableSurface is used to define the surface geometry, so triangulated surface files can be used, as well as a list of simple predefined shapes (box, cylinder, ...).

Example specification: internalField { type surfaces;

Set a value of one everywhere, except ... defaultValue 1;

surfaces { Set a value of zero in a sphere bubble { type sphere;

centre (0.5 0.5 0.5); radius 0.1;

value 0; }

Set a value of zero where the y coordinate is greater than 1 air { type plane;

point (0 1 0); normal (0 -1 0);

value 0; } } }

Source files

• Surfaces_DimensionedFieldFunction.H Surfaces_
• DimensionedFieldFunction.C

Definition at line 96 of file Surfaces_DimensionedFieldFunction.H.

Constructor & Destructor Documentation

Surfaces() [1/2]

Surfaces	(	const dictionary &	dict,
		DimensionedFieldType &	field
	)

Construct with dictionary to initialise given field.

Definition at line 76 of file Surfaces_DimensionedFieldFunction.C.

Surfaces() [2/2]

Surfaces	(	const Surfaces< DimensionedFieldType > &	dff,
		DimensionedFieldType &	field
	)

Construct a copy for the given field.

Definition at line 91 of file Surfaces_DimensionedFieldFunction.C.

~Surfaces()

virtual ~Surfaces ( )

inlinevirtual

Destructor.

Definition at line 165 of file Surfaces_DimensionedFieldFunction.H.

Member Function Documentation

TypeName()

TypeName

(

"surfaces"

)

Runtime type information.

clone()

virtual autoPtr<DimensionedFieldFunction<DimensionedFieldType> > clone ( DimensionedFieldType &  field ) const

virtual

Construct and return a clone for the specified field.

Implements DimensionedFieldFunction< DimensionedFieldType >.

evaluate()

void evaluate

virtual

Evaluate the function and set the field.

Implements DimensionedFieldFunction< DimensionedFieldType >.

Definition at line 124 of file Surfaces_DimensionedFieldFunction.C.

References Foam::dimless, forAll, IOobject::groupName(), Foam::searchableSurfaces::insideFraction(), Foam::name(), and Foam::New().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Write data to dictionary stream.

Implements DimensionedFieldFunction< DimensionedFieldType >.

Definition at line 152 of file Surfaces_DimensionedFieldFunction.C.

References Foam::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/fields/DimensionedFields/DimensionedFieldFunctions/Surfaces/Surfaces_DimensionedFieldFunction.H
• src/finiteVolume/fields/DimensionedFields/DimensionedFieldFunctions/Surfaces/Surfaces_DimensionedFieldFunction.C
