An implementation of Bsplines. More...
Public Member Functions
BSpline (const pointField &knots, const bool notImplementedClosed=false)
Construct from components. More...
BSpline (const BSpline &)=delete
Disallow default bitwise copy construction. More...
point  position (const scalar lambda) const
Return the point position corresponding to the curve parameter. More...
point  position (const label segment, const scalar lambda) const
Return the point position corresponding to the local parameter. More...
scalar  length () const
Return the length of the curve. More...
void  operator= (const BSpline &)=delete
Disallow default bitwise assignment. More...
Public Member Functions inherited from polyLine
polyLine (const pointField &, const bool notImplementedClosed=false)
Construct from components. More...
polyLine (const polyLine &)=delete
Disallow default bitwise copy construction. More...
const pointField &  points () const
Return constaccess to the controlpoints. More...
label  nSegments () const
Return the number of line segments. More...
point  position (const scalar) const
Return the point position corresponding to the curve parameter. More...
point  position (const label segment, const scalar) const
Return the point position corresponding to the local parameter. More...
scalar  length () const
Return the length of the curve. More...
void  operator= (const polyLine &)=delete
Disallow default bitwise assignment. More...
Additional Inherited Members
Protected Member Functions inherited from polyLine
void  calcParam ()
Precalculate the rational cumulative parameter value. More...
label  localParameter (scalar &lambda) const
Return the line segment and the local parameter [0..1]. More...
Protected Attributes inherited from polyLine
pointField  points_
The control points or ends of each segments. More...
scalar  lineLength_
The real line length. More...
scalarList  param_
The rational (01) cumulative parameter value for each point. More...
An implementation of Bsplines.
In this implementation, the end tangents are created automatically by reflection.
In matrix form, the local interpolation on the interval t=[0..1] is described as follows:
P(t) = 1/6 * [ t^3 t^2 t 1 ] * [ 1 3 3 1 ] * [ P1 ] [ 3 6 3 0 ] [ P0 ] [ 3 0 3 0 ] [ P1 ] [ 1 4 1 0 ] [ P2 ]
Where P1 and P2 represent the neighbouring points or the extrapolated end points. Simple reflection is used to automatically create the end points.
The spline is discretised based on the chord length of the individual segments. In rare cases (sections with very high curvatures), the resulting distribution may be suboptimal.
A future implementation could also handle closed splines.
BSpline  (  const pointField &  knots,
const bool  notImplementedClosed = false

)
Foam::point position  (  const scalar  lambda  )  const
Return the point position corresponding to the curve parameter.
0 <= lambda <= 1
Definition at line 42 of file BSpline.C.
References UList< T >::first(), lambda(), UList< T >::last(), Foam::constant::physicoChemical::mu, and points.
Referenced by BSplineEdge::position().
Foam::point position  (  const label  segment,
const scalar  lambda
)  const
Return the point position corresponding to the local parameter.
0 <= lambda <= 1 on the given segment
Definition at line 60 of file BSpline.C.
References UList< T >::first(), UList< T >::last(), Foam::constant::physicoChemical::mu, and points.
Foam::scalar length  (  )  const
Return the length of the curve.
Definition at line 132 of file BSpline.C.
References NotImplemented.
Referenced by BSplineEdge::length().

delete
Disallow default bitwise assignment.
