CatmullRomSpline Class Reference

An implementation of Catmull-Rom splines (sometimes known as Overhauser splines). More...

Inheritance diagram for CatmullRomSpline:
Collaboration diagram for CatmullRomSpline:

Public Member Functions

 CatmullRomSpline (const pointField &knots, const bool notImplementedClosed=false)
 Construct from components. More...

 CatmullRomSpline (const CatmullRomSpline &)=delete
 Disallow default bitwise copy construction. More...

point position (const scalar lambda) const
 Return the point position corresponding to the curve parameter. More...

point position (const label segment, const scalar lambda) const
 Return the point position corresponding to the local parameter. More...

scalar length () const
 Return the length of the curve. More...

void operator= (const CatmullRomSpline &)=delete
 Disallow default bitwise assignment. More...

- Public Member Functions inherited from polyLine
 polyLine (const pointField &, const bool notImplementedClosed=false)
 Construct from components. More...

 polyLine (const polyLine &)=delete
 Disallow default bitwise copy construction. More...

const pointFieldpoints () const
 Return const-access to the control-points. More...

label nSegments () const
 Return the number of line segments. More...

point position (const scalar) const
 Return the point position corresponding to the curve parameter. More...

point position (const label segment, const scalar) const
 Return the point position corresponding to the local parameter. More...

scalar length () const
 Return the length of the curve. More...

void operator= (const polyLine &)=delete
 Disallow default bitwise assignment. More...


Additional Inherited Members

- Protected Member Functions inherited from polyLine
void calcParam ()
 Precalculate the rational cumulative parameter value. More...

label localParameter (scalar &lambda) const
 Return the line segment and the local parameter [0..1]. More...

- Protected Attributes inherited from polyLine
pointField points_
 The control points or ends of each segments. More...

scalar lineLength_
 The real line length. More...

scalarList param_
 The rational (0-1) cumulative parameter value for each point. More...


Detailed Description

An implementation of Catmull-Rom splines (sometimes known as Overhauser splines).

In this implementation, the end tangents are created automatically by reflection.

In matrix form, the local interpolation on the interval t=[0..1] is described as follows:

P(t) = 1/2 * [ t^3 t^2 t 1 ] * [ -1  3 -3  1 ] * [ P-1 ]
                               [  2 -5  4 -1 ]   [ P0 ]
                               [ -1  0  1  0 ]   [ P1 ]
                               [  0  2  0  0 ]   [ P2 ]

Where P-1 and P2 represent the neighbouring points or the extrapolated end points. Simple reflection is used to automatically create the end points.

The spline is discretised based on the chord length of the individual segments. In rare cases (sections with very high curvatures), the resulting distribution may be sub-optimal.

A future implementation could also handle closed splines.

See also
http://www.algorithmist.net/catmullrom.html provides a nice introduction
Source files

Definition at line 75 of file CatmullRomSpline.H.

Constructor & Destructor Documentation

◆ CatmullRomSpline() [1/2]

CatmullRomSpline ( const pointField knots,
const bool  notImplementedClosed = false
)

Construct from components.

Definition at line 30 of file CatmullRomSpline.C.

◆ CatmullRomSpline() [2/2]

CatmullRomSpline ( const CatmullRomSpline )
delete

Disallow default bitwise copy construction.

Member Function Documentation

◆ position() [1/2]

Foam::point position ( const scalar  lambda) const

Return the point position corresponding to the curve parameter.

0 <= lambda <= 1

Definition at line 42 of file CatmullRomSpline.C.

References UList< T >::first(), lambda(), UList< T >::last(), Foam::constant::physicoChemical::mu, and points.

Referenced by splineEdge::position().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ position() [2/2]

Foam::point position ( const label  segment,
const scalar  lambda
) const

Return the point position corresponding to the local parameter.

0 <= lambda <= 1 on the given segment

Definition at line 60 of file CatmullRomSpline.C.

References UList< T >::first(), UList< T >::last(), Foam::constant::physicoChemical::mu, and points.

Here is the call graph for this function:

◆ length()

Foam::scalar length ( ) const

Return the length of the curve.

Definition at line 132 of file CatmullRomSpline.C.

References NotImplemented.

Referenced by splineEdge::length().

Here is the caller graph for this function:

◆ operator=()

void operator= ( const CatmullRomSpline )
delete

Disallow default bitwise assignment.


The documentation for this class was generated from the following files:
