Public Member Functions | List of all members
hierarchGeomDecomp Class Reference

Does hierarchical decomposition of points. Works by first sorting the points in x direction into equal sized bins, then in y direction and finally in z direction. More...

Inheritance diagram for hierarchGeomDecomp:
Inheritance graph
[legend]
Collaboration diagram for hierarchGeomDecomp:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("hierarchical")
 Runtime type information. More...

 hierarchGeomDecomp (const dictionary &decompositionDict)
 Construct given the decomposition dictionary. More...

virtual ~hierarchGeomDecomp ()
 Destructor. More...

virtual bool parallelAware () const
 Hierarchgeom is aware of processor boundaries. More...

virtual labelList decompose (const pointField &, const scalarField &weights)
 Return for every coordinate the wanted processor number. More...

virtual labelList decompose (const pointField &)
 Without weights. Code for weighted decomposition is a bit complex. More...

virtual labelList decompose (const polyMesh &mesh, const pointField &cc, const scalarField &cWeights)
 Return for every coordinate the wanted processor number. Use the. More...

virtual labelList decompose (const polyMesh &mesh, const pointField &cc)
 Without weights. Code for weighted decomposition is a bit complex. More...

virtual labelList decompose (const labelListList &globalCellCells, const pointField &cc, const scalarField &cWeights)
 Return for every coordinate the wanted processor number. Explicitly. More...

virtual labelList decompose (const labelListList &globalCellCells, const pointField &cc)
 Like decompose but with uniform weights on the cells. More...

- Public Member Functions inherited from geomDecomp
 geomDecomp (const dictionary &decompositionDict, const word &derivedType)
 Construct given the decomposition dictionary. More...

- Public Member Functions inherited from decompositionMethod
 TypeName ("decompositionMethod")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, decompositionMethod, dictionary,(const dictionary &decompositionDict),(decompositionDict))

 decompositionMethod (const dictionary &decompositionDict)
 Construct given the decomposition dictionary. More...

virtual ~decompositionMethod ()
 Destructor. More...

label nDomains () const

virtual labelList decompose (const polyMesh &mesh, const labelList &cellToRegion, const pointField &regionPoints, const scalarField &regionWeights)
 Return for every coordinate the wanted processor number. Gets. More...

virtual labelList decompose (const polyMesh &mesh, const labelList &cellToRegion, const pointField &regionPoints)
 Like decompose but with uniform weights on the regions. More...

void setConstraints (const polyMesh &mesh, boolList &blockedFace, PtrList< labelList > &specifiedProcessorFaces, labelList &specifiedProcessor, List< labelPair > &explicitConnections)
 Helper: extract constraints: More...

void applyConstraints (const polyMesh &mesh, const boolList &blockedFace, const PtrList< labelList > &specifiedProcessorFaces, const labelList &specifiedProcessor, const List< labelPair > &explicitConnections, labelList &finalDecomp)
 Helper: apply constraints to a decomposition. This gives. More...

virtual labelList decompose (const polyMesh &mesh, const scalarField &cellWeights, const boolList &blockedFace, const PtrList< labelList > &specifiedProcessorFaces, const labelList &specifiedProcessor, const List< labelPair > &explicitConnections)

labelList decompose (const polyMesh &mesh, const scalarField &cWeights)
 Decompose a mesh. Apply all constraints from decomposeParDict. More...


Additional Inherited Members

- Static Public Member Functions inherited from decompositionMethod
static autoPtr< decompositionMethodNew (const dictionary &decompositionDict)
 Return a reference to the selected decomposition method. More...

static void calcCellCells (const polyMesh &mesh, const labelList &agglom, const label nLocalCoarse, const bool global, CompactListList< label > &cellCells)
 Helper: determine (local or global) cellCells from mesh. More...

static void calcCellCells (const polyMesh &mesh, const labelList &agglom, const label nLocalCoarse, const bool parallel, CompactListList< label > &cellCells, CompactListList< scalar > &cellCellWeights)
 Helper: determine (local or global) cellCells and face weights. More...

- Protected Attributes inherited from geomDecomp
const dictionarygeomDecomDict_

Vector< labeln_

scalar delta_

tensor rotDelta_

- Protected Attributes inherited from decompositionMethod
const dictionarydecompositionDict_

label nProcessors_

PtrList< decompositionConstraintconstraints_
 Optional constraints. More...


Detailed Description

Does hierarchical decomposition of points. Works by first sorting the points in x direction into equal sized bins, then in y direction and finally in z direction.

Uses single array to hold decomposition which is indexed as if it is a 3 dimensional array:

finalDecomp[i,j,k] is indexed as

i*n[0]*n[1] + j*n[1] + k

E.g. if we're sorting 'xyz': the first sort (over the x-component) determines in which x-domain the point goes. Then for each of the x-domains the points are sorted in y direction and each individual x-domain gets split into three y-domains. And similar for the z-direction.

Since the domains are of equal size the maximum difference in size is n[0]*n[1] (or n[1]*n[2]?) (small anyway)

Source files

Definition at line 66 of file hierarchGeomDecomp.H.

Constructor & Destructor Documentation

◆ hierarchGeomDecomp()

hierarchGeomDecomp ( const dictionary decompositionDict)

Construct given the decomposition dictionary.

Definition at line 762 of file hierarchGeomDecomp.C.

◆ ~hierarchGeomDecomp()

virtual ~hierarchGeomDecomp ( )
inlinevirtual

Destructor.

Definition at line 174 of file hierarchGeomDecomp.H.

Member Function Documentation

◆ TypeName()

TypeName ( "hierarchical"  )

Runtime type information.

◆ parallelAware()

virtual bool parallelAware ( ) const
inlinevirtual

Hierarchgeom is aware of processor boundaries.

Implements decompositionMethod.

Definition at line 181 of file hierarchGeomDecomp.H.

References hierarchGeomDecomp::decompose().

Here is the call graph for this function:

◆ decompose() [1/6]

Foam::labelList decompose ( const pointField points,
const scalarField weights
)
virtual

Return for every coordinate the wanted processor number.

Implements geomDecomp.

Definition at line 718 of file hierarchGeomDecomp.C.

References Foam::e, forAll, Foam::max(), Foam::reduce(), and List< T >::size().

Referenced by hierarchGeomDecomp::decompose(), and hierarchGeomDecomp::parallelAware().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ decompose() [2/6]

Foam::labelList decompose ( const pointField points)
virtual

Without weights. Code for weighted decomposition is a bit complex.

so kept separate for now.

Implements geomDecomp.

Definition at line 678 of file hierarchGeomDecomp.C.

References hierarchGeomDecomp::decompose(), Foam::e, forAll, Foam::max(), Foam::reduce(), and List< T >::size().

Here is the call graph for this function:

◆ decompose() [3/6]

virtual labelList decompose ( const polyMesh mesh,
const pointField cc,
const scalarField cWeights
)
inlinevirtual

Return for every coordinate the wanted processor number. Use the.

mesh connectivity (if needed)

Implements decompositionMethod.

Definition at line 201 of file hierarchGeomDecomp.H.

References hierarchGeomDecomp::decompose().

Here is the call graph for this function:

◆ decompose() [4/6]

virtual labelList decompose ( const polyMesh mesh,
const pointField cc
)
inlinevirtual

Without weights. Code for weighted decomposition is a bit complex.

so kept separate for now.

Reimplemented from decompositionMethod.

Definition at line 212 of file hierarchGeomDecomp.H.

◆ decompose() [5/6]

virtual labelList decompose ( const labelListList globalCellCells,
const pointField cc,
const scalarField cWeights
)
inlinevirtual

Return for every coordinate the wanted processor number. Explicitly.

provided connectivity - does not use mesh_. The connectivity is equal to mesh.cellCells() except for

  • in parallel the cell numbers are global cell numbers (starting from 0 at processor0 and then incrementing all through the processors)
  • the connections are across coupled patches

Implements decompositionMethod.

Definition at line 225 of file hierarchGeomDecomp.H.

References hierarchGeomDecomp::decompose().

Here is the call graph for this function:

◆ decompose() [6/6]

virtual labelList decompose ( const labelListList globalCellCells,
const pointField cc
)
inlinevirtual

Like decompose but with uniform weights on the cells.

Reimplemented from decompositionMethod.

Definition at line 235 of file hierarchGeomDecomp.H.

References hierarchGeomDecomp::decompose().

Here is the call graph for this function:

The documentation for this class was generated from the following files:
