Public Types | Public Member Functions | Protected Member Functions | Protected Attributes | List of all members
buoyantKEpsilon< BasicTurbulenceModel > Class Template Reference

Additional buoyancy generation/dissipation term applied to the k and epsilon equations of the standard k-epsilon model. More...

Inheritance diagram for buoyantKEpsilon< BasicTurbulenceModel >:
Inheritance graph
[legend]
Collaboration diagram for buoyantKEpsilon< BasicTurbulenceModel >:
Collaboration graph
[legend]

Public Types

typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from kEpsilon< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from RASModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel


Public Member Functions

 TypeName ("buoyantKEpsilon")
 Runtime type information. More...

 buoyantKEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)
 Construct from components. More...

virtual ~buoyantKEpsilon ()
 Destructor. More...

virtual bool read ()
 Re-read model coefficients if they have changed. More...

- Public Member Functions inherited from kEpsilon< BasicTurbulenceModel >
 TypeName ("kEpsilon")
 Runtime type information. More...

 kEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)
 Construct from components. More...

virtual ~kEpsilon ()
 Destructor. More...

tmp< volScalarFieldDkEff () const
 Return the effective diffusivity for k. More...

tmp< volScalarFieldDepsilonEff () const
 Return the effective diffusivity for epsilon. More...

virtual tmp< volScalarFieldk () const
 Return the turbulence kinetic energy. More...

virtual tmp< volScalarFieldepsilon () const
 Return the turbulence kinetic energy dissipation rate. More...

virtual void correct ()
 Solve the turbulence equations and correct the turbulence viscosity. More...

- Public Member Functions inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
 eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
 Construct from components. More...

virtual ~eddyViscosity ()
 Destructor. More...

virtual tmp< volScalarFieldnut () const
 Return the turbulence viscosity. More...

virtual tmp< scalarFieldnut (const label patchi) const
 Return the turbulence viscosity on patch. More...

virtual tmp< volSymmTensorFieldR () const
 Return the Reynolds stress tensor. More...

virtual void validate ()
 Validate the turbulence fields after construction. More...

- Public Member Functions inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
 linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
 Construct from components. More...

virtual ~linearViscousStress ()
 Destructor. More...

virtual tmp< volSymmTensorFielddevRhoReff () const
 Return the effective stress tensor. More...

virtual tmp< fvVectorMatrixdivDevRhoReff (volVectorField &U) const
 Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrixdivDevRhoReff (const volScalarField &rho, volVectorField &U) const
 Return the source term for the momentum equation. More...

- Public Member Functions inherited from RASModel< BasicTurbulenceModel >
 TypeName ("RAS")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

 RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
 Construct from components. More...

virtual ~RASModel ()
 Destructor. More...

const dimensionedScalarkMin () const
 Return the lower allowable limit for k (default: small) More...

const dimensionedScalarepsilonMin () const
 Return the lower allowable limit for epsilon (default: small) More...

const dimensionedScalaromegaMin () const
 Return the lower allowable limit for omega (default: small) More...

dimensionedScalarkMin ()
 Allow kMin to be changed. More...

dimensionedScalarepsilonMin ()
 Allow epsilonMin to be changed. More...

dimensionedScalaromegaMin ()
 Allow omegaMin to be changed. More...

virtual const dictionarycoeffDict () const
 Const access to the coefficients dictionary. More...

virtual tmp< volScalarFieldnuEff () const
 Return the effective viscosity. More...

virtual tmp< scalarFieldnuEff (const label patchi) const
 Return the effective viscosity on patch. More...


Protected Member Functions

tmp< volScalarFieldGcoef () const

virtual tmp< fvScalarMatrixkSource () const

virtual tmp< fvScalarMatrixepsilonSource () const

- Protected Member Functions inherited from kEpsilon< BasicTurbulenceModel >
virtual void correctNut ()

- Protected Member Functions inherited from RASModel< BasicTurbulenceModel >
virtual void printCoeffs (const word &type)
 Print model coefficients. More...


Protected Attributes

dimensionedScalar Cg_

- Protected Attributes inherited from kEpsilon< BasicTurbulenceModel >
dimensionedScalar Cmu_

dimensionedScalar C1_

dimensionedScalar C2_

dimensionedScalar C3_

dimensionedScalar sigmak_

dimensionedScalar sigmaEps_

volScalarField k_

volScalarField epsilon_

- Protected Attributes inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
volScalarField nut_

- Protected Attributes inherited from RASModel< BasicTurbulenceModel >
dictionary RASDict_
 RAS coefficients dictionary. More...

Switch turbulence_
 Turbulence on/off flag. More...

Switch printCoeffs_
 Flag to print the model coeffs at run-time. More...

dictionary coeffDict_
 Model coefficients dictionary. More...

dimensionedScalar kMin_
 Lower limit of k. More...

dimensionedScalar epsilonMin_
 Lower limit of epsilon. More...

dimensionedScalar omegaMin_
 Lower limit for omega. More...


Additional Inherited Members

- Static Public Member Functions inherited from RASModel< BasicTurbulenceModel >
static autoPtr< RASModelNew (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)
 Return a reference to the selected RAS model. More...


Detailed Description

template<class BasicTurbulenceModel>
class Foam::RASModels::buoyantKEpsilon< BasicTurbulenceModel >

Additional buoyancy generation/dissipation term applied to the k and epsilon equations of the standard k-epsilon model.

Reference:

    Henkes, R.A.W.M., Van Der Vlugt, F.F. & Hoogendoorn, C.J. (1991).
    Natural Convection Flow in a Square Cavity Calculated with
    Low-Reynolds-Number Turbulence Models.
    Int. J. Heat Mass Transfer, 34, 1543-1557.

This implementation is based on the density rather than temperature gradient extending the applicability to systems in which the density gradient may be generated by variation of composition rather than temperature. Further, the 1/Prt coefficient is replaced by Cg to provide more general control of model.

The default model coefficients are

    buoyantKEpsilonCoeffs
    {
        Cg              1.0;
    }
See also
Foam::RASModels::kEpsilon
Source files

Definition at line 77 of file buoyantKEpsilon.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 106 of file buoyantKEpsilon.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 107 of file buoyantKEpsilon.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 108 of file buoyantKEpsilon.H.

Constructor & Destructor Documentation

◆ buoyantKEpsilon()

buoyantKEpsilon ( const alphaField alpha,
const rhoField rho,
const volVectorField U,
const surfaceScalarField alphaRhoPhi,
const surfaceScalarField phi,
const transportModel transport,
const word propertiesName = turbulenceModel::propertiesName,
const word type = typeName
)

Construct from components.

Definition at line 42 of file buoyantKEpsilon.C.

◆ ~buoyantKEpsilon()

virtual ~buoyantKEpsilon ( )
inlinevirtual

Destructor.

Definition at line 132 of file buoyantKEpsilon.H.

References buoyantKEpsilon< BasicTurbulenceModel >::read().

Here is the call graph for this function:

Member Function Documentation

◆ Gcoef()

tmp< volScalarField > Gcoef ( ) const
protected

Definition at line 102 of file buoyantKEpsilon.C.

References g, and Foam::fvc::grad().

Here is the call graph for this function:

◆ kSource()

tmp< fvScalarMatrix > kSource ( ) const
protectedvirtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 116 of file buoyantKEpsilon.C.

References g, kEpsilon< BasicTurbulenceModel >::kSource(), Foam::mag(), Foam::fvm::SuSp(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ epsilonSource()

tmp< fvScalarMatrix > epsilonSource ( ) const
protectedvirtual

◆ TypeName()

TypeName ( "buoyantKEpsilon< BasicTurbulenceModel >"  )

Runtime type information.

◆ read()

bool read ( )
virtual

Re-read model coefficients if they have changed.

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 85 of file buoyantKEpsilon.C.

Referenced by buoyantKEpsilon< BasicTurbulenceModel >::~buoyantKEpsilon().

Here is the caller graph for this function:

Member Data Documentation

◆ Cg_

dimensionedScalar Cg_
protected

Definition at line 94 of file buoyantKEpsilon.H.


The documentation for this class was generated from the following files:
