Go to the source code of this file.
Namespaces | |
| Foam::tracking | |
| Functions for tracking locations through a mesh. | |
| Foam | |
| Namespace for OpenFOAM. | |
Functions | |
| point | position (const polyMesh &mesh, const barycentric &coordinates, const label celli, const label facei, const label faceTrii, const scalar stepFraction) |
| Return the position given the coordinates and tet topology. More... | |
| barycentric | coordinates (const polyMesh &mesh, const point &position, const label celli, const label facei, const label faceTrii, const scalar stepFraction) |
| Return the coordinates given the position and tet topology. More... | |
| Pair< vector > | faceNormalAndDisplacement (const polyMesh &mesh, const barycentric &coordinates, const label celli, const label facei, const label faceTrii, const scalar stepFraction) |
| Return the normal of the corresponding point on the associated face and. More... | |
| template<class Displacement > | |
| Tuple2< bool, scalar > | toFace (const polyMesh &mesh, const Displacement &displacement, const scalar fraction, barycentric &coordinates, label &celli, label &facei, label &faceTrii, scalar &stepFraction, scalar &stepFractionBehind, label &nTracksBehind, const string &debugPrefix=NullObjectRef< string >()) |
| Track along the displacement for a given fraction of the overall. More... | |
| template<class Displacement > | |
| Tuple2< bool, scalar > | toCell (const polyMesh &mesh, const Displacement &displacement, const scalar fraction, barycentric &coordinates, label &celli, label &facei, label &faceTrii, scalar &stepFraction, scalar &stepFractionBehind, label &nTracksBehind, const string &debugPrefix=NullObjectRef< string >()) |
| As toFace, except that if the track ends on an internal face then this. More... | |
| template<class Displacement > | |
| Tuple2< bool, scalar > | toBoundary (const polyMesh &mesh, const Displacement &displacement, const scalar fraction, barycentric &coordinates, label &celli, label &facei, label &faceTrii, scalar &stepFraction, scalar &stepFractionBehind, label &nTracksBehind, const string &debugPrefix=NullObjectRef< string >()) |
| As toFace, except that the track continues across multiple cells until. More... | |
| bool | locate (const polyMesh &mesh, const point &position, barycentric &coordinates, label &celli, label &facei, label &faceTrii, const scalar stepFraction, const string &debugPrefix=NullObjectRef< string >()) |
| Initialise the location at the given position. Returns whether or not a. More... | |
| void | crossInternalFace (const polyMesh &mesh, barycentric &coordinates, label &celli, label &facei, label &faceTrii) |
| Cross an internal face. More... | |
| void | crossWedge (const wedgePolyPatch &inPatch, barycentric &coordinates, label &celli, label &facei, label &faceTrii, const scalar stepFraction) |
| Cross a wedge patch. More... | |
| void | crossCyclic (const cyclicPolyPatch &inPatch, barycentric &coordinates, label &celli, label &facei, label &faceTrii) |
| Cross a cyclic patch. More... | |
| void | inProcessor (const processorPolyPatch &inPatch, label &celli, label &facei) |
| Initialise crossing of a processor patch. Breaks the topology in order. More... | |
| void | outProcessor (const processorPolyPatch &outPatch, barycentric &coordinates, label &celli, label &facei, label &faceTrii) |
| Complete crossing of a processor patch. Restore the topology. More... | |
Original source file tracking.H
Definition in file tracking.H.
