cutTriTet.H File Reference

Include dependency graph for cutTriTet.H:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	uniformOp< Type >
class	noOp
class	areaOp
class	areaMagOp
class	volumeOp
class	areaIntegrateOp< Type >
class	areaMagIntegrateOp< Type >
class	volumeIntegrateOp< Type >
class	listOp< Type, Size >
class	listOp< Type, Size >::result
	Result class. More...
class	appendOp< Container >
class	opAddResult< Op, Op >
class	opAddResult< noOp, noOp >
class	opAddResult< noOp, Op >
class	opAddResult< Op, noOp >

Namespaces
	Foam
	Namespace for OpenFOAM.
	Foam::cutTriTet

Typedefs
typedef listOp< point, 3 >	listTriOp
typedef listOp< point, 4 >	listTetOp

Functions
template<class Point , class AboveOp , class BelowOp >
cutTriTet::opAddResult< AboveOp, BelowOp >::type	triCut (const FixedList< Point, 3 > &tri, const FixedList< scalar, 3 > &level, const AboveOp &aboveOp, const BelowOp &belowOp)
	Cut a triangle along the zero plane defined by the given levels. Templated. More...
template<class AboveOp , class BelowOp >
cutTriTet::opAddResult< AboveOp, BelowOp >::type	triCut (const FixedList< point, 3 > &tri, const plane &s, const AboveOp &aboveOp, const BelowOp &belowOp)
	As above, but with a plane specifying the location of the cut. More...
template<class Point , class AboveOp , class BelowOp >
cutTriTet::opAddResult< AboveOp, BelowOp >::type	tetCut (const FixedList< Point, 4 > &tet, const FixedList< scalar, 4 > &level, const AboveOp &aboveOp, const BelowOp &belowOp)
	As triCut, but for a tetrahedron. More...
template<class AboveOp , class BelowOp >
cutTriTet::opAddResult< AboveOp, BelowOp >::type	tetCut (const FixedList< point, 4 > &tet, const plane &s, const AboveOp &aboveOp, const BelowOp &belowOp)
	As above, but with a plane specifying the location of the cut. More...

Detailed Description

Original source file cutTriTet.H

Description: Functions which cut triangles and tetrahedra. Generic operations are applied to each half of a cut.

SourceFiles: cutTriTetI.H cutTriTetTemplates.C

Definition in file cutTriTet.H.
