Fifth-order wave model. More...

Inheritance diagram for Stokes5:

Collaboration diagram for Stokes5:

Public Member Functions
	TypeName ("Stokes5")
	Runtime type information. More...

	Stokes5 (const dictionary &dict, const scalar g, const word &modelName=Stokes5::typeName, scalar(*celerityPtr)(const AiryCoeffs &)=&Stokes5::celerity)
	Construct from a dictionary and gravity. More...

virtual autoPtr< waveModel >	clone () const
	Construct a clone. More...

virtual	~Stokes5 ()
	Destructor. More...

virtual scalar	celerity () const
	The wave celerity [m/s]. More...

virtual tmp< scalarField >	elevation (const scalar t, const scalarField &x) const
	Get the wave elevation at a given time and local coordinates. Local. More...

virtual tmp< vector2DField >	velocity (const scalar t, const vector2DField &xz) const
	Get the wave velocity at a given time and local coordinates. Local. More...

Public Member Functions inherited from Stokes2
	TypeName ("Stokes2")
	Runtime type information. More...

	Stokes2 (const dictionary &dict, const scalar g, const word &modelName=Stokes2::typeName, scalar(*celerityPtr)(const AiryCoeffs &)=&Stokes2::celerity)
	Construct from a dictionary and gravity. More...

virtual	~Stokes2 ()
	Destructor. More...

Public Member Functions inherited from Airy
	TypeName ("Airy")
	Runtime type information. More...

	Airy (const Airy &wave)
	Construct a copy. More...

	Airy (const dictionary &dict, const scalar g, const word &modelName=Airy::typeName, scalar(*celerityPtr)(const AiryCoeffs &)=&AiryCoeffs::celerity)
	Construct from a dictionary and gravity. More...

virtual	~Airy ()
	Destructor. More...

scalar	depth () const
	Get the depth. More...

scalar	amplitude (const scalar t) const
	Get the amplitude. More...

scalar	amplitude () const
	Get the amplitude at steady state. More...

scalar	length () const
	Get the length. More...

scalar	phase () const
	Get the phase. More...

virtual void	write (Ostream &os) const
	Write. More...

Public Member Functions inherited from waveModel
	TypeName ("waveModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, waveModel, dictionary,(const dictionary &dict, const scalar g),(dict, g))

	waveModel (const waveModel &wave)
	Construct a copy. More...

	waveModel (const dictionary &dict, const scalar g)
	Construct from a dictionary and gravity. More...

virtual	~waveModel ()
	Destructor. More...

scalar	g () const
	Get the value of gravity. More...

Static Protected Member Functions
static scalar	celerity (const AiryCoeffs &)
	The wave celerity [m/s]. More...

Static Protected Member Functions inherited from Stokes2
static scalar	celerity (const AiryCoeffs &)
	The wave celerity [m/s]. More...

Static Protected Member Functions inherited from Airy
static scalar	celerity (const AiryCoeffs &)
	The wave celerity [m/s]. More...

Additional Inherited Members
Static Public Member Functions inherited from waveModel
static autoPtr< waveModel >	New (const dictionary &dict, const scalar g)
	Select. More...

static autoPtr< waveModel >	New (const word &type, const dictionary &dict, const scalar g)
	Select. More...

Protected Member Functions inherited from Airy
AiryCoeffs	coeffs (const scalar t) const
	Return the wave coefficients. More...

AiryCoeffs	coeffs () const
	Return the wave coefficients at steady state. More...

Detailed Description

Fifth-order wave model.

Reference:

    Fenton, J. D. (1985).
    A fifth-order Stokes theory for steady waves.
    Journal of waterway, port, coastal, and ocean engineering, 111(2),
    216-234.

Usage: The parameters of this model are identical to those used by the Airy model

Constructor & Destructor Documentation

◆ Stokes5()

Stokes5	(	const dictionary &	dict,
		const scalar	g,
		const word &	modelName = `Stokes5::typeName`,
		scalar(*)(const AiryCoeffs &)	celerityPtr = `&Stokes5::celerity`
	)

Construct from a dictionary and gravity.

Definition at line 67 of file Stokes5.C.

Referenced by Stokes5::clone().

Here is the caller graph for this function:

◆ ~Stokes5()

~Stokes5 ( )

virtual

Destructor.

Definition at line 81 of file Stokes5.C.

Member Function Documentation

◆ celerity() [1/2]

Foam::scalar celerity ( const AiryCoeffs & coeffs )

staticprotected

The wave celerity [m/s].

Definition at line 43 of file Stokes5.C.

References AiryCoeffs::amplitude, Stokes2::celerity(), AiryCoeffs::celerity(), Airy::coeffs(), Foam::cosh(), AiryCoeffs::deep(), AiryCoeffs::depth, Foam::endl(), Foam::Info, AiryCoeffs::k(), Foam::log(), Foam::max(), Foam::min(), Foam::pow3(), Foam::pow4(), Foam::pow5(), Foam::fvm::S(), and Foam::sqr().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "Stokes5" )

Runtime type information.

◆ clone()

virtual autoPtr<waveModel> clone ( ) const

inlinevirtual

Construct a clone.

Reimplemented from Stokes2.

Definition at line 94 of file Stokes5.H.

References Stokes5::Stokes5().

Here is the call graph for this function:

◆ celerity() [2/2]

Foam::scalar celerity ( ) const

virtual

The wave celerity [m/s].

Reimplemented from Stokes2.

Definition at line 87 of file Stokes5.C.

◆ elevation()

Foam::tmp< Foam::scalarField > elevation	(	const scalar	t,
		const scalarField &	x
	)		const

virtual

Get the wave elevation at a given time and local coordinates. Local.

x is aligned with the direction of propagation.

Reimplemented from Stokes2.

Definition at line 93 of file Stokes5.C.

References AiryCoeffs::angle(), Foam::cos(), Foam::cosh(), AiryCoeffs::deep(), Stokes2::elevation(), Foam::endl(), Foam::Info, AiryCoeffs::k(), Foam::log(), Foam::max(), Foam::min(), Foam::pow3(), Foam::pow4(), Foam::pow5(), Foam::pow6(), Foam::fvm::S(), Foam::sqr(), Foam::T(), Foam::tanh(), and x.

Here is the call graph for this function:

◆ velocity()

Foam::tmp< Foam::vector2DField > velocity	(	const scalar	t,
		const vector2DField &	xz
	)		const

virtual

Get the wave velocity at a given time and local coordinates. Local.

x is aligned with the direction of propagation, and z with negative gravity.

Reimplemented from Stokes2.

Definition at line 162 of file Stokes5.C.

References Airy::celerity(), Foam::cosh(), AiryCoeffs::deep(), Foam::endl(), Foam::Info, AiryCoeffs::k(), Foam::log(), Foam::max(), Foam::min(), Foam::pow3(), Foam::pow4(), Foam::pow5(), Foam::pow6(), Foam::fvm::S(), Foam::sinh(), Foam::sqr(), Stokes2::velocity(), and AiryCoeffs::vi().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/waves/waveModels/Stokes5/Stokes5.H
src/waves/waveModels/Stokes5/Stokes5.C
