cosine Class Reference

Cosine wall heat flux partitioning model. More...

Inheritance diagram for cosine:

Collaboration diagram for cosine:

Public Member Functions
	TypeName ("cosine")
	Runtime type information. More...
	cosine (const dictionary &dict)
	Construct from a dictionary. More...
	cosine (const cosine &model)
	Copy construct. More...
virtual autoPtr< partitioningModel >	clone () const
	Construct and return a clone. More...
virtual	~cosine ()
	Destructor. More...
virtual tmp< scalarField >	wetFraction (const scalarField &alphaLiquid) const
	Return the wet fraction. More...
virtual tmp< volScalarField::Internal >	wetFraction (const volScalarField::Internal &alphaLiquid) const
	Return the wet fraction. More...
virtual tmp< volScalarField >	wetFraction (const volScalarField &alphaLiquid) const
	Return the wet fraction. More...
virtual void	write (Ostream &os) const
	Write to stream. More...
template<class ScalarFieldType >
Foam::tmp< ScalarFieldType >	calculate (const ScalarFieldType &alphaLiquid) const
Public Member Functions inherited from partitioningModel
	TypeName ("partitioningModel")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, partitioningModel, dictionary,(const dictionary &dict),(dict))
	Declare runtime construction. More...
	partitioningModel ()
	Construct null. More...
	partitioningModel (const partitioningModel &)
	Copy construct. More...
virtual	~partitioningModel ()
	Destructor. More...
void	operator= (const partitioningModel &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from partitioningModel
static autoPtr< partitioningModel >	New (const dictionary &dict)
	Select null constructed. More...

Detailed Description

Cosine wall heat flux partitioning model.

Proposed threshold liquid fractions:

• alphaLiquid1 0.1
• alphaLiquid0 0.05

    Tentner, A., Lo, S., & Kozlov, V. (2006).
    Advances in computational fluid dynamics modeling
    of two-phase flow in boiling water reactor fuel assemblies.
    In International Conference of Nuclear Engineering,
    Miami, Florida, USA.

Source files

• cosine.H
• cosine.C

Definition at line 64 of file cosine.H.

Constructor & Destructor Documentation

cosine() [1/2]

cosine

(

const dictionary &

dict

)

Construct from a dictionary.

Definition at line 80 of file cosine.C.

Referenced by cosine::clone().

Here is the caller graph for this function:

cosine() [2/2]

cosine

(

const cosine &

model

)

Copy construct.

Definition at line 91 of file cosine.C.

~cosine()

~cosine ( )

virtual

Destructor.

Definition at line 104 of file cosine.C.

Member Function Documentation

TypeName()

TypeName

(

"cosine"

)

Runtime type information.

clone()

virtual autoPtr<partitioningModel> clone ( ) const

inlinevirtual

Construct and return a clone.

Implements partitioningModel.

Definition at line 102 of file cosine.H.

References cosine::cosine().

Here is the call graph for this function:

wetFraction() [1/3]

Foam::tmp< Foam::scalarField > wetFraction ( const scalarField &  alphaLiquid ) const

virtual

Return the wet fraction.

Implements partitioningModel.

Definition at line 111 of file cosine.C.

References Foam::fvPatchDistWave::calculate().

Here is the call graph for this function:

wetFraction() [2/3]

Foam::tmp< Foam::volScalarField::Internal > wetFraction ( const volScalarField::Internal &  alphaLiquid ) const

virtual

Return the wet fraction.

Implements partitioningModel.

Definition at line 121 of file cosine.C.

References Foam::fvPatchDistWave::calculate().

Here is the call graph for this function:

wetFraction() [3/3]

Foam::tmp< Foam::volScalarField > wetFraction ( const volScalarField &  alphaLiquid ) const

virtual

Return the wet fraction.

Implements partitioningModel.

Definition at line 131 of file cosine.C.

References Foam::fvPatchDistWave::calculate().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Write to stream.

Reimplemented from partitioningModel.

Definition at line 140 of file cosine.C.

References partitioningModel::write(), and Foam::writeEntry().

Here is the call graph for this function:

calculate()

Foam::tmp<ScalarFieldType> calculate

(

const ScalarFieldType &

alphaLiquid

)

const

Definition at line 53 of file cosine.C.

References Foam::cos(), Foam::neg(), Foam::constant::mathematical::pi(), and Foam::pos0().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• applications/modules/multiphaseEuler/fvModels/wallBoiling/partitioningModels/cosine/cosine.H
• applications/modules/multiphaseEuler/fvModels/wallBoiling/partitioningModels/cosine/cosine.C
