A correlation for nucleation site density. More...

Inheritance diagram for KocamustafaogullariIshiiNucleationSite:

Collaboration diagram for KocamustafaogullariIshiiNucleationSite:

Public Member Functions
	TypeName ("KocamustafaogullariIshii")
	Runtime type information. More...

	KocamustafaogullariIshiiNucleationSite (const dictionary &dict)
	Construct from a dictionary. More...

	KocamustafaogullariIshiiNucleationSite (const KocamustafaogullariIshiiNucleationSite &model)
	Copy construct. More...

virtual autoPtr< nucleationSiteModel >	clone () const
	Construct and return a clone. More...

virtual	~KocamustafaogullariIshiiNucleationSite ()
	Destructor. More...

virtual tmp< scalarField >	nucleationSiteDensity (const phaseModel &liquid, const phaseModel &vapour, const label patchi, const scalarField &Tl, const scalarField &Tsatw, const scalarField &L, const scalarField &dDep, const scalarField &fDep) const
	Calculate and return the nucleation-site density. More...

virtual tmp< volScalarField::Internal >	nucleationSiteDensity (const phaseModel &liquid, const phaseModel &vapor, const phaseModel &solid, const volScalarField::Internal &Tf, const volScalarField::Internal &Tsatw, const volScalarField::Internal &L, const volScalarField::Internal &dDep, const volScalarField::Internal &fDep) const
	Calculate and return the nucleation-site density. More...

virtual tmp< volScalarField >	nucleationSiteDensity (const phaseModel &liquid, const phaseModel &vapour, const phaseModel &solid, const volScalarField &Tf, const volScalarField &Tsatw, const volScalarField &L, const volScalarField &dDep, const volScalarField &fDep) const
	Calculate and return the nucleation-site density. More...

virtual void	write (Ostream &os) const
	Write to stream. More...

template<class ScalarFieldType >
Foam::tmp< ScalarFieldType >	calculate (const ScalarFieldType &Tsatw, const ScalarFieldType &L, const ScalarFieldType &dDep, const ScalarFieldType &Tw, const ScalarFieldType &rhoLiquid, const ScalarFieldType &rhoVapour, const ScalarFieldType &sigma) const

Public Member Functions inherited from nucleationSiteModel
	TypeName ("nucleationSiteModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, nucleationSiteModel, dictionary,(const dictionary &dict),(dict))
	Declare runtime construction. More...

	nucleationSiteModel ()
	Construct null. More...

	nucleationSiteModel (const nucleationSiteModel &model)
	Copy construct. More...

virtual	~nucleationSiteModel ()
	Destructor. More...

void	operator= (const nucleationSiteModel &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from nucleationSiteModel
static autoPtr< nucleationSiteModel >	New (const dictionary &dict)
	Select null constructed. More...

Detailed Description

A correlation for nucleation site density.

Reference:

    Kocamustafaogullari, G., & Ishii, M. (1983).
    Interfacial area and nucleation site density in boiling systems.
    International Journal of Heat and Mass Transfer, 26(9), 1377-1387.

Source files

Definition at line 59 of file KocamustafaogullariIshiiNucleationSite.H.

Constructor & Destructor Documentation

◆ KocamustafaogullariIshiiNucleationSite() [1/2]

KocamustafaogullariIshiiNucleationSite ( const dictionary & dict )

Construct from a dictionary.

Definition at line 92 of file KocamustafaogullariIshiiNucleationSite.C.

Referenced by KocamustafaogullariIshiiNucleationSite::clone().

Here is the caller graph for this function:

◆ KocamustafaogullariIshiiNucleationSite() [2/2]

KocamustafaogullariIshiiNucleationSite ( const KocamustafaogullariIshiiNucleationSite & model )

Copy construct.

Definition at line 103 of file KocamustafaogullariIshiiNucleationSite.C.

◆ ~KocamustafaogullariIshiiNucleationSite()

~KocamustafaogullariIshiiNucleationSite ( )

virtual

Destructor.

Definition at line 116 of file KocamustafaogullariIshiiNucleationSite.C.

Member Function Documentation

◆ TypeName()

TypeName ( "KocamustafaogullariIshii" )

Runtime type information.

◆ clone()

virtual autoPtr<nucleationSiteModel> clone ( ) const

inlinevirtual

Construct and return a clone.

Implements nucleationSiteModel.

Definition at line 102 of file KocamustafaogullariIshiiNucleationSite.H.

References KocamustafaogullariIshiiNucleationSite::KocamustafaogullariIshiiNucleationSite().

Here is the call graph for this function:

◆ nucleationSiteDensity() [1/3]

Foam::tmp< Foam::scalarField > nucleationSiteDensity	(	const phaseModel &	liquid,
		const phaseModel &	vapour,
		const label	patchi,
		const scalarField &	Tl,
		const scalarField &	Tsatw,
		const scalarField &	L,
		const scalarField &	dDep,
		const scalarField &	fDep
	)		const

virtual

Calculate and return the nucleation-site density.

Implements nucleationSiteModel.

Definition at line 125 of file KocamustafaogullariIshiiNucleationSite.C.

References GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), Foam::fvPatchDistWave::calculate(), patchi, phaseModel::rho(), liquid::rho(), and liquid::sigma().

Here is the call graph for this function:

◆ nucleationSiteDensity() [2/3]

Foam::tmp< Foam::volScalarField::Internal > nucleationSiteDensity	(	const phaseModel &	liquid,
		const phaseModel &	vapor,
		const phaseModel &	solid,
		const volScalarField::Internal &	Tf,
		const volScalarField::Internal &	Tsatw,
		const volScalarField::Internal &	L,
		const volScalarField::Internal &	dDep,
		const volScalarField::Internal &	fDep
	)		const

virtual

Calculate and return the nucleation-site density.

Implements nucleationSiteModel.

Definition at line 162 of file KocamustafaogullariIshiiNucleationSite.C.

References Foam::fvPatchDistWave::calculate(), phaseModel::rho(), liquid::rho(), and liquid::sigma().

Here is the call graph for this function:

◆ nucleationSiteDensity() [3/3]

Foam::tmp< Foam::volScalarField > nucleationSiteDensity	(	const phaseModel &	liquid,
		const phaseModel &	vapour,
		const phaseModel &	solid,
		const volScalarField &	Tf,
		const volScalarField &	Tsatw,
		const volScalarField &	L,
		const volScalarField &	dDep,
		const volScalarField &	fDep
	)		const

virtual

Calculate and return the nucleation-site density.

Implements nucleationSiteModel.

Definition at line 189 of file KocamustafaogullariIshiiNucleationSite.C.

References Foam::fvPatchDistWave::calculate(), phaseModel::rho(), liquid::rho(), and liquid::sigma().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write to stream.

Reimplemented from nucleationSiteModel.

Definition at line 215 of file KocamustafaogullariIshiiNucleationSite.C.

References token::END_STATEMENT, Foam::nl, nucleationSiteModel::write(), and Foam::writeKeyword().

Here is the call graph for this function:

◆ calculate()

Foam::tmp<ScalarFieldType> calculate	(	const ScalarFieldType &	Tsatw,
		const ScalarFieldType &	L,
		const ScalarFieldType &	dDep,
		const ScalarFieldType &	Tw,
		const ScalarFieldType &	rhoLiquid,
		const ScalarFieldType &	rhoVapour,
		const ScalarFieldType &	sigma
	)		const

Definition at line 55 of file KocamustafaogullariIshiiNucleationSite.C.

References Foam::dimTemperature, f(), Foam::max(), Foam::pow(), Foam::constant::physicoChemical::sigma, and Foam::sqr().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

applications/modules/multiphaseEuler/fvModels/wallBoiling/nucleationSiteModels/KocamustafaogullariIshiiNucleationSite/KocamustafaogullariIshiiNucleationSite.H
applications/modules/multiphaseEuler/fvModels/wallBoiling/nucleationSiteModels/KocamustafaogullariIshiiNucleationSite/KocamustafaogullariIshiiNucleationSite.C
