This source condition creates a uniform fixed value source term in the surface-area-volume-ratio (kappa) equations of the fractal shape model of population balance. More...

Inheritance diagram for uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource:

[legend]

Collaboration diagram for uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource:

[legend]

Public Member Functions
	TypeName ("uniformFixedValueSurfaceAreaVolumeRatio")
	Runtime type information. More...

	uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource (const DimensionedField< scalar, volMesh > &, const dictionary &dict)
	Construct from internal field and dictionary. More...

	uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource (const uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...

virtual autoPtr< fvScalarFieldSource >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

virtual	~uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource ()
	Destructor. More...

virtual tmp< DimensionedField< scalar, volMesh > >	sourceValue (const fvSource &model, const DimensionedField< scalar, volMesh > &source) const
	Return the source value. More...

virtual tmp< scalarField >	sourceValue (const fvSource &model, const scalarField &source, const labelUList &cells) const
	Return the source value. More...

virtual tmp< DimensionedField< scalar, volMesh > >	internalCoeff (const fvSource &model, const DimensionedField< scalar, volMesh > &source) const
	Return the internal coefficient. More...

virtual tmp< scalarField >	internalCoeff (const fvSource &model, const scalarField &source, const labelUList &cells) const
	Return the internal coefficient. More...

virtual void	write (Ostream &) const
	Write. More...

Public Member Functions inherited from secondaryPropertyFvScalarFieldSource
	secondaryPropertyFvScalarFieldSource (const DimensionedField< scalar, volMesh > &)
	Construct from internal field. More...

const UPtrList< diameterModels::sizeGroup > &	fis () const
	Return the list of size-groups. More...

label	i () const
	Return the index of this group. More...

const diameterModels::sizeGroup &	fi (const label deltai=0) const
	Return a size-group. More...

template<class ModelType >
const volScalarField &	fld (const label deltai=0) const
	Return a secondary property field. More...

template<class ModelType >
const ModelType &	model (const label deltai=0) const
	Return a secondary property model. More...

template<class ModelType >
const Foam::volScalarField &	fld (const label deltai) const

Detailed Description

This source condition creates a uniform fixed value source term in the surface-area-volume-ratio (kappa) equations of the fractal shape model of population balance.

Usage

Example of the source condition specification:

<sourceName>
{
    type            uniformFixedValueSurfaceAreaVolumeRatio;
    libs            ("libmultiphaseEulerFvModels.so");
    uniformValue    1.5e10;
}

Source files

Definition at line 63 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.H.

Constructor & Destructor Documentation

◆ uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource() [1/2]

uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource	(	const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from internal field and dictionary.

Definition at line 32 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.C.

◆ uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource() [2/2]

uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource	(	const uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource &	field,
		const DimensionedField< scalar, volMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 54 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.C.

◆ ~uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource()

~uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource ( )

virtual

Destructor.

Definition at line 69 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.C.

Member Function Documentation

◆ TypeName()

TypeName ( "uniformFixedValueSurfaceAreaVolumeRatio" )

Runtime type information.

◆ clone()

virtual autoPtr<fvScalarFieldSource> clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 99 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.H.

◆ sourceValue() [1/2]

Foam::tmp< Foam::DimensionedField< Foam::scalar, Foam::volMesh > > sourceValue	(	const fvSource &	model,
		const DimensionedField< scalar, volMesh > &	source
	)		const

virtual

Return the source value.

Definition at line 77 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.C.

References Foam::dimensions(), and fvModel::name().

Here is the call graph for this function:

◆ sourceValue() [2/2]

Foam::tmp< Foam::scalarField > sourceValue	(	const fvSource &	model,
		const scalarField &	source,
		const labelUList &	cells
	)		const

virtual

Return the source value.

Definition at line 95 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.C.

References cells, and fvModel::name().

Here is the call graph for this function:

◆ internalCoeff() [1/2]

Foam::tmp< Foam::DimensionedField< Foam::scalar, Foam::volMesh > > internalCoeff	(	const fvSource &	model,
		const DimensionedField< scalar, volMesh > &	source
	)		const

virtual

Return the internal coefficient.

Definition at line 110 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.C.

References Foam::dimless, fvModel::name(), and DimensionedField< Type, GeoMesh, PrimitiveField >::New().

Here is the call graph for this function:

◆ internalCoeff() [2/2]

Foam::tmp< Foam::scalarField > internalCoeff	(	const fvSource &	model,
		const scalarField &	source,
		const labelUList &	cells
	)		const

virtual

Return the internal coefficient.

Definition at line 128 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.C.

References List< T >::size().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write.

Definition at line 140 of file uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.C.

References Foam::dimensions(), Foam::vtkWriteOps::write(), and Foam::writeEntry().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

applications/modules/multiphaseEuler/populationBalance/derivedFvFieldSources/uniformFixedValueSurfaceAreaVolumeRatio/uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.H
applications/modules/multiphaseEuler/populationBalance/derivedFvFieldSources/uniformFixedValueSurfaceAreaVolumeRatio/uniformFixedValueSurfaceAreaVolumeRatioFvScalarFieldSource.C
