uniformDensityHydrostaticPressureFvPatchScalarField Class Reference

This boundary condition provides a hydrostatic pressure condition, calculated as: More...

Inheritance diagram for uniformDensityHydrostaticPressureFvPatchScalarField:
Inheritance graph
[legend]
Collaboration diagram for uniformDensityHydrostaticPressureFvPatchScalarField:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("uniformDensityHydrostaticPressure")
 Runtime type information. More...

 uniformDensityHydrostaticPressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 uniformDensityHydrostaticPressureFvPatchScalarField (const uniformDensityHydrostaticPressureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
 Construct by mapping given. More...

 uniformDensityHydrostaticPressureFvPatchScalarField (const uniformDensityHydrostaticPressureFvPatchScalarField &)=delete
 Disallow copy without setting internal field reference. More...

 uniformDensityHydrostaticPressureFvPatchScalarField (const uniformDensityHydrostaticPressureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField > clone (const DimensionedField< scalar, volMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

scalar rho () const
 Return the constant density in the far-field. More...

scalar & rho ()
 Return reference to the constant density in the far-field. More...

scalar pRef () const
 Return the reference pressure. More...

scalar & pRef ()
 Return reference to the reference pressure to allow adjustment. More...

const vector & pRefPoint () const
 Return the pressure reference location. More...

vector & pRefPoint ()
 Return reference to the pressure reference location. More...

virtual void updateCoeffs ()
 Update the coefficients associated with the patch field. More...

virtual void write (Ostream &) const
 Write. More...


Detailed Description

This boundary condition provides a hydrostatic pressure condition, calculated as:

\[ p_{hyd} = p_{ref} + \rho_{ref} g (x - x_{ref}) \]

where

$ p_{hyd} $ = Hydrostatic pressure [Pa]
$ p_{ref} $ = Reference pressure [Pa]
$ x_{ref} $ = Reference point in Cartesian co-ordinates
$ \rho_{ref} $ = Density (assumed uniform)
$ g $ = Acceleration due to gravity [m/s^2]
Usage
Property Description Required Default value
rhoRef Uniform density [kg/m^3] yes
pRef Reference pressure [Pa] yes
pRefPoint Reference pressure location no hRef
value Initial value no pRef

Example of the boundary condition specification:

    <patchName>
    {
        type            uniformDensityHydrostaticPressure;
        rhoRef          1000;
        pRef            1e5;
        pRefPoint       (0 0 0);
    }
Source files

Definition at line 127 of file uniformDensityHydrostaticPressureFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ uniformDensityHydrostaticPressureFvPatchScalarField() [1/4]

uniformDensityHydrostaticPressureFvPatchScalarField ( const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const dictionary &  dict
)

Construct from patch, internal field and dictionary.

Definition at line 35 of file uniformDensityHydrostaticPressureFvPatchScalarField.C.

References dict, DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), fvPatchField< Type >::operator, fvPatchField< Type >::operator=(), and p.

Here is the call graph for this function:

◆ uniformDensityHydrostaticPressureFvPatchScalarField() [2/4]

uniformDensityHydrostaticPressureFvPatchScalarField ( const uniformDensityHydrostaticPressureFvPatchScalarField &  ptf,
const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const fieldMapper &  mapper
)

Construct by mapping given.

uniformDensityHydrostaticPressureFvPatchScalarField onto a new patch

Definition at line 63 of file uniformDensityHydrostaticPressureFvPatchScalarField.C.

◆ uniformDensityHydrostaticPressureFvPatchScalarField() [3/4]

uniformDensityHydrostaticPressureFvPatchScalarField ( const uniformDensityHydrostaticPressureFvPatchScalarField &  )
delete

Disallow copy without setting internal field reference.

◆ uniformDensityHydrostaticPressureFvPatchScalarField() [4/4]

uniformDensityHydrostaticPressureFvPatchScalarField ( const uniformDensityHydrostaticPressureFvPatchScalarField &  ptf,
const DimensionedField< scalar, volMesh > &  iF
)

Copy constructor setting internal field reference.

Definition at line 80 of file uniformDensityHydrostaticPressureFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "uniformDensityHydrostaticPressure"  )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 186 of file uniformDensityHydrostaticPressureFvPatchScalarField.H.

◆ rho() [1/2]

scalar rho ( ) const
inline

Return the constant density in the far-field.

Definition at line 207 of file uniformDensityHydrostaticPressureFvPatchScalarField.H.

◆ rho() [2/2]

scalar& rho ( )
inline

Return reference to the constant density in the far-field.

to allow adjustment

Definition at line 214 of file uniformDensityHydrostaticPressureFvPatchScalarField.H.

◆ pRef() [1/2]

scalar pRef ( ) const
inline

Return the reference pressure.

Definition at line 220 of file uniformDensityHydrostaticPressureFvPatchScalarField.H.

◆ pRef() [2/2]

scalar& pRef ( )
inline

Return reference to the reference pressure to allow adjustment.

Definition at line 226 of file uniformDensityHydrostaticPressureFvPatchScalarField.H.

◆ pRefPoint() [1/2]

const vector& pRefPoint ( ) const
inline

Return the pressure reference location.

Definition at line 232 of file uniformDensityHydrostaticPressureFvPatchScalarField.H.

◆ pRefPoint() [2/2]

vector& pRefPoint ( )
inline

Return reference to the pressure reference location.

to allow adjustment

Definition at line 239 of file uniformDensityHydrostaticPressureFvPatchScalarField.H.

◆ updateCoeffs()

void updateCoeffs ( )
virtual

Update the coefficients associated with the patch field.

Definition at line 97 of file uniformDensityHydrostaticPressureFvPatchScalarField.C.

References Foam::mag(), and UniformDimensionedField< Type >::value().

Here is the call graph for this function:

◆ write()

void write ( Ostream &  os) const
virtual

Write.

Definition at line 127 of file uniformDensityHydrostaticPressureFvPatchScalarField.C.

References fvPatchField< Type >::write(), and Foam::writeEntry().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
