dispersedTurbulentDispersionModel Class Reference

Inheritance diagram for dispersedTurbulentDispersionModel:

Collaboration diagram for dispersedTurbulentDispersionModel:

Public Member Functions
	dispersedTurbulentDispersionModel (const dictionary &dict, const phaseInterface &interface)
virtual	~dispersedTurbulentDispersionModel ()
	Destructor. More...
const phaseCompressible::momentumTransportModel &	continuousTurbulence () const
	Return a reference to the turbulence model for the continuous phase. More...
Public Member Functions inherited from turbulentDispersionModel
	TypeName ("turbulentDispersionModel")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, turbulentDispersionModel, dictionary,(const dictionary &dict, const phaseInterface &interface),(dict, interface))
	turbulentDispersionModel (const dictionary &dict, const phaseInterface &interface)
	Construct from a dictionary and an interface. More...
virtual	~turbulentDispersionModel ()
	Destructor. More...
virtual tmp< volScalarField >	D () const =0
	Return the turbulent diffusivity multiplying the gradient of the. More...

Protected Attributes
const dispersedPhaseInterface	interface_
	Interface. More...

Additional Inherited Members
Static Public Member Functions inherited from turbulentDispersionModel
static autoPtr< turbulentDispersionModel >	New (const dictionary &dict, const phaseInterface &interface, const bool outer=true)
Static Public Attributes inherited from turbulentDispersionModel
static const dimensionSet	dimD
	Diffusivity dimensions. More...

Detailed Description

Definition at line 53 of file dispersedTurbulentDispersionModel.H.

Constructor & Destructor Documentation

dispersedTurbulentDispersionModel()

dispersedTurbulentDispersionModel	(	const dictionary &	dict,
		const phaseInterface &	interface
	)

Definition at line 30 of file dispersedTurbulentDispersionModel.C.

~dispersedTurbulentDispersionModel()

~dispersedTurbulentDispersionModel ( )

virtual

Destructor.

Definition at line 47 of file dispersedTurbulentDispersionModel.C.

Member Function Documentation

continuousTurbulence()

const Foam::phaseCompressible::momentumTransportModel & continuousTurbulence

(

)

const

Return a reference to the turbulence model for the continuous phase.

Definition at line 55 of file dispersedTurbulentDispersionModel.C.

References IOobject::groupName(), objectRegistry::lookupObject(), and momentumTransportModel::mesh().

Here is the call graph for this function:

Member Data Documentation

interface_

const dispersedPhaseInterface interface_

protected

Interface.

Definition at line 62 of file dispersedTurbulentDispersionModel.H.

---

The documentation for this class was generated from the following files:

• applications/modules/multiphaseEuler/phaseSystem/interfacialModels/turbulentDispersionModels/dispersedTurbulentDispersionModel/dispersedTurbulentDispersionModel.H
• applications/modules/multiphaseEuler/phaseSystem/interfacialModels/turbulentDispersionModels/dispersedTurbulentDispersionModel/dispersedTurbulentDispersionModel.C
