Eddy-diffusivity based energy gradient heat flux model for RAS or LES of turbulent flow. Specie fluxes are computed assuming a unity turbulent Lewis number. More...

Inheritance diagram for unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >:

[legend]

Collaboration diagram for unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >:

[legend]

Public Types
typedef TurbulenceThermophysicalTransportModel::alphaField	alphaField

typedef TurbulenceThermophysicalTransportModel::momentumTransportModel	momentumTransportModel

typedef TurbulenceThermophysicalTransportModel::thermoModel	thermoModel

Public Member Functions
	TypeName ("unityLewisEddyDiffusivity")
	Runtime type information. More...

	unityLewisEddyDiffusivity (const momentumTransportModel &momentumTransport, const thermoModel &thermo, const bool allowDefaultPrt=false)
	Construct from a momentum transport model and a thermo model. More...

	unityLewisEddyDiffusivity (const word &type, const momentumTransportModel &momentumTransport, const thermoModel &thermo, const bool allowDefaultPrt=false)
	Construct from a type name, a momentum transport model and a thermo. More...

virtual	~unityLewisEddyDiffusivity ()
	Destructor. More...

virtual bool	read ()
	Read thermophysicalTransport dictionary. More...

virtual tmp< volScalarField >	alphat () const
	Turbulent thermal diffusivity for enthalpy [kg/m/s]. More...

virtual tmp< scalarField >	alphat (const label patchi) const
	Turbulent thermal diffusivity for enthalpy for a patch [kg/m/s]. More...

virtual tmp< volScalarField >	kappaEff () const
	Effective thermal turbulent conductivity. More...

virtual tmp< scalarField >	kappaEff (const label patchi) const
	Effective thermal turbulent conductivity. More...

virtual tmp< scalarField >	alphaEff (const label patchi) const
	Effective thermal turbulent diffusivity. More...

virtual tmp< volScalarField >	DEff (const volScalarField &Yi) const
	Effective mass diffusion coefficient. More...

virtual tmp< scalarField >	DEff (const volScalarField &Yi, const label patchi) const
	Effective mass diffusion coefficient. More...

virtual tmp< surfaceScalarField >	q () const
	Return the heat flux [W/m^2]. More...

virtual tmp< scalarField >	q (const label patchi) const
	Return the patch heat flux [W/m^2]. More...

virtual tmp< fvScalarMatrix >	divq (volScalarField &he) const
	Return the source term for the energy equation. More...

virtual tmp< surfaceScalarField >	j (const volScalarField &Yi) const
	Return the specie flux for the given specie mass-fraction [kg/m^2/s]. More...

virtual tmp< scalarField >	j (const volScalarField &Yi, const label patchi) const
	Return the specie flux. More...

virtual tmp< fvScalarMatrix >	divj (volScalarField &Yi) const
	Return the source term for the given specie mass-fraction equation. More...

virtual void	predict ()
	Correct the unityLewisEddyDiffusivity viscosity. More...

Protected Member Functions
virtual void	correctAlphat ()

tmp< volScalarField >	alphaEff () const

Protected Attributes
dimensionedScalar	Prt_
	Turbulent Prandtl number []. More...

volScalarField	alphat_
	Turbulent thermal diffusivity of enthalpy [kg/m/s]. More...

Detailed Description

template<class TurbulenceThermophysicalTransportModel>
class Foam::turbulenceThermophysicalTransportModels::unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >

Eddy-diffusivity based energy gradient heat flux model for RAS or LES of turbulent flow. Specie fluxes are computed assuming a unity turbulent Lewis number.

Usage

LES
{
    model           unityLewisEddyDiffusivity;
    Prt             0.85;
}

Source files

Definition at line 60 of file unityLewisEddyDiffusivity.H.

Member Typedef Documentation

◆ alphaField

typedef TurbulenceThermophysicalTransportModel::alphaField alphaField

Definition at line 98 of file unityLewisEddyDiffusivity.H.

◆ momentumTransportModel

typedef TurbulenceThermophysicalTransportModel::momentumTransportModel momentumTransportModel

Definition at line 102 of file unityLewisEddyDiffusivity.H.

◆ thermoModel

typedef TurbulenceThermophysicalTransportModel::thermoModel thermoModel

Definition at line 105 of file unityLewisEddyDiffusivity.H.

Constructor & Destructor Documentation

◆ unityLewisEddyDiffusivity() [1/2]

unityLewisEddyDiffusivity	(	const momentumTransportModel &	momentumTransport,
		const thermoModel &	thermo,
		const bool	allowDefaultPrt = `false`
	)

Construct from a momentum transport model and a thermo model.

Definition at line 53 of file unityLewisEddyDiffusivity.C.

◆ unityLewisEddyDiffusivity() [2/2]

unityLewisEddyDiffusivity	(	const word &	type,
		const momentumTransportModel &	momentumTransport,
		const thermoModel &	thermo,
		const bool	allowDefaultPrt = `false`
	)

Construct from a type name, a momentum transport model and a thermo.

model, and whether to default the turbulent Prandtl number to one if it is not specified

Definition at line 72 of file unityLewisEddyDiffusivity.C.

◆ ~unityLewisEddyDiffusivity()

virtual ~unityLewisEddyDiffusivity ( )

inlinevirtual

Destructor.

Definition at line 135 of file unityLewisEddyDiffusivity.H.

Member Function Documentation

◆ correctAlphat()

void correctAlphat

protectedvirtual

Definition at line 40 of file unityLewisEddyDiffusivity.C.

◆ alphaEff() [1/2]

tmp<volScalarField> alphaEff ( ) const

inlineprotected

Definition at line 85 of file unityLewisEddyDiffusivity.H.

References unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphat(), Foam::constant::electromagnetic::kappa, GeometricField< Type, GeoMesh, PrimitiveField >::New(), and thermo.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >" )

Runtime type information.

◆ read()

bool read

virtual

Read thermophysicalTransport dictionary.

Reimplemented in nonUnityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >.

Definition at line 117 of file unityLewisEddyDiffusivity.C.

References Foam::blockMeshTools::read().

Here is the call graph for this function:

◆ alphat() [1/2]

virtual tmp<volScalarField> alphat ( ) const

inlinevirtual

Turbulent thermal diffusivity for enthalpy [kg/m/s].

Definition at line 145 of file unityLewisEddyDiffusivity.H.

References unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphat_.

Referenced by unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphaEff(), and unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphat().

Here is the caller graph for this function:

◆ alphat() [2/2]

virtual tmp<scalarField> alphat ( const label patchi ) const

inlinevirtual

Turbulent thermal diffusivity for enthalpy for a patch [kg/m/s].

Definition at line 151 of file unityLewisEddyDiffusivity.H.

References unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphat(), and patchi.

Here is the call graph for this function:

◆ kappaEff() [1/2]

virtual tmp<volScalarField> kappaEff ( ) const

inlinevirtual

Effective thermal turbulent conductivity.

of mixture [W/m/K]

Definition at line 158 of file unityLewisEddyDiffusivity.H.

◆ kappaEff() [2/2]

virtual tmp<scalarField> kappaEff ( const label patchi ) const

inlinevirtual

Effective thermal turbulent conductivity.

of mixture for patch [W/m/K]

Definition at line 165 of file unityLewisEddyDiffusivity.H.

◆ alphaEff() [2/2]

virtual tmp<scalarField> alphaEff ( const label patchi ) const

inlinevirtual

Effective thermal turbulent diffusivity.

of mixture for a patch [kg/m/s]

Definition at line 174 of file unityLewisEddyDiffusivity.H.

◆ DEff() [1/2]

virtual tmp<volScalarField> DEff ( const volScalarField & Yi ) const

inlinevirtual

Effective mass diffusion coefficient.

for a given specie mass-fraction [kg/m/s]

Reimplemented in nonUnityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >.

Definition at line 184 of file unityLewisEddyDiffusivity.H.

◆ DEff() [2/2]

virtual tmp<scalarField> DEff	(	const volScalarField &	Yi,
		const label	patchi
	)		const

inlinevirtual

Effective mass diffusion coefficient.

for a given specie mass-fraction for patch [kg/m/s]

Reimplemented in nonUnityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >.

Definition at line 195 of file unityLewisEddyDiffusivity.H.

◆ q() [1/2]

tmp< surfaceScalarField > q

virtual

Return the heat flux [W/m^2].

Reimplemented in nonUnityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >.

Definition at line 134 of file unityLewisEddyDiffusivity.C.

References Foam::constant::atomic::group, IOobject::groupName(), and GeometricField< Type, GeoMesh, PrimitiveField >::New().

Here is the call graph for this function:

◆ q() [2/2]

tmp< scalarField > q ( const label patchi ) const

virtual

Return the patch heat flux [W/m^2].

Reimplemented in nonUnityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >.

Definition at line 151 of file unityLewisEddyDiffusivity.C.

References alpha(), patchi, and thermo.

Here is the call graph for this function:

◆ divq()

tmp< fvScalarMatrix > divq ( volScalarField & he ) const

virtual

Return the source term for the energy equation.

Reimplemented in nonUnityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >.

Definition at line 167 of file unityLewisEddyDiffusivity.C.

References alpha(), he(), and Foam::fvm::laplacian().

Here is the call graph for this function:

◆ j() [1/2]

tmp< surfaceScalarField > j ( const volScalarField & Yi ) const

virtual

Return the specie flux for the given specie mass-fraction [kg/m^2/s].

Definition at line 178 of file unityLewisEddyDiffusivity.C.

References IOobject::groupName(), Foam::fvc::interpolate(), IOobject::name(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), and Foam::fvc::snGrad().

Here is the call graph for this function:

◆ j() [2/2]

tmp< scalarField > j	(	const volScalarField &	Yi,
		const label	patchi
	)		const

virtual

Return the specie flux.

for the given specie mass-fraction for patch [kg/m^2/s]

Definition at line 197 of file unityLewisEddyDiffusivity.C.

References alpha(), GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), and patchi.

Here is the call graph for this function:

◆ divj()

tmp< fvScalarMatrix > divj ( volScalarField & Yi ) const

virtual

Return the source term for the given specie mass-fraction equation.

Definition at line 214 of file unityLewisEddyDiffusivity.C.

◆ predict()

void predict

virtual

Correct the unityLewisEddyDiffusivity viscosity.

Definition at line 224 of file unityLewisEddyDiffusivity.C.

Member Data Documentation

◆ Prt_

dimensionedScalar Prt_

protected

Turbulent Prandtl number [].

Definition at line 72 of file unityLewisEddyDiffusivity.H.

◆ alphat_

volScalarField alphat_

protected

Turbulent thermal diffusivity of enthalpy [kg/m/s].

Definition at line 77 of file unityLewisEddyDiffusivity.H.

Referenced by unityLewisEddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphat().

The documentation for this class was generated from the following files:

src/ThermophysicalTransportModels/fluid/turbulence/unityLewisEddyDiffusivity/unityLewisEddyDiffusivity.H
src/ThermophysicalTransportModels/fluid/turbulence/unityLewisEddyDiffusivity/unityLewisEddyDiffusivity.C
