Eddy-diffusivity based temperature gradient heat flux model for single specie RAS or LES of turbulent flow. More...

Inheritance diagram for eddyDiffusivity< TurbulenceThermophysicalTransportModel >:

Collaboration diagram for eddyDiffusivity< TurbulenceThermophysicalTransportModel >:

[legend]

Public Types
typedef TurbulenceThermophysicalTransportModel::alphaField	alphaField

typedef TurbulenceThermophysicalTransportModel::momentumTransportModel	momentumTransportModel

typedef TurbulenceThermophysicalTransportModel::thermoModel	thermoModel

Public Member Functions
	TypeName ("eddyDiffusivity")
	Runtime type information. More...

	eddyDiffusivity (const momentumTransportModel &momentumTransport, const thermoModel &thermo)
	Construct from a momentum transport model and a thermo model. More...

virtual	~eddyDiffusivity ()
	Destructor. More...

virtual bool	read ()
	Read thermophysicalTransport dictionary. More...

virtual tmp< volScalarField >	alphat () const
	Turbulent thermal diffusivity for enthalpy [kg/m/s]. More...

virtual tmp< scalarField >	alphat (const label patchi) const
	Turbulent thermal diffusivity for enthalpy for a patch [kg/m/s]. More...

virtual tmp< volScalarField >	kappaEff () const
	Effective thermal turbulent conductivity. More...

virtual tmp< scalarField >	kappaEff (const label patchi) const
	Effective thermal turbulent conductivity. More...

virtual tmp< scalarField >	alphaEff (const label patchi) const
	Effective thermal turbulent diffusivity. More...

virtual tmp< volScalarField >	DEff (const volScalarField &Yi) const
	Effective mass diffusion coefficient. More...

virtual tmp< scalarField >	DEff (const volScalarField &Yi, const label patchi) const
	Effective mass diffusion coefficient. More...

virtual tmp< surfaceScalarField >	q () const
	Return the heat flux [W/m^2]. More...

virtual tmp< scalarField >	q (const label patchi) const
	Return the patch heat flux [W/m^2]. More...

virtual tmp< fvScalarMatrix >	divq (volScalarField &he) const
	Return the source term for the energy equation. More...

virtual tmp< surfaceScalarField >	j (const volScalarField &Yi) const
	Return the specie flux for the given specie mass-fraction [kg/m^2/s]. More...

virtual tmp< scalarField >	j (const volScalarField &Yi, const label patchi) const
	Return the specie flux. More...

virtual tmp< fvScalarMatrix >	divj (volScalarField &Yi) const
	Return the source term for the given specie mass-fraction equation. More...

virtual void	predict ()
	Correct the eddyDiffusivity viscosity. More...

Protected Member Functions
virtual void	correctAlphat ()

tmp< volScalarField >	alphaEff () const
	Effective thermal turbulent diffusivity of mixture [kg/m/s]. More...

Protected Attributes
dimensionedScalar	Prt_
	Turbulent Prandtl number []. More...

volScalarField	alphat_
	Turbulent thermal diffusivity of enthalpy [kg/m/s]. More...

Detailed Description

template<class TurbulenceThermophysicalTransportModel>
class Foam::turbulenceThermophysicalTransportModels::eddyDiffusivity< TurbulenceThermophysicalTransportModel >

Eddy-diffusivity based temperature gradient heat flux model for single specie RAS or LES of turbulent flow.

The heat flux source is implemented as an implicit energy correction to the temperature gradient based flux source. At convergence the energy correction is 0.

Usage

LES
{
    model           eddyDiffusivity;
    Prt             0.85;
}

Source files

Definition at line 63 of file eddyDiffusivity.H.

Member Typedef Documentation

◆ alphaField

typedef TurbulenceThermophysicalTransportModel::alphaField alphaField

Definition at line 102 of file eddyDiffusivity.H.

◆ momentumTransportModel

typedef TurbulenceThermophysicalTransportModel::momentumTransportModel momentumTransportModel

Definition at line 106 of file eddyDiffusivity.H.

◆ thermoModel

typedef TurbulenceThermophysicalTransportModel::thermoModel thermoModel

Definition at line 109 of file eddyDiffusivity.H.

Constructor & Destructor Documentation

◆ eddyDiffusivity()

eddyDiffusivity	(	const momentumTransportModel &	momentumTransport,
		const thermoModel &	thermo
	)

Construct from a momentum transport model and a thermo model.

Definition at line 52 of file eddyDiffusivity.C.

◆ ~eddyDiffusivity()

virtual ~eddyDiffusivity ( )

inlinevirtual

Destructor.

Definition at line 127 of file eddyDiffusivity.H.

Member Function Documentation

◆ correctAlphat()

void correctAlphat

protectedvirtual

Definition at line 40 of file eddyDiffusivity.C.

◆ alphaEff() [1/2]

tmp<volScalarField> alphaEff ( ) const

inlineprotected

Effective thermal turbulent diffusivity of mixture [kg/m/s].

Used for the implicit energy correction on the temperature laplacian

Definition at line 89 of file eddyDiffusivity.H.

◆ TypeName()

TypeName ( "eddyDiffusivity< TurbulenceThermophysicalTransportModel >" )

Runtime type information.

◆ read()

bool read

virtual

Read thermophysicalTransport dictionary.

Definition at line 89 of file eddyDiffusivity.C.

References Foam::blockMeshTools::read().

Here is the call graph for this function:

◆ alphat() [1/2]

virtual tmp<volScalarField> alphat ( ) const

inlinevirtual

Turbulent thermal diffusivity for enthalpy [kg/m/s].

Definition at line 137 of file eddyDiffusivity.H.

References eddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphat_.

Referenced by eddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphat().

Here is the caller graph for this function:

◆ alphat() [2/2]

virtual tmp<scalarField> alphat ( const label patchi ) const

inlinevirtual

Turbulent thermal diffusivity for enthalpy for a patch [kg/m/s].

Definition at line 143 of file eddyDiffusivity.H.

References eddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphat(), and patchi.

Here is the call graph for this function:

◆ kappaEff() [1/2]

virtual tmp<volScalarField> kappaEff ( ) const

inlinevirtual

Effective thermal turbulent conductivity.

of mixture [W/m/K]

Definition at line 150 of file eddyDiffusivity.H.

◆ kappaEff() [2/2]

virtual tmp<scalarField> kappaEff ( const label patchi ) const

inlinevirtual

Effective thermal turbulent conductivity.

of mixture for patch [W/m/K]

Definition at line 157 of file eddyDiffusivity.H.

◆ alphaEff() [2/2]

virtual tmp<scalarField> alphaEff ( const label patchi ) const

inlinevirtual

Effective thermal turbulent diffusivity.

of mixture for a patch [kg/m/s]

Definition at line 166 of file eddyDiffusivity.H.

◆ DEff() [1/2]

tmp< volScalarField > DEff ( const volScalarField & Yi ) const

virtual

Effective mass diffusion coefficient.

for a given specie mass-fraction [kg/m/s]

Definition at line 106 of file eddyDiffusivity.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ DEff() [2/2]

tmp< scalarField > DEff	(	const volScalarField &	Yi,
		const label	patchi
	)		const

virtual

Effective mass diffusion coefficient.

for a given specie mass-fraction for patch [kg/m/s]

Definition at line 123 of file eddyDiffusivity.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ q() [1/2]

tmp< surfaceScalarField > q

virtual

Return the heat flux [W/m^2].

Definition at line 141 of file eddyDiffusivity.C.

References alpha(), Foam::constant::atomic::group, IOobject::groupName(), Foam::fvc::interpolate(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), Foam::fvc::snGrad(), Foam::T(), and thermo.

Here is the call graph for this function:

◆ q() [2/2]

tmp< scalarField > q ( const label patchi ) const

virtual

Return the patch heat flux [W/m^2].

Definition at line 157 of file eddyDiffusivity.C.

References alpha(), patchi, and thermo.

Here is the call graph for this function:

◆ divq()

tmp< fvScalarMatrix > divq ( volScalarField & he ) const

virtual

Return the source term for the energy equation.

Definition at line 173 of file eddyDiffusivity.C.

References alpha(), he(), Foam::fvc::laplacian(), Foam::fvm::laplacianCorrection(), Foam::T(), and thermo.

Here is the call graph for this function:

◆ j() [1/2]

tmp< surfaceScalarField > j ( const volScalarField & Yi ) const

virtual

Return the specie flux for the given specie mass-fraction [kg/m^2/s].

Definition at line 188 of file eddyDiffusivity.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ j() [2/2]

tmp< scalarField > j	(	const volScalarField &	Yi,
		const label	patchi
	)		const

virtual

Return the specie flux.

for the given specie mass-fraction for patch [kg/m^2/s]

Definition at line 205 of file eddyDiffusivity.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ divj()

tmp< fvScalarMatrix > divj ( volScalarField & Yi ) const

virtual

Return the source term for the given specie mass-fraction equation.

Definition at line 223 of file eddyDiffusivity.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::nl, and Foam::type().

Here is the call graph for this function:

◆ predict()

void predict

virtual

Correct the eddyDiffusivity viscosity.

Definition at line 239 of file eddyDiffusivity.C.

Member Data Documentation

◆ Prt_

dimensionedScalar Prt_

protected

Turbulent Prandtl number [].

Definition at line 75 of file eddyDiffusivity.H.

◆ alphat_

volScalarField alphat_

protected

Turbulent thermal diffusivity of enthalpy [kg/m/s].

Definition at line 80 of file eddyDiffusivity.H.

Referenced by eddyDiffusivity< TurbulenceThermophysicalTransportModel >::alphat().

The documentation for this class was generated from the following files:

src/ThermophysicalTransportModels/fluid/turbulence/eddyDiffusivity/eddyDiffusivity.H
src/ThermophysicalTransportModels/fluid/turbulence/eddyDiffusivity/eddyDiffusivity.C
