totalTemperatureFvPatchScalarField Class Reference

This boundary condition provides a total temperature condition. More...

Inheritance diagram for totalTemperatureFvPatchScalarField:
Inheritance graph
[legend]
Collaboration diagram for totalTemperatureFvPatchScalarField:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("totalTemperature")
 Runtime type information. More...

 totalTemperatureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 totalTemperatureFvPatchScalarField (const totalTemperatureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
 Construct by mapping given totalTemperatureFvPatchScalarField. More...

 totalTemperatureFvPatchScalarField (const totalTemperatureFvPatchScalarField &)=delete
 Disallow copy without setting internal field reference. More...

 totalTemperatureFvPatchScalarField (const totalTemperatureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField > clone (const DimensionedField< scalar, volMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

const scalarField & T0 () const
 Return the reference temperature. More...

scalarField & T0 ()
 Return reference to the temperature to allow adjustment. More...

virtual void map (const fvPatchScalarField &, const fieldMapper &)
 Map the given fvPatchField onto this fvPatchField. More...

virtual void reset (const fvPatchScalarField &)
 Reset the fvPatchField to the given fvPatchField. More...

virtual void updateCoeffs ()
 Update the coefficients associated with the patch field. More...

virtual void write (Ostream &) const
 Write. More...


Detailed Description

This boundary condition provides a total temperature condition.

Usage
Property Description Required Default value
U Velocity field name no U
phi Flux field name no phi
psi Compressibility field name no psi
gamma ratio of specific heats (Cp/Cv) yes
T0 reference temperature yes

Example of the boundary condition specification:

    <patchName>
    {
        type            totalTemperature;
        T0              uniform 300;
    }
Source files
See also
Foam::fixedValueFvPatchField

Definition at line 100 of file totalTemperatureFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ totalTemperatureFvPatchScalarField() [1/4]

totalTemperatureFvPatchScalarField ( const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const dictionary &  dict
)

Construct from patch, internal field and dictionary.

Definition at line 34 of file totalTemperatureFvPatchScalarField.C.

References dict, DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), fvPatchField< Type >::operator=(), and p.

Referenced by totalTemperatureFvPatchScalarField::clone().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ totalTemperatureFvPatchScalarField() [2/4]

totalTemperatureFvPatchScalarField ( const totalTemperatureFvPatchScalarField &  ptf,
const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const fieldMapper &  mapper
)

Construct by mapping given totalTemperatureFvPatchScalarField.

onto a new patch

Definition at line 62 of file totalTemperatureFvPatchScalarField.C.

◆ totalTemperatureFvPatchScalarField() [3/4]

totalTemperatureFvPatchScalarField ( const totalTemperatureFvPatchScalarField &  )
delete

Disallow copy without setting internal field reference.

◆ totalTemperatureFvPatchScalarField() [4/4]

totalTemperatureFvPatchScalarField ( const totalTemperatureFvPatchScalarField &  tppsf,
const DimensionedField< scalar, volMesh > &  iF
)

Copy constructor setting internal field reference.

Definition at line 79 of file totalTemperatureFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "totalTemperature"  )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 162 of file totalTemperatureFvPatchScalarField.H.

References totalTemperatureFvPatchScalarField::totalTemperatureFvPatchScalarField().

Here is the call graph for this function:

◆ T0() [1/2]

const scalarField& T0 ( ) const
inline

Return the reference temperature.

Definition at line 179 of file totalTemperatureFvPatchScalarField.H.

◆ T0() [2/2]

scalarField& T0 ( )
inline

Return reference to the temperature to allow adjustment.

Definition at line 185 of file totalTemperatureFvPatchScalarField.H.

◆ map()

void map ( const fvPatchScalarField &  ptf,
const fieldMapper &  mapper
)
virtual

Map the given fvPatchField onto this fvPatchField.

Definition at line 96 of file totalTemperatureFvPatchScalarField.C.

◆ reset()

void reset ( const fvPatchScalarField &  ptf)
virtual

Reset the fvPatchField to the given fvPatchField.

Used for mesh to mesh mapping

Definition at line 111 of file totalTemperatureFvPatchScalarField.C.

◆ updateCoeffs()

void updateCoeffs ( )
virtual

Update the coefficients associated with the patch field.

Definition at line 125 of file totalTemperatureFvPatchScalarField.C.

References Foam::magSqr(), and Foam::neg().

Here is the call graph for this function:

◆ write()

void write ( Ostream &  os) const
virtual

Write.

Definition at line 152 of file totalTemperatureFvPatchScalarField.C.

References fvPatchField< Type >::write(), and Foam::writeEntry().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
