The thermophysical properties of a solid. More...

Inheritance diagram for solidProperties:

[legend]

Public Member Functions
	TypeName ("solid")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, solidProperties,,(),())

	declareRunTimeSelectionTable (autoPtr, solidProperties, dictionary,(const dictionary &dict),(dict))

	solidProperties (scalar rho, scalar Cp, scalar kappa, scalar hf, scalar emissivity)
	Construct from components. More...

	solidProperties (const dictionary &dict)
	Construct from dictionary. More...

virtual autoPtr< solidProperties >	clone () const
	Construct and return clone. More...

virtual	~solidProperties ()
	Destructor. More...

scalar	rho () const
	Density [kg/m^3]. More...

scalar	Cp () const
	Specific heat capacity [J/kg/K]. More...

scalar	hf () const
	Heat of formation [J/kg]. More...

scalar	hs (const scalar T) const
	Sensible enthalpy [J/kg]. More...

scalar	ha (scalar T) const
	Absolute enthalpy [J/kg]. More...

scalar	es (const scalar T) const
	Sensible internal energy [J/kg]. More...

scalar	ea (scalar T) const
	Absolute internal energy [J/kg]. More...

scalar	kappa () const
	Thermal conductivity [W/m/K]. More...

scalar	emissivity () const
	Emissivity []. More...

void	readIfPresent (const dictionary &dict)
	Read and set the properties present it the given dictionary. More...

virtual void	write (Ostream &os) const
	Write the solidProperties properties. More...

Static Public Member Functions
static autoPtr< solidProperties >	New (const word &name)
	Return a pointer to a new solidProperties created from name. More...

static autoPtr< solidProperties >	New (const dictionary &dict)
	Return a pointer to a new solidProperties created from dictionary. More...

Friends
Ostream &	operator<< (Ostream &os, const solidProperties &s)
	Ostream Operator. More...

Detailed Description

The thermophysical properties of a solid.

Source files

Definition at line 55 of file solidProperties.H.

Constructor & Destructor Documentation

◆ solidProperties() [1/2]

solidProperties	(	scalar	rho,
		scalar	Cp,
		scalar	kappa,
		scalar	hf,
		scalar	emissivity
	)

Construct from components.

Definition at line 39 of file solidProperties.C.

Referenced by solidProperties::clone().

Here is the caller graph for this function:

◆ solidProperties() [2/2]

solidProperties ( const dictionary & dict )

Construct from dictionary.

Definition at line 56 of file solidProperties.C.

◆ ~solidProperties()

virtual ~solidProperties ( )

inlinevirtual

Destructor.

Definition at line 134 of file solidProperties.H.

Member Function Documentation

◆ TypeName()

TypeName ( "solid" )

Runtime type information.

◆ declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable	(	autoPtr	,
		solidProperties	,
		()	,
		()
	)

◆ declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable	(	autoPtr	,
		solidProperties	,
		dictionary	,
		(const dictionary &dict)	,
		(dict)
	)

◆ clone()

virtual autoPtr<solidProperties> clone ( ) const

inlinevirtual

Construct and return clone.

Reimplemented in CaCO3, C, and ash.

Definition at line 118 of file solidProperties.H.

References solidProperties::solidProperties().

Here is the call graph for this function:

◆ New() [1/2]

Foam::autoPtr< Foam::solidProperties > New ( const word & name )

static

Return a pointer to a new solidProperties created from name.

Definition at line 31 of file solidPropertiesNew.C.

References Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, InfoInFunction, Foam::name(), and Foam::nl.

Referenced by solidMixtureProperties::solidMixtureProperties().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ New() [2/2]

Foam::autoPtr< Foam::solidProperties > New ( const dictionary & dict )

static

Return a pointer to a new solidProperties created from dictionary.

Definition at line 57 of file solidPropertiesNew.C.

References dict, dictionaryName::dictName(), Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, dictionary::found(), InfoInFunction, dictionary::lookup(), Foam::New(), Foam::nl, and dictionary::optionalSubDict().

Here is the call graph for this function:

◆ rho()

Foam::scalar rho ( ) const

inline

Density [kg/m^3].

Definition at line 30 of file solidPropertiesI.H.

◆ Cp()

Foam::scalar Cp ( ) const

inline

Specific heat capacity [J/kg/K].

Definition at line 36 of file solidPropertiesI.H.

◆ hf()

Foam::scalar hf ( ) const

inline

Heat of formation [J/kg].

Definition at line 42 of file solidPropertiesI.H.

◆ hs()

Foam::scalar hs ( const scalar T ) const

inline

Sensible enthalpy [J/kg].

Definition at line 48 of file solidPropertiesI.H.

References Foam::T(), and Foam::constant::standard::Tstd.

Here is the call graph for this function:

◆ ha()

Foam::scalar ha ( scalar T ) const

inline

Absolute enthalpy [J/kg].

Definition at line 54 of file solidPropertiesI.H.

References hs(), and Foam::T().

Here is the call graph for this function:

◆ es()

Foam::scalar es ( const scalar T ) const

inline

Sensible internal energy [J/kg].

Definition at line 60 of file solidPropertiesI.H.

References hs(), and Foam::T().

Here is the call graph for this function:

◆ ea()

Foam::scalar ea ( scalar T ) const

inline

Absolute internal energy [J/kg].

Definition at line 66 of file solidPropertiesI.H.

References es(), and Foam::T().

Here is the call graph for this function:

◆ kappa()

Foam::scalar kappa ( ) const

inline

Thermal conductivity [W/m/K].

Definition at line 72 of file solidPropertiesI.H.

◆ emissivity()

Foam::scalar emissivity ( ) const

inline

Emissivity [].

Definition at line 78 of file solidPropertiesI.H.

◆ readIfPresent()

void readIfPresent ( const dictionary & dict )

Read and set the properties present it the given dictionary.

Definition at line 68 of file solidProperties.C.

References dict, and dictionary::readIfPresent().

Referenced by ash::ash(), C::C(), and CaCO3::CaCO3().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write the solidProperties properties.

Reimplemented in CaCO3, C, and ash.

Definition at line 79 of file solidProperties.C.

References token::SPACE.

Referenced by ash::write(), C::write(), and CaCO3::write().

Here is the caller graph for this function:

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<<	(	Ostream &	os,
		const solidProperties &	s
	)

friend

Ostream Operator.

The documentation for this class was generated from the following files:

src/thermophysicalModels/thermophysicalProperties/solidProperties/solidProperties/solidProperties.H
src/thermophysicalModels/thermophysicalProperties/solidProperties/solidProperties/solidProperties.C
src/thermophysicalModels/thermophysicalProperties/solidProperties/solidProperties/solidPropertiesI.H
src/thermophysicalModels/thermophysicalProperties/solidProperties/solidProperties/solidPropertiesNew.C
